Google Pixel 3 XL vs Galaxy Note 9 vs iPhone XS Max: Specs comparison
With the Pixel 3 XL, Google is certainly betting big on becoming a mainstream smartphone maker, which it kind of failed with the previous generations of its smartphone lineup due to certain supply and availability issues that plagued it. Hopefully, the Pixel 3 XL won't be subjected to the same set of problems.

Anyhoo, now that the Pixel 3 XL with its eye-sore notch is official, a slew of specs comparison are in queue to mercilessly stack it up against some of the very best phones out there, and chief among these are the Samsung Galaxy Note 9 and the iPhone XS Max. Each is ponying up a rather commendable bag of features that will certainly give the new Pixel 3 XL a run for its money, though we shouldn't underestimate the new Google flagship at all.

How does the Pixel 3 XL stack up against those two, pound for pound? Of course, specs aren't everything as they don't factor in the software and the overall experience, yet it's still rather important to compare the hardware prowess of all three devices and see which one would net the most bag for the buck.

Google Pixel 3 XL Samsung Galaxy Note9 Apple iPhone XS Max

Design

Dimensions
6.22 x 3.02 x 0.31 inches
158 x 76.7 x 7.9 mm
6.37 x 3.01 x 0.35 inches
161.9 x 76.4 x 8.8 mm
6.20 x 3.05 x 0.30 inches
157.5 x 77.4 x 7.7 mm
Weight
6.49 oz (184.0 g) 7.09 oz (201.0 g) 7.34 oz (208.0 g)
Materials
Back: Glass (Corning Gorilla Glass 5)
Frame: Aluminum
Back: Glass (Corning Gorilla Glass 5)
Frame: Aluminum
Back: Glass
Frame: Stainless steel
Resistance
Water, Dust; IP68 Water, Dust; IP68 Water, Dust; IP68
Biometrics
Fingerprint (touch) Iris scanner, 2D Face unlock, Fingerprint (touch) 3D Face unlock
Features
Notification light, Stylus
Keys
Right: Volume control, Lock/Unlock key Left: Volume control, Lock/Unlock key; Right: Other Left: Volume control, Other; Right: Lock/Unlock key
Colors
Black, Pink, White Midnight black, Ocean blue, Cloud silver, Lavender purple Gold, Silver, Space gray

Display

Size
6.3-inch 6.4-inch 6.5-inch
Resolution
2960x1440px, 18.5:9 ratio, 522 PPI 2960x1440px, 18.5:9 ratio, 516 PPI 2688x1242px, 19.5:9 ratio, 458 PPI
Technology
Super AMOLED Super AMOLED OLED
Screen-to-body
83.12 % 83.51 % 84.29 %
Peak brightness
625 cd/m2 (nit)
Features
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor HDR support, Pressure-sensitive, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor

Hardware

System chip
Qualcomm Snapdragon 845 SDM845 (10 nm) Qualcomm Snapdragon 845 SDM845 (10 nm) Apple A12 Bionic APL1W81 (7 nm)
Processor
Octa-core
2500 MHz
Kryo 385
Octa-core
2800 MHz
Kryo 385
Hexa-core
2490 MHz
Vortex and Tempest
GPU
Adreno 630 Adreno 630 Apple 4-core GPU
RAM
4GB (LPDDR4) 6GB (LPDDR4) 4GB (LPDDR4)
Internal storage
64GB 128GB 64GB
Storage expansion
not expandable microSDXC up to 512 GB not expandable
OS
Android (12, 11, 10, 9.0 Pie) Android (10, 9.0 Pie, 8.1 Oreo), Samsung One UI iOS (15.x, 14.x, 13.x, 12.x)

Battery

Capacity
3430 mAh 4000 mAh 3179 mAh
Type
Li - Polymer Li - Ion Li - Ion
Charging
USB Power Delivery, Qi wireless charging Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging USB Power Delivery, Qi wireless charging
Charge speed
Wired: 15.0W
Wireless: 7.5W

Camera

Rear
Single camera Dual camera Dual camera
Main camera
12.2 MP (OIS, PDAF, CMOS image sensor)
Aperture size: F1.8
Focal length: 28 mm
Sensor size: 1/2.55"
Pixel size: 1.4 μm
12 MP (OIS, PDAF)
Aperture size: F1.5/F2.4
Focal length: 26 mm
Sensor size: 1/2.55"
Pixel size: 1.4 μm
12 MP (Sapphire crystal lens cover, OIS, PDAF, CMOS image sensor, BSI sensor)
Aperture size: F1.8
Focal length: 26 mm
Sensor size: 1/2.55"
Pixel size: 1.4 μm
Second camera
12 MP (Telephoto, OIS, Autofocus)
Optical zoom: 2.0x
Aperture size: F2.4
Focal Length: 52 mm
Sensor size: 1/3.4"
Pixel size: 1 μm
12 MP (Telephoto, Sapphire crystal lens cover, OIS, PDAF, CMOS image sensor, BSI sensor)
Optical zoom: 2.0x
Aperture size: F2.4
Focal Length: 52 mm
Sensor size: 1/3.4"
Pixel size: 1 μm
Flash
Dual LED LED Quad LED
Video recording
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (120 fps), 1280x720 (HD) (240 fps)
OIS, EIS, Video calling, Video sharing
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Time-lapse video, Hyperlapse, Continuous autofocus, Object tracking, EIS
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD)
OIS, Time-lapse video, Continuous autofocus, Picture-taking during video recording, Video calling, Video sharing
Front
8 MP (Dual-Camera, Wide Angle, Autofocus), Video capture: 1920x1080 (Full HD) 8 MP (Wide Angle, Autofocus), Video capture: 2560x1440 (QHD) (30 fps) 7 MP (Wide Angle, HDR), Video capture: 1920x1080 (Full HD)

Connectivity & Features

Bluetooth
5.0 5.0 5.0
WLAN
802.11 a,b,g,n,ac,dual-band
Wi-Fi Direct, Hotspot
802.11 a,b,g,n,ac,dual-band
MIMO, Wi-Fi Direct, Hotspot
802.11 a,b,g,n,ac,dual-band
MIMO, Wi-Fi Direct, Hotspot
USB
Type-C, USB 3.1 Type-C, USB 3.1 Lightning
Hearing aid compatible
M3/T3 M4/T3 M3/T4
Location
GPS, A-GPS, Glonass, Galileo GPS, A-GPS, Glonass, Cell ID, Wi-Fi positioning GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Sensors
Accelerometer, Gyroscope, Compass, Barometer Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer Accelerometer, Gyroscope, Compass, Barometer
Other
NFC, VoIP, Tethering, Computer sync, OTA sync NFC, ANT+ NFC, UMA (Wi-Fi Calling)

Multimedia

Headphones
No 3.5mm jack 3.5mm jack No 3.5mm jack
Speakers
Earpiece, Multiple speakers Earpiece, Multiple speakers Earpiece, Multiple speakers
Features
Album art cover, Background playback 32-Bit DAC, Dolby Atmos
Screen mirroring
Wireless screen share Wireless screen share Wireless screen share
Additional microphone(s)
Noise cancellation Noise cancellation Noise cancellation, Video recording

Cellular

4G (FDD)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 32(1500 L-band), 66(AWS-3), 71(600) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD)
Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46 Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46 Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46
3G
Bands 1(2100), 2(1900), 4(1700/2100), 5(850) Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100) Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed
LTE-A Pro Cat 16 (1000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA, UMTS LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA LTE-A Pro Cat 16 (1000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, HSUPA, UMTS
Dual SIM
Yes Yes
SIM type
Nano SIM, eSIM Nano SIM Nano SIM, eSIM
HD Voice
Yes Yes Yes
VoLTE
Yes Yes Yes

Regulatory Approval

FCC approval
Date approved: Aug 31, 2018
FCC ID value: A4RG013C
Date approved: Jul 03, 2018
FCC ID value: A3LSMN960U
Date approved: Sep 12, 2018
FCC ID value: BCG-E3219A
Measured SAR
Head: 1.35 W/kg
Body: 1.19 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 1.35 W/kg
Phablet: 3.48 W/kg
Head: 0.27 W/kg
Body: 0.76 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 1.35 W/kg
Phablet: 3.90 W/kg
Head: 1.00 W/kg
Body: 1.00 W/kg
Simultaneous Transmission: 1.52 W/kg
Wireless Router: 1.00 W/kg

Buyers information

MSRP
$ 899 $ 1000 $ 1099
In The Box
Quick Switch Adapter, USB-C to USB-C cable, USB-C 18W Power adapter, Pixel USB-C earbuds, USB-C to 3.5mm headphone adapter, SIM tool, Quick Start Guide S Pen, USB Cable, Earphones, SIM removal tool, USB power adaptor, USB connector, Pen, nibs, Tweezer, Clear cover case, Quick start guide, USB connector leaflet. EarPods with Lightning Connector, Lightning to USB Cable, USB Power Adapter, Documentation

Availability

Officially announced
Oct 09, 2018 Aug 09, 2018 Sep 12, 2018
