Samsung Galaxy Note5

Description

The Samsung Galaxy Note5 brings a huge redesign to the Note series: it adopts the glass and metal styling of the Galaxy S6, but in a larger, 5.7" form factor, and it features the signature S Pen stylus. The Note5 sports the 14nm Exynos 7420 octa-core system chip with a whopping 4GB of LPDDR4 RAM. In terms of photography, it sports a 16-megapixel rear cam with OIS, while up front there is a 5-megapixel selfie shooter, and both cameras sport wide, f/1.9 lenses. The battery on the Note 5 is smaller than on the Note4: it's a 3000mAh juicer that is not user removable. The base model of the phone ships with 32GB of internal storage, and there is a costlier, 64GB version, but both lack support for expandable storage.

This device is also known as Samsung SM-920V, Samsung SM-N920A, Samsung SM-920R4, Samsung SM-N920T, Samsung SM-N920I, Samsung SM-N920A, Samsung Note5

Pros

  • Supports wireless charging

Cons

  • 64GB basic storage (not expandable)

Popular Comparisons

The Samsung Galaxy Note5 is most commonly compared with these phones:

Specs Compare

Display

Benchmarks
Size: 5.7 inches
Resolution: 2560 x 1440 pixels, 518 PPI
Technology: Super AMOLED
Screen-to-body: 76.62 %
Features: Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor

Hardware

Benchmarks
System chip: Samsung Exynos 7 Octa 7420
Processor: Octa-core, 2100 MHz, ARM Cortex-A57 and ARM Cortex-A53, 64-bit, 14 nm
GPU: Mali-T760 MP8
RAM: 4GB LPDDR4
Internal storage: 64GB, available to use: 54.1 GB, not expandable
Device type: Smartphone
OS: Android (7.0 Nougat, 6.0 Marshmallow, 5.1 Lollipop), Samsung TouchWiz UI Screenshots

Battery

Benchmarks
Capacity: 3000 mAh
Type: Li - Ion, Not user replaceable
Charging: Qi and Powermat wireless charging

Camera

Benchmarks
Rear: Single camera Camera samples
Main camera: 16 MP (OIS, PDAF, CMOS image sensor, BSI sensor)
Specifications: Aperture size: F1.9; Focal length: 28 mm; Sensor size: 1/2.6"; Pixel size: 1.12 μm
Video recording: 3840x2160 (4K UHD) (30 fps), 2560x1440 (QHD), 1920x1080 (Full HD) (60 fps), 1280x720 (HD), 640x480 (VGA)
Features: OIS, Continuous autofocus, Object tracking, EIS, Video calling
Front: 5 MP
Dimensions: 6.03 x 3.00 x 0.30 inches (153.2 x 76.1 x 7.6 mm)
Weight: 6.03 oz (171.0 g)
Materials: Back: Glass; Frame: Metal
Biometrics: Fingerprint (touch)
Features: Stylus, Touch sensitive control keys
Keys: Left: Volume control; Right: Lock/Unlock key
Colors: Black sapphire, Gold platinum, Silver titan, White pearl

Cellular

LTE (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 17(700 b), 18(800 Lower), 19(800 Upper), 26(850+), 28(700 APT)
LTE (TDD): Bands 40(2300)
UMTS: 850, 900, 1900, 2100 MHz
Data Speed: LTE-A Cat 9 (450/50 Mbit/s), HSPA, HSUPA, UMTS
SIM type: Nano SIM

Multimedia

Benchmarks
Headphones: 3.5mm jack
Speakers: Earpiece, Loudspeaker
Features: Album art cover, Background playback
Screen mirroring: Wireless screen share

Connectivity & Features

Bluetooth: 4.2
Wi-Fi: 802.11 a, b, g, n, ac, dual-band; MIMO, Wi-Fi Direct, Hotspot
USB: microUSB, USB 2.0
Features: Charging, Mass storage device
Location: GPS, A-GPS, Glonass, BeiDou
Sensors: Accelerometer, Gyroscope, Compass, Hall (for flip covers), Gesture, Barometer
Other: NFC, ANT+, Tethering, Computer sync, OTA sync

Regulatory Approval

FCC approval:
Date approved: Jul 15, 2015
FCC ID value: A3LSMN920A link
Measured SAR:
Head: 0.22 W/kg
Body: 0.76 W/kg
Simultaneous Transmission: 1.27 W/kg
Wireless Router: 0.98 W/kg

Availability

Officially announced: Aug 13, 2015
Despite our efforts to provide full and correct Samsung Galaxy Note5 specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Samsung Galaxy Note5

SM-N920R4 for US Cellular

Differences from the main variant:
LTE (FDD): Bands 2(1900), 4(AWS-1), 5(850), 12(700 a), 13(700 c), 17(700 b), 25(1900+)
Hearing aid compatible: M4, T3
FCC approval:
Date approved: Jul 16, 2015
FCC ID value: A3LSMN920R4 link
Measured SAR:
Head: 0.21 W/kg
Body: 0.70 W/kg
Simultaneous Transmission: 1.46 W/kg
Wireless Router: 1.08 W/kg

Samsung Galaxy Note5

SM-N920T for T-Mobile

Differences from the main variant:
LTE (FDD): Bands 2(1900), 4(AWS-1), 12(700 a), 20(800 DD)
UMTS: 850, 1700/2100, 1900, 2100 MHz
VoLTE: Yes
Hearing aid compatible: M4, T3
FCC approval:
Date approved: Jul 16, 2015
FCC ID value: A3LSMN920T link
Measured SAR:
Head: 0.28 W/kg
Body: 1.07 W/kg
Simultaneous Transmission: 1.38 W/kg
Wireless Router: 1.09 W/kg

Samsung Galaxy Note5

SM-N920I International version

Differences from the main variant:
FCC approval:
Date approved: Jul 15, 2015
FCC ID value: A3LSMN920I link
Measured SAR:
Head: 0.23 W/kg
Body: 1.09 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 1.09 W/kg

Samsung Galaxy Note5

SM-920V for Verizon Wireless

Differences from the main variant:
LTE (FDD): Bands 2(1900), 3(1800), 4(AWS-1), 7(2600), 13(700 c)
HD Voice: Yes
VoLTE: Yes
Hearing aid compatible: M4, T3
FCC approval:
Date approved: Jul 15, 2015
FCC ID value: A3LSMN920V link
Measured SAR:
Head: 0.21 W/kg
Body: 0.70 W/kg
Simultaneous Transmission: 1.48 W/kg
Wireless Router: 1.10 W/kg

Samsung Galaxy Note5

with 32 GB storage

Differences from the main variant:
Internal storage: 32GB

Samsung Galaxy Note5 Duos

Differences from the main variant:
Dual SIM: Yes
