Asus ZenFone 3 Deluxe

Asus ZenFone 3 Deluxe
5.7"
1080 x 1920 pixels
23 MP
8 MP front
Qualcomm Snapdragon 821
Quad-core, 2400 MHz
RAM: 6 GB
MEMORY: 256 GB + MicroSD
BATTERY: 3000 mAh
Announced: May 30, 2016
Market status: Released
Release date: Jul 12, 2016
Features: Fingerprint Lightweight Thin LTE Rugged NFC Dual SIM

Pros

  • High screen-to-body ratio (73.89 %)
  • Big display (5.7 inches)
  • Lots of RAM (6 GB RAM)
  • Dual SIM card support

Cons

No cons

Share

embed

Description

The Asus ZenFone 3 Deluxe is made to impress with its all-metal construction. The phone comes with 5.7-inch Full HD Super AMOLED display, Qualcomm Snapdragon 820 SOC and 6GB of RAM. The main camera is 23-megapixel one with OIS and ASUS TriTech autofocus system. The ZenFone 3 Deluxe also features fingerprint sensor, USB 3.0 Type-C and Quick charge 3.

Do you ...?




Compare

Design

  • Device type:
    • Smart phone
  • OS:
    • PopupAndroid (6.0), ZenUI 3.0 UI
  • Dimensions:
    • 6.16 x 3.05 x 0.30 inches (156.4 x 77.4 x 7.5 mm)
  • Weight:
    • 6.00 oz (170 g)
      the average is 5.5 oz (158 g)
  • Materials:
    • Main body: Aluminum
  • Features:
    • Fingerprint (touch), Touch sensitive control keys, Soft keys
  • Colors:
    • Gold, Gray, Silver

Displaybenchmark

  • Physical size:
    • 5.7 inches
  • Resolution:
    • 1080 x 1920 pixels
  • Pixel density:

    Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.

    • 386 ppi
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • Super AMOLED
  • Screen-to-body ratio:

    Screen-to-body ratio - Shows what part of the frontal area of a phone its screen occupies.

    • 73.89 %
  • Features:
    • Oleophobic coating, Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor

Camerabenchmark

  • Camera:
      • Popup23 megapixels
    • Flash:
      • Dual LED
    • Aperture size:

      Aperture size - The aperture of a camera is the opening through which light travels before it reaches the camera sensor. The smaller the number is, the bigger this opening is, allowing for more light to pass.

      • F2.0
    • Camera sensor size:

      Camera sensor size - A bigger camera sensor is able to capture more light, and thus produce better photos.

      • 1/2.6"
    • Pixel size:

      Pixel size - The size of an individual pixel on a camera's sensor. The bigger, the better.

      • 1 μm
    • Hardware Features:
      • Sapphire crystal lens cover, Optical image stabilization, Autofocus (Laser, Phase detection)
    • Software Features:
      • Touch to focus, Smile detection, Face detection, Self-timer, Digital zoom, Geo tagging
    • Settings:
      • Exposure compensation, ISO control, White balance presets
    • Shooting Modes:
      • High Dynamic Range mode (HDR), Panorama, Night mode, Effects
  • Camcorder:
      • 3840x2160 (4K) (30 fps)
    • Features:
      • Continuous autofocus, Digital image stabilization, Video calling, Video sharing
  • Front-facing camera:
      • 8 megapixels
    • Features:
      • Wide Angle, High Dynamic Range mode (HDR)

Hardwarebenchmark

  • System chip:

    System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.

    • Qualcomm Snapdragon 821 MSM8996 Pro
  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Quad-core, 2400 MHz, Kryo, 64-bit
  • Graphics processor:

    Graphics processor - The graphics processor is important for the smooth operation of the system and especially in games and other applications that may involve complex graphics and animations.

      • Adreno 530
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 6 GB RAM
  • Built-in storage:

    Built-in storage - Bigger storage capacity allows you to keep more content saved onto your device, such as more applications, photos or video. Games and video content typically take up the biggest amount of storage space.

    • 256 GB
  • Storage expansion:

    Storage expansion - Some handsets allow you to expand their storage capacity by using a memory expansion card – most often microSD. Expansion memory is mostly suitable for media storage, such as photo, video or music content.

    • microSD, microSDHC, microSDXC up to 128 GB

Batterybenchmark

  • Capacity:

    Capacity - The bigger, the better! However, battery capacity is not the only factor that has an effect on battery life. Those include the chipset in use, the software running on the device, as well as the consumer's unique usage pattern.

    • 3000 mAh
  • Type:
    • Not user replaceable, Li - Ion

Multimediabenchmark

  • Music player:
    • Filter by:
      • Album, Artist, Genre, Playlists
    • Features:
      • Album art cover, Background playback
  • Speakers:
    • Earpiece, Loudspeaker

Cellular

  • CDMA:

    CDMA - Code Division Multiple Access. A technique of multiplexing, also called spread spectrum, in which analog signals are converted into digital form for transmission. For each communication channel, the signals are encoded in a sequence known to the transmitter and the receiver for that channel. The foremost application is digital cellular phone technology from QUALCOMM that operates in the 800MHz band and 1.9GHz PCS band. CDMA phones are noted for their excellent call quality and long battery life.

    • 800 MHz
  • GSM:
    • 850, 900, 1800, 1900 MHz
  • UMTS:
    • 800, 850, 900, 1700/2100, 1900, 2100 MHz
  • LTE (FDD):
    • Bands 1, 2, 3, 4, 5, 7, 8, 12, 17, 18, 19, 20, 26, 28, 29, 30
  • LTE (TDD):
    • Bands 38, 39, 40, 41
  • Data:
    • LTE-A, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
  • Micro SIM:
    • Yes
  • Nano SIM:
    • Yes
  • Multiple SIM cards:
    • 2 slots

Phone features

  • Sensors:
      • Accelerometer, Gyroscope, Compass, Hall (for flip covers)
  • Notifications:
    • Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
  • Other features:
    • Voice dialing, Voice commands, Voice recording
specifications continue after the ad

Connectivity

  • Bluetooth:
      • 4.2, EDR
  • Wi-Fi:
      • 802.11 b, g, n, ac, dual-band
    • Mobile hotspot:
      • Yes
  • USB:
      • USB 3.0
    • Connector:
      • USB Type-C (reversible)
    • Features:
      • Mass storage device, USB charging
  • Positioning:

    Positioning - This field shows the positioning systems supported by the device. The most common types are GPS and A-GPS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization.

    • GPS, A-GPS, Glonass, BeiDou
  • Navigation:
    • Turn-by-turn navigation, Voice navigation
  • Other:
    • NFC, Tethering, Computer sync, OTA sync

Availability

  • Officially announced:
    • 30 May 2016

Regulatory Approval

  • FCC approval:

    FCC approval - The Federal Communications Commission (FCC) is an independent United States government agency, directly responsible to Congress. The FCC was established by the Communications Act of 1934 and is charged with regulating interstate and international communications by radio, television, wire, satellite and cable. The FCC's jurisdiction covers the 50 states, the District of Columbia, and U.S. possessions. Every wireless phone device that is sold in the U.S. has to be tested and approved for sale by the FCC.

    • Date approved:

      Date approved - Shows the date when the particular phone is approved by the Federal Communications Commission

      • 17 Jul 2017
      • FCC ID value:

        FCC ID value - Shows the FCC Identifying value of the particular phone

        MSQX00ID link
  • FCC measured SAR:

    FCC measured SAR - Working closely with federal health and safety agencies, such as the Food and Drug Administration (FDA), the FCC has adopted limits for safe exposure to radiofrequency (RF) energy. These limits are given in terms of a unit referred to as the Specific Absorption Rate (SAR), which is a measure of the amount of radio frequency energy absorbed by the body when using a mobile phone. The FCC requires cell phone manufacturers to ensure that their phones comply with these objective limits for safe exposure. Any cell phone at or below these SAR levels (that is, any phone legally sold in the U.S.) is a "safe" phone, as measured by these standards. The FCC limit for public exposure from cellular telephones is an SAR level of 1.6 watts per kilogram (1.6 W/kg).

    • Head:
      • 0.29 W/kg
    • Body:
      • 0.81 W/kg
    • Simultaneous Transmission:
      • 1.08 W/kg
    • Wireless Router:
      • 1.08 W/kg

To see the full specifications with in-depth details click here.

This device is also known as Asus ZS570KL


Despite our efforts to provide full and correct Asus ZenFone 3 Deluxe specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.


If you are interested in using our specs commercially, check out our Phone specs database licensing page.
