ZTE Axon M

Announced:
Oct 17, 2017
Market status:
Released
Release date:
Nov 1, 2017

PhoneArena Rating:

4.0
Read Full Review

Display

Display size:

5.2 inches

Resolution:

1080 x 1920 pixels

Pixel density:

424 ppi

Technology:

IPS LCD

Screen-to-body ratio:

68.98 %

Features:

Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor

Additional display:

5.2 inches, 1080 x 1920 pixels, IPS LCD, Colors: 16 777 216, Touch screen: Yes, Capacitive, Multi-touch: Yes

Camera

Rear:

Single camera

Main camera:

20 megapixels

Hardware Features:

Doubles as a front camera, Phase detection autofocus

Specifications:

Aperture size: F1.8; Sensor size: 1/2.8"; Pixel size: 1 μm

Flash:

Dual LED

Video recording:

3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (30 fps), 1280x720 (HD) (240 fps)

Features:

Time-lapse video, Picture-taking during video recording, Digital image stabilization, Video calling, Video sharing

Design

Dimensions:

5.94 x 2.82 x 0.48 inches (150.8 x 71.6 x 12.1 mm)

Weight:

8.11 oz (230 g)
the average is 6.1 oz (173 g)

Materials:

Back: Aluminum

Biometrics:

Fingerprint (touch)

Colors:

Black

Multimedia

Headphones:

3.5 mm jack

Speakers:

Earpiece, Loudspeaker

Features:

Album art cover, Background playback, Dolby Atmos

Screen mirroring:

Wireless screen share

Additional microphone(s):

for Noise cancellation

Hardware & Performance

System chip:

Qualcomm Snapdragon 821 MSM8996 Pro-AB

Processor:

Quad-core, 2150 MHz, Kryo, 64-bit, 14 nm

GPU:

Adreno 530

RAM:

4 GB

Internal storage:

64 GB

Available to use:

49 GB

Storage expansion:

microSDXC up to 256 GB

OS:

Android (7.1 Nougat)

Connectivity & Features

Bluetooth:

4.2

Wi-Fi:

802.11 a, b, g, n, ac, dual-band; Hotspot, Wi-Fi Direct

USB:

USB Type-C (reversible), USB 2.0

Features:

Mass storage device, USB charging

Location:

GPS, A-GPS

Sensors:

Accelerometer

Other:

NFC, VoIP, Tethering, Computer sync, OTA sync

Cellular

LTE (FDD):

Bands 2, 4, 5, 12, 29, 30, 66

UMTS:

850, 1700/2100, 1900 MHz

Data:

LTE, HSPA, HSUPA

SIM type:

Nano SIM

HD Voice:

Yes

VoLTE:

Yes

Battery

Capacity:

3180 mAh

Type:

Not user replaceable

Charging:

Yes

Talk time:

28.70 hours
the average is 21 h (1250 min)

Stand-by time:

12.1 days (290 hours)
the average is 21 days (493 h)

Phone features

Notifications:

Haptic feedback, Music ringtones, Vibration, Flight mode, Silent mode, Speakerphone

Other features:

Voice dialing, Voice commands, Voice recording, TTY/TDD

Regulatory Approval

FCC approval:

Date approved:

Oct 09, 2017

FCC ID value:

SRQ-Z999 link

FCC measured SAR:

Head:

0.68 W/kg

Body:

0.10 W/kg

Simultaneous Transmission:

1.48 W/kg

Wireless Router:

0.59 W/kg

Shopping information

MSRP price:

$ 725

This device is also known as ZTE Z999

RELATED VIDEO

US CARRIER AVAILABILITY

Discontinued

Pros

No Pros

Cons

  • Thick body (0.48 inches)
  • No front-facing camera

Description

Looking at the Axon M as just a regular device, the spec sheet doesn’t look too shabby. SD821, 4 gigs of RAM, and 64GB storage make us feel like we’re dealing with a near-flagship-level device, while the glass and aluminum body further reinforce this feeling. Throw in a 20-megapixel sensor, 4K video recording, and USB-C with Quick-charge 3.0 and we’re feeling pretty good about the Axon M. Of course, then there’s the form-factor. As a clamshell, it’s a narrow device that feels like its packing a little more than most phones, but that’s obviously because it is.
