Samsung Galaxy Z Fold 5

Full Specifications

Released · Aug 11, 2023

6.6

Read Samsung Galaxy Z Fold 5 Review

Be the first to review this phone

I want it 1 user

I have it 3 users

I had it 0 users

Popular Comparisons

The Samsung Galaxy Z Fold 5 is most commonly compared with these phones:

Design
Dimensions	6.10 x 5.11 x 0.24 inches 154.9 x 129.9 x 6.1 mm
Folded	6.10 x2.64 x0.52 inches (154.9 x 67.1 x 13.4 mm)
Weight	8.92 oz (253.0 g)
Materials	Back: Glass (Corning Gorilla Glass Victus 2) Frame: Aluminum
Resistance	Water; IPX8
Biometrics	Fingerprint (touch)
Keys	Right: Volume control, Lock/Unlock key
Colors	Icy Blue, Phantom Black, Cream, Gray, Blue

Display
Size	7.6-inch
Resolution	2176x1812px, 21.6:18 ratio, 373 PPI
Technology	Dynamic AMOLED
Refresh rate	120Hz
Screen-to-body	91.12 %
Peak brightness	1750 cd/m2 (nit)
Features	Folding inside the device, HDR support, Ambient light sensor, Proximity sensor
Front cover display	6.2 inches 2316 x904 px Dynamic AMOLED 120Hz refresh rate, Scratch-resistant glass (Corning Gorilla Glass Victus 2), Ambient light sensor, Proximity senso

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	1 (Excellent)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Qualcomm Snapdragon 8 Gen 2 SM8550-AC (4 nm)
Processor	Octa-core 1x 3.36GHz Cortex-X3 + 2x 2.8GHz Cortex-A715 + 2x 2.8GHz Cortex-A710 + 3x 2.0GHz Cortex-A510
GPU	Adreno 740
RAM	12GB
Internal storage	256GB
Storage expansion	not expandable
OS	Android (14, 13)
This device has different variants: View all

PhoneArena Performance Test
GeekBench 6 Single	2062
GeekBench 6 Multi	5531
3D Mark High	3886
3D Mark Low	2158
Learn more on our PhoneArena Performance Test Results page.

Battery
Capacity	4400 mAh
Type	Li - Polymer
Charging	Fast charging, Qi wireless charging, Reverse wireless charging
Charge speed	Wired: 25.0W Wireless: 15.0W

PhoneArena Battery Test
Battery Life Estimate:	4h 41min
Browsing:	9h 22min
Gaming:	9h 27min
Video:	6h 30min
Learn more on our PhoneArena Battery Test Results page.

Camera
Rear	Triple camera
Main camera	50 MP (OIS, PDAF) Aperture size: F1.8 Focal length: 23 mm Sensor size: 1/1.56" Pixel size: 1.0 μm
Second camera	12 MP (Ultra-wide) Aperture size: F2.2 Focal Length: 12 mm Sensor size: 1/3.06" Pixel size: 1.12 μm
Third camera	10 MP (Telephoto) Aperture size: F2.4 Focal Length: 66 mm Sensor size: 1/3.94" Pixel size: 1.0 μm
Flash	LED
Video recording	7680x4320 (8K UHD) (30 fps), 3840x2160 (4K UHD) (60 fps)
Front	4 MP (Under-screen) Folded: 10 MP

PhoneArena Camera Test
Overall score:	140
Photo score:	144
Video score:	135
Learn more on our PhoneArena Camera Test Results page.

Connectivity & Features
Bluetooth	5.3
Wi-Fi	802.11 a,b,g,n,ac,ax(Wi-Fi 6),Wi-Fi 6E Wi-Fi Direct, Hotspot
USB	Type-C
Location	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors	Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other	NFC

Multimedia
Headphones	No 3.5mm jack
Speakers	Earpiece, Multiple speakers
Screen mirroring	Wireless screen share
Additional microphone(s)	Noise cancellation

Cellular
5G	Bands n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n29, n30, n40, n41, n66, n78, 5G Ready
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 66(AWS-3)
4G (TDD)	Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
3G	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type	Dual Nano SIM + eSIM

Regulatory Approval
FCC approval	Date approved: Jun 26, 2023 FCC ID value: A3LSMF946U
Measured SAR	Head: 1.16 W/kg Body: 1.07 W/kg Simultaneous Transmission: 1.57 W/kg

Buyers information
MSRP	$ 1799
In The Box	USB-C cable, SIM ejector tool, Paperwork

Availability
Officially announced	Jul 26, 2023

Despite our efforts to provide full and correct Samsung Galaxy Z Fold 5 specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

With 512GB internal storage

Differences from the main variant:
Internal storage	512GB

With 1TB internal storage

Differences from the main variant:
Internal storage	1024GB
