HTC Trophy

HTC Trophy
3.8"
480 x 800 pixels
5 MP
Qualcomm Snapdragon S1
Single core, 1000 MHz
RAM: 0.6 GB
MEMORY: 16 GB
BATTERY: 1300 mAh
Announced: May 19, 2011
Market status: Released
Release date: May 26, 2011
Features: Fingerprint Lightweight Thin LTE Rugged NFC Dual SIM

US carrier availability

Discontinued: Verizon

Pros

No pros

Cons

  • Lacks microSD slot for storage expansion
  • No front-facing camera
  • Too little RAM memory (0.6 GB RAM)
  • Single-core processor
  • Low pixel density screen (246 ppi)
  • Low-resolution camera (5 megapixels)

Share

embed

Description

HTC Trophy is a global Windows Phone 7 device for Verizon Wireless. It has a 1GHz processor, 3.8" WVGA display, 5MP Autofocus camera with LED flash, 720p video recording, 16GB of on-board memory, 576MB RAM / 512MB ROM , FM Radio, and will support DLNA.

Do you ...?




Compare

Design

  • Device type:
    • Smart phone
  • OS:
    • Windows Phone, 7.5 Mango
  • Dimensions:
    • 4.67 x 2.42 x 0.47 inches (119 x 61 x 12 mm)
  • Weight:
    • 4.90 oz (139 g)
      the average is 5.4 oz (154 g)

Display

  • Physical size:
    • 3.8 inches
  • Resolution:
    • 480 x 800 pixels
  • Pixel density:

    Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.

    • 246 ppi
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • TFT
  • Screen-to-body ratio:

    Screen-to-body ratio - Shows what part of the frontal area of a phone its screen occupies.

    • 56.37 %
  • Features:
    • Ambient light sensor, Proximity sensor, Scratch-resistant glass

Camera

  • Camera:
      • 5 megapixels
    • Flash:
      • LED
    • Hardware Features:
      • Autofocus
    • Software Features:
    • Shooting Modes:
      • Scenes
  • Camcorder:
      • 1280x720 (720p HD) (24 fps)
    • Features:
      • Continuous autofocus

Hardware

  • System chip:

    System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.

    • Qualcomm Snapdragon S1 QSD8250
  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Single core, 1000 MHz, Scorpion
  • Graphics processor:

    Graphics processor - The graphics processor is important for the smooth operation of the system and especially in games and other applications that may involve complex graphics and animations.

      • Adreno 200
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 0.6 GB RAM / 512 MB ROM
  • Built-in storage:

    Built-in storage - Bigger storage capacity allows you to keep more content saved onto your device, such as more applications, photos or video. Games and video content typically take up the biggest amount of storage space.

    • 16 GB

Battery

  • Capacity:

    Capacity - The bigger, the better! However, battery capacity is not the only factor that has an effect on battery life. Those include the chipset in use, the software running on the device, as well as the consumer's unique usage pattern.

    • 1300 mAh
  • Type:
    • User replaceable, Li - Ion
  • Talk time:
    • 4.90 hours
      the average is 26 h (1589 min)
  • Stand-by time:
    • 11.9 days (286 hours)
      the average is 20 days (481 h)

Multimedia

  • Screen mirroring:
    • DLNA
  • Radio:
      • FM

Cellular

  • CDMA:

    CDMA - Code Division Multiple Access. A technique of multiplexing, also called spread spectrum, in which analog signals are converted into digital form for transmission. For each communication channel, the signals are encoded in a sequence known to the transmitter and the receiver for that channel. The foremost application is digital cellular phone technology from QUALCOMM that operates in the 800MHz band and 1.9GHz PCS band. CDMA phones are noted for their excellent call quality and long battery life.

    • 800, 1900 MHz
  • GSM:
    • 850, 900, 1800, 1900 MHz
  • UMTS:
    • 2100 MHz
  • Data:
    • HSDPA 7.2 Mbit/s, HSUPA 2 Mbit/s, UMTS

Phone features

  • Sensors:
      • Accelerometer, Compass
  • Notifications:
    • Service lights, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
  • Hearing aid compatibility:
      • M4, T4
  • Other features:
    • Voice recording, TTY/TDD
specifications continue after the ad

Connectivity

  • Bluetooth:
      • 2.1, EDR
  • Wi-Fi:
      • 802.11 b, g, n
  • USB:
      • USB 2.0
    • Connector:
      • microUSB
  • Positioning:

    Positioning - This field shows the positioning systems supported by the device. The most common types are GPS and A-GPS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization.

    • GPS, A-GPS
  • Navigation:
    • Yes
  • Other:
    • Computer sync, OTA sync

Availability

  • Officially announced:
    • 19 May 2011

Shopping information

  • MSRP price:
    • $ 430

Regulatory Approval

  • FCC approval:

    FCC approval - The Federal Communications Commission (FCC) is an independent United States government agency, directly responsible to Congress. The FCC was established by the Communications Act of 1934 and is charged with regulating interstate and international communications by radio, television, wire, satellite and cable. The FCC's jurisdiction covers the 50 states, the District of Columbia, and U.S. possessions. Every wireless phone device that is sold in the U.S. has to be tested and approved for sale by the FCC.

    • Date approved:

      Date approved - Shows the date when the particular phone is approved by the Federal Communications Commission

      • 06 Jan 2011
      • FCC ID value:

        FCC ID value - Shows the FCC Identifying value of the particular phone

        NM8PC40200 link
  • FCC measured SAR:

    FCC measured SAR - Working closely with federal health and safety agencies, such as the Food and Drug Administration (FDA), the FCC has adopted limits for safe exposure to radiofrequency (RF) energy. These limits are given in terms of a unit referred to as the Specific Absorption Rate (SAR), which is a measure of the amount of radio frequency energy absorbed by the body when using a mobile phone. The FCC requires cell phone manufacturers to ensure that their phones comply with these objective limits for safe exposure. Any cell phone at or below these SAR levels (that is, any phone legally sold in the U.S.) is a "safe" phone, as measured by these standards. The FCC limit for public exposure from cellular telephones is an SAR level of 1.6 watts per kilogram (1.6 W/kg).

    • Head:
      • 1.48 W/kg
    • Body:
      • 1.02 W/kg

To see the full specifications with in-depth details click here.


Despite our efforts to provide full and correct HTC Trophy specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.


If you are interested in using our specs commercially, check out our Phone specs database licensing page.
