Apple iPhone 7 Plus

Full Specifications

Released · Sep 16, 2016

5.5-inch · 1920x1080px

This device is also known as Apple A1784, Apple A1661

9.3

Read Apple iPhone 7 Plus Review

9.1

Read All User Reviews (14)

I want it 33 users

I have it 74 users

I had it 86 users

Popular Comparisons

The Apple iPhone 7 Plus is most commonly compared with these phones:

Availability
Officially announced	Sep 07, 2016
Prices (MSRP)	$969
This device has different variants: View all

Design
Dimensions	6.23 x 3.07 x 0.29 inches 158.2 x 77.9 x 7.3 mm
Weight	6.63 oz (188.0 g)
Materials	Back: Aluminum
Resistance	Water, Dust; IP67
Biometrics	Fingerprint (touch)
Keys	Left: Volume control; Right: Lock/Unlock key
Colors	Black, Gold, Silver, Red, Rose gold, Jet black

Display
Size	5.5-inch, 67.58% screen-to-body
Type	IPS LCD, 625 nits
Resolution	1920x1080px, 16:9 ratio, 401 PPI
Features	Pressure-sensitive, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	2 (Good)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Apple A10 Fusion APL1W24 (16 nm)
Processor	Quad-core 2340 MHz
GPU	PowerVR 7XT GT7600 Plus
Memory	3GB (LPDDR4)/256GB 3GB/32GB 3GB/128GB
Storage expansion	not expandable
OS	iOS (15.x, 14.x, 13.x, 12.x, 11.x, 10.x)
This device has different variants: View all

Battery
Type	2900 mAh, Li - Ion

Camera
Rear	Dual camera
Main camera	12 MP (Sapphire crystal lens cover, OIS, PDAF, BSI sensor) Aperture size: F1.8 Focal length: 28 mm Sensor size: 1/3" Pixel size: 1.22 μm
Second camera	12 MP (Telephoto, Sapphire crystal lens cover, Autofocus) Optical zoom: 2.0x Aperture size: F2.8 Focal Length: 56 mm Sensor size: 1/3.6" Pixel size: 1 μm
Flash	Quad LED
Video recording	4K UHD (30 fps), 1080p (120 fps), 720p (240 fps) OIS, Time-lapse video, Continuous autofocus, Video calling, Video sharing
Front	7 MP (HDR) Video capture: 1080p

Connectivity & Features
Bluetooth	4.2
WLAN	a,b,g,n,ac,dual-band MIMO, Hotspot 802.11 a, b, g, n, ac
USB	Lightning
Sensors	Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor
Location	GPS, A-GPS, Glonass, Cell ID, Wi-Fi positioning
Other	NFC, UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync

Multimedia
Headphones	No 3.5mm jack
Speakers	Earpiece, Multiple speakers
Features	Album art cover, Background playback

Cellular
4G (FDD) Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 29, 30
4G (TDD) Bands	38, 39, 40, 41
3G Bands	2, 4, 5, 8
Data Speed	LTE-A Cat 12 (600/100 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type	Nano SIM
VoLTE	Yes
This device has different variants: View all

Regulatory Approval
FCC approval	Date approved: Sep 07, 2016 FCC ID value: BCG-E3087A
Measured SAR	Head: 1.09 W/kg Body: 1.10 W/kg Simultaneous Transmission: 1.52 W/kg Wireless Router: 1.13 W/kg

Alternative variants

with 32 GB storage

Differences from the main variant:
Memory	32GB
Prices (MSRP)	$769

with 128 GB storage

Differences from the main variant:
Memory	128GB
Prices (MSRP)	$869

for Sprint, Boost Mobile and MetroPCS

Differences from the main variant:
3G Bands	5, 8, 4, 2, 1

Despite our efforts to provide full and correct Apple iPhone 7 Plus specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.
