Samsung Galaxy Note 20

Posted:
May 13, 2020
Status:
Not announced
Release date:
unknown

Not official: The information for this phone is preliminary and could be incomplete or inaccurate.

Display

Size:

6.4 inches

Resolution:

3200 x 1440 pixels, 20:9 ratio, 547 PPI

Technology:

Dynamic AMOLED

Features:

HDR video support, Scratch-resistant glass (Corning Gorilla Glass 6), Ambient light sensor, Proximity sensor

Hardware & Performance

System chip:

Qualcomm Snapdragon 865 SM8250

Processor:

Octa-core, 2840 MHz, Kryo 585, 64-bit, 7 nm

GPU:

Adreno 650

RAM:

12GB LPDDR5

Internal storage:

128GB

Storage expansion:

microSDXC up to 1000 GB

OS:

Android (10), Samsung One UI

Battery

Capacity:

4000 mAh

Type:

Li - Polymer, Not user replaceable

Charging:

Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging, Reverse wireless charging

Camera

Rear:

Quad camera

Main camera:

108 MP (OIS, PDAF)

Specifications:

Aperture size: F1.8; Focal length: 26 mm

Second camera:

48 MP (Telephoto, OIS, PDAF)

Specifications:

Aperture size: F3.5; Focal Length: 102 mm; Sensor size: 1/2"; Pixel size: 0.8 μm

Third camera:

12 MP (Ultra-wide, Autofocus)

Specifications:

Aperture size: F2.2; Focal Length: 13 mm; Pixel size: 1.4 μm

Fourth camera:

0.3 MP VGA (ToF 3D depth sensing)

Video recording:

7680x4320 (8K UHD) (24 fps), 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)

Features:

OIS, HDR, Time-lapse video, EIS

Front:

40 MP (PDAF, HDR)

Design

Materials:

Back: Glass (Corning Gorilla Glass 6); Frame: Aluminum

Resistance:

Water, Dust; IP 68

Biometrics:

2D Face unlock, Ultrasonic in-screen fingerprint

Features:

Stylus

Colors:

Cosmic black, Cosmic grey

Cellular

5G:

n1, n3, n5, n7, n8, n28, n40, n77, n78, SA, NSA, Sub-6, mmWave

LTE (FDD):

Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 32(1500 L-band), 66(AWS-3)

LTE (TDD):

Bands 39(1900+), 40(2300), 41(2600+)

UMTS:

850, 900, 1700/2100, 1900, 2100 MHz

Data Speed:

LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s

SIM type:

Nano SIM

Multimedia

Headphones:

No 3.5mm jack

Features:

32-Bit DAC, Dolby Atmos, aptX, Dolby Digital, Dolby Digital Plus

Connectivity & Features

Bluetooth:

5.0

Wi-Fi:

802.11 a, b, g, n, ac, ax, dual-band; MIMO, Wi-Fi Direct, Hotspot

USB:

Type-C (reversible), USB 3.1

Features:

Charging, Headphones port, OTG

Sensors:

Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer

Other:

NFC, ANT+

This device is also known as Samsung Galaxy Note20

Description

The Samsung Galaxy Note 20 is due to arrive sometime in late summer. Specs-wise, we expect the Snapdragon 865 chipset and an Exynos one to match in all non-US regions accompanied by 12GB of RAM and 4000mAh battery. At the back will be situated the same quad-camera setup from the S20 Ultra. A 6.4-inch AMOLED display with a 60Hz refresh rate should be at the front. S Pen and 5G will come off as standard.
