Apple iPhone 14 Pro Max vs Samsung Galaxy S23 Ultra Specs Comparison

Display

Size
6.7-inch	6.8-inch
Resolution
2796 x 1290 px, 19.5:9 ratio, 460 PPI	3088 x 1440 px, 19.3:9 ratio, 501 PPI
Technology
OLED	Dynamic AMOLED
Refresh rate
Variable 1-120Hz	120Hz
Screen-to-body
88.45 %	89.87 %
Peak brightness
2000 cd/m2 (nit)	1750 cd/m2 (nit)
Features
Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass (Ceramic Shield), Ambient light sensor, Proximity sensor	HDR support, Scratch-resistant glass (Corning Gorilla Glass Victus 2), Ambient light sensor, Proximity sensor

Hardware

System chip
Apple 16 Bionic (4 nm)	Qualcomm Snapdragon 8 Gen 2 SM8550 (4 nm)
Processor
Hexa-core, 2x 3.46GHz Everest + 4x 2.02GHz Sawtooth	Octa-core, 1x 3.36GHz Kryo Prime + 4x 2.8GHz Kryo Gold + 3x 2.0GHz Kryo Silver
GPU
Apple GPU 5-core	Adreno 740
RAM
6GB (LPDDR5)	8GB (LPDDR5X)
Internal storage
128GB, not expandable	256GB (UFS 4.0), not expandable
OS
iOS (18.x, 17.x, 16.x)	Android (14, 13), One UI
Device type
Smartphone	Smartphone

Battery

Capacity
4323 mAh	5000 mAh
Type
Li - Ion, Not user replaceable	Li - Ion, Not user replaceable
Charging
Fast charging, Qi wireless charging, MagSafe wireless charging	Fast charging, Qi wireless charging, Reverse wireless charging
Max charge speed
Wired: 25.0W Wireless: 15.0W	Wired: 45.0W Wireless: 15.0W

PhoneArena Battery Tests

Battery Life Estimate

7h 39min

Browsing

19h 5min

Video

11h 0min

Gaming

8h 39min

Battery Life Estimate

7h 17min

Browsing

18h 57min

Video

8h 54min

Gaming

10h 59min

Find out more details about battery and charging for all phones we have tested on our PhoneArena Battery Score page.

Camera

Rear
Triple camera	Quad camera
Main camera
48 MP (Sensor-shift OIS, PDAF) Specifications: Aperture size: F1.8 Focal length: 24 mm Sensor size: 1/1.28" Pixel size: 2.44 μm	200 MP (OIS, PDAF) Specifications: Aperture size: F1.7 Focal length: 24 mm Sensor size: 1/1.3" Pixel size: 0.6 μm
Second camera
12 MP (Telephoto, OIS, PDAF) Specifications: Optical zoom: 3.0x Aperture size: F2.8 Focal Length: 77 mm Sensor size: 1/3.5" Pixel size: 1.0 μm	10 MP (Telephoto, OIS) Specifications: Optical zoom: 3.0x Aperture size: F2.4 Focal Length: 69 mm Sensor size: 1/3.52" Pixel size: 1.12 μm
Third camera
12 MP (Ultra-wide, PDAF) Specifications: Aperture size: F2.2 Focal Length: 13 mm Pixel size: 1.4 μm	10 MP (Telephoto) Specifications: Optical zoom: 10.0x Aperture size: F4.9 Focal Length: 230 mm Sensor size: 1/3.52" Pixel size: 1.12 μm
Fourth camera
	12 MP (Ultra-wide) Specifications: Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/2.55" Pixel size: 1.4 μm
Flash
Dual LED	LED
Video recording
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (30 fps) Features: OIS, HDR, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode	7680x4320 (8K UHD) (30 fps), 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (960 fps) Features: OIS, HDR
Front
12 MP (Time-of-Flight (ToF), Autofocus, HDR), Video capture: 3840x2160 (4K UHD) (60 fps)	12 MP (PDAF), Video capture: 3840x2160 (4K UHD) (60 fps)

PhoneArena Camera Tests

148

Overall

146


150

Video

147

Overall

150


144

Video

Find out more details about photo and video scores for all phones we have tested on our PhoneArena Camera Score page.

Design

Dimensions
6.33 x 3.05 x 0.31 inches (160.7 x 77.6 x 7.85 mm) thickness with camera 0.474 inches (12.03 mm)	6.43 x 3.07 x 0.35 inches (163.3 x 78 x 8.9 mm) thickness with camera 0.42 inches (10.68 mm)
Weight
8.47 oz(240.0 g)	8.25 oz(234.0 g)
Materials
Back: Glass Frame: Stainless steel	Back: Glass (Corning Gorilla Glass Victus 2) Frame: Aluminum
Resistance
Water, Dust; IP68	Water, Splash, Dust; IP68
Biometrics
3D Face unlock	2D Face unlock, Ultrasonic in-screen fingerprint
Features
	Stylus
Keys
Left: Volume control, Other; Right: Lock/Unlock key	Right: Volume control, Lock/Unlock key
Colors
Space Black, Silver, Gold, Deep Purple	Phantom Black, Cream, Green, Lavender

Cellular

5G
Bands n1, n2, n3, n4, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave	Bands n1, n7, n28, n41, n66, n71, n78, n258, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD)
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)	Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed
LTE-A, HSDPA+ (4G) 42.2 Mbit/s	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
eSIM	Dual Nano SIM + eSIM
HD Voice
Yes
VoLTE
Yes

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Multiple speakers	Earpiece, Multiple speakers
Features
Dolby Atmos
Screen mirroring
Wireless screen share	Wireless screen share
Additional microphone(s)
Noise cancellation	Noise cancellation

Connectivity & Features

Bluetooth
5.3	5.3
Wi-Fi
802.11 a,b,g,n,ac,ax(Wi-Fi 6) Wi-Fi Direct, Hotspot	802.11 a,b,g,n,ac,ax(Wi-Fi 6),Wi-Fi 6E Wi-Fi Direct, Hotspot
USB
Lightning, Features: Charging	Type-C (reversible), USB 3.2, Features: Charging, OTG
Hearing aid compatible
M3/T4	M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, Emergency SOS via satellite (SMS sending/receiving)	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors
Accelerometer, Gyroscope, Compass, Barometer	Accelerometer, Gyroscope, Compass, Barometer
Other
NFC, Ultra Wideband (UWB)	NFC, Ultra Wideband (UWB)

Regulatory Approval

FCC approval
Date approved: Sep 08, 2022 FCC ID value: BCG-E8154A	Date approved: Dec 08, 2023 FCC ID value: A3LSMS918U
Measured SAR
Head: 0.94 W/kg Body: 0.94 W/kg Simultaneous Transmission: 1.50 W/kg Wireless Router: 0.95 W/kg	Head: 1.12 W/kg Body: 0.92 W/kg Simultaneous Transmission: 1.58 W/kg Wireless Router: 1.16 W/kg

Buyers information

MSRP
$ 1099 / € 1479	$ 1200 / € 1300
In The Box
Phone, USB-C to Lightning Cable, Documentation	USB-C cable, SIM Tray ejector, Paperwork

Availability

Officially announced
Sep 07, 2022	Feb 01, 2023

Alternative variants

With 256Gb internal storage

Internal storage	256GB
MSRP	$ 1199

With 12GB RAM

RAM	12GB

With 512GB internal storage

Internal storage	512GB
MSRP	$ 1399

With 12GB RAM and 512GB internal storage

RAM	12GB
Internal storage	512GB
MSRP	$ 1450 / € 1589

With 1TB internal storage

Internal storage	1024GB
MSRP	$ 1599

With 12GB RAM and 1TB internal storage

RAM	12GB
Internal storage	1024GB
MSRP	$ 1649 / € 1749

International

5G	Bands n1, n2, n3, n4, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, SA, NSA, Sub-6
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3)
4G (TDD)	Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 46, 48(3600)
SIM type	Nano SIM, eSIM

International

5G	Bands n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n66, n75, n77, n78, SA, NSA, Sub-6
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 32(1500 L-band), 66(AWS-3)
4G (TDD)	Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
