Samsung GALAXY Note LTE

Announced
Jan 9, 2012
Market status
Released

US carrier availability

Discontinued: AT&T

Pros

  • Big display (5.3 inches)
  • High-resolution display (800 x 1280 pixels)
  • High-resolution camera (8 megapixels)
  • Dual core processor
  • Fast mobile data support (4G)
  • NFC
  • HDMI connector for TV-out (via microUSB)
  • Supports special active stylus for input

Cons

No cons

Share

embed

Description

This phone is AT&T's version of the Samsung Galaxy Note. It is coming with LTE connectivity and a dual-core 1.5GHz processor. The other specs between the already launched overseas model and the U.S. model are supposed to be the same including the 5.29 inch WXGA Super AMOLED screen. 1GB of RAM is aboard with 16GB of native storage included. That can be pumped up to as much as 48GB using a microSD card. The 8MP camera on back has AF and captures video at 1080p (at 30fps). The front-facing camera weighs in at 2MP for self-portraits and video chat.

Do you ...?




Unlock this phone Compare

Design

  • Device type:
    • Smart phone
  • OS:
    • Android (4.0, 2.3) TouchWiz UI
  • Dimensions:
    • 5.78 x 3.27 x 0.38 inches (147 x 83 x 10 mm)
  • Weight:
    • 6.28 oz (178 g)
      the average is 4.7 oz (136 g)

Display

  • Physical size:
    • 5.3 inches
  • Resolution:
    • 800 x 1280 pixels
  • Pixel density:

    Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.

    • 285 ppi
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • Super AMOLED
  • Colors:
    • 16 777 216
  • Touchscreen:
      • Multi-touch
  • Features:
    • Light sensor, Proximity sensor

Camera

  • Camera:
      • 8 megapixels
    • Flash:
      • LED
    • Aperture size:

      Aperture size - The aperture of a camera is the opening through which light travels before it reaches the camera sensor. The smaller the number is, the bigger this opening is, allowing for more light to pass.

      • F2.6
    • Features:
      • Autofocus, Smile detection, Burst mode, Panorama, Scenes
  • Camcorder:
      • 1920x1080 (1080p HD) (30 fps)
    • Features:
      • Video calling
  • Front-facing camera:
      • 2 megapixels

Hardware

  • System chip:

    System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.

    • Qualcomm Snapdragon S3 MSM8660
  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Dual core, 1500 MHz
  • Graphics processor:
      • Yes
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 1024 MB RAM
  • Built-in storage:
    • 16 GB
  • Storage expansion:
    • microSD, microSDHC up to 32 GB

Battery

  • Talk time:
    • 10.00 hours
      the average is 12 h (703 min)
  • Stand-by time:
    • 10.4 days (250 hours)
      the average is 20 days (490 h)
  • Capacity:
    • 2500 mAh

Multimedia

  • Music player:
    • Filter by:
      • Album, Artist, Playlists
    • Features:
      • Album art cover, Background playback
  • Speakers:
    • Earpiece, Loudspeaker
  • YouTube player:
    • Yes

Internet browsing

  • Built-in online services support:
    • Facebook, YouTube (upload), Picasa/Google+, Twitter

Technology

  • GSM:
    • 850, 900, 1800, 1900 MHz
  • UMTS:
    • 850, 1900, 2100 MHz
  • FDD LTE:
    • 700 (band 17), 1700/2100 (band 4) MHz
  • Data:
    • LTE, HSDPA+ (4G) 21.1 Mbit/s, HSDPA 14.4 Mbit/s, HSUPA 5.76 Mbit/s, UMTS
  • Positioning:

    Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.

    • A-GPS, Glonass
  • Navigation:
    • Yes
specifications continue after the ad

Connectivity

  • Bluetooth:
      • 3.0
  • Wi-Fi:
      • 802.11 b, g, n
    • Mobile hotspot:
      • Yes
  • USB:
      • USB 2.0
    • Connector:
      • microUSB
    • Features:
      • Mass storage device, USB charging
  • HDMI:
      • via microUSB
  • Other:
    • TV-Out, NFC, MHL, Computer sync, OTA sync

Other features

  • Notifications:
    • Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
  • Sensors:
      • Accelerometer, Barometer
  • Hearing aid compatibility:
      • M3
    • Voice dialing, Voice commands, Voice recording, TTY/TDD

Availability

  • Officially announced:
    • 09 Jan 2012

Shopping information

  • MSRP price:
    • $ 300

To see the full specifications with in-depth details click here.

This device is also known as Samsung SGH-I717


Despite our efforts to provide full and correct Samsung GALAXY Note LTE specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.


If you are interested in using our specs commercially, check out our Phone specs database licensing page.
