Apple iPhone 17 vs Apple iPhone 16e Specs Comparison

Design

Dimensions
	5.78x2.81x0.31 inches (~0.33 inches with camera bump) 146.7 x 71.5 x 7.8 mm (~8.3 mm with camera bump)
Weight
	5.89 oz (167.0 g)
Materials
Back: Glass Frame: Aluminum	Back: Glass Frame: Aluminum
Resistance
Water, Dust; IP68	Water, Dust; IP68
Biometrics
3D Face unlock	3D Face unlock
Keys
Left: Volume control, Other; Right: Lock/Unlock key, Other	Left: Volume control, Other; Right: Lock/Unlock key
Colors
	White, Black

Display

Size
6.1-inch	6.1-inch
Resolution
2556x1179px, 19.5:9 ratio, 461 PPI	2532x1170px, 19.5:9 ratio, 457 PPI
Technology
OLED	OLED
Refresh rate
60Hz	60Hz
Screen-to-body
	87.24 %
Peak brightness
2000 cd/m2 (nit)	1200 cd/m2 (nit)
Features
Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass (Ceramic Shield), Ambient light sensor, Proximity sensor	Super Retina XDR, Oleophobic coating, Scratch-resistant glass (Ceramic Shield)

Hardware

System chip
(3 nm)	Apple A18 (3 nm)
Processor
Hexa-core	Hexa-core 2x 4.04GHz + 4x 2.20GHz
GPU
Yes	Apple 4-core GPU
RAM
8GB (LPDDR5)	8GB (LPDDR5)
Internal storage
128GB	128GB (NVMe)
Storage expansion
not expandable	not expandable
OS
iOS (18.x)	iOS (18.x)

Battery

Capacity
	4005 mAh
Type
Li - Ion, Not user replaceable	Li - Ion, Not user replaceable
Charging
Fast charging, Qi2 wireless charging, Reverse wired charging, MagSafe wireless charging	Fast charging, Qi wireless charging
Charge speed
	Wired: 20.0W Wireless: 7.5W

PhoneArena Battery Tests

Battery Life Estimate

Untested

Browsing

Untested

Video

Untested

Gaming

Untested

Battery Life Estimate

6h 4min

Browsing

17h 27min

Video

6h 59min

Gaming

7h 45min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Dual camera	Single camera
Main camera
48 MP (Sensor-shift OIS, PDAF)	48 MP (OIS, Autofocus) Aperture size: F1.6 Focal length: 26 mm
Second camera
12 MP (Ultra-wide, PDAF)
Flash
Dual LED	LED
Video recording
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps) OIS, HDR, Dolby Vision HDR, Cinematic mode	3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps) OIS, Continuous autofocus, Picture-taking during video recording, Cinematic mode
Front
12 MP (Time-of-Flight (ToF), Autofocus, HDR), Video capture: 3840x2160 (4K UHD) (60 fps)	12 MP (Time-of-Flight (ToF), Autofocus, Autofocus), Video capture: 3840x2160 (4K UHD) (60 fps)

PhoneArena Camera Tests

N/A

Overall

N/A


N/A

Video

118

Overall

128


107

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.3	5.3
Wi-Fi
802.11 a,b,g,n,ac,ax(Wi-Fi 6),Wi-Fi 6E,Wi-Fi 7 Wi-Fi Direct, Hotspot	802.11 a,b,g,n,ac,ax(Wi-Fi 6) MIMO, Wi-Fi Direct, Hotspot
USB
Type-C (reversible), USB 2.0, Features: Charging	Type-C (reversible), USB 2.0, Features: Charging
Hearing aid compatible
M3/T4	M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning	GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, NavIC, Cell ID, Wi-Fi positioning
Sensors
Accelerometer, Gyroscope, Compass, Barometer, Emergency SOS via satellite (SMS sending/receiving)	Accelerometer, Gyroscope, Compass, Barometer
Other
NFC, Ultra Wideband (UWB)	NFC, Ultra Wideband (UWB)

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Multiple speakers	Earpiece, Multiple speakers
Features
Dolby Atmos
Screen mirroring
Wireless screen share	Wireless screen share
Additional microphone(s)
Noise cancellation	Noise cancellation

Cellular

5G
Bands 5G Ready	Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n53, n66, n70, n71, n75, n76, n77, n78, n79, SA, NSA, Sub-6
4G (FDD)
	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD)
	Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 48(3600), 53
3G
	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed
LTE-A, HSDPA+ (4G) 42.2 Mbit/s	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
eSIM	eSIM
HD Voice
Yes	Yes
VoLTE
Yes	Yes

Regulatory Approval

FCC approval
	Date approved: Feb 19, 2025 FCC ID value: BCG-E8725A
Measured SAR
	Head: 1.20 W/kg Body: 1.20 W/kg Simultaneous Transmission: 1.55 W/kg

Buyers information

MSRP
	$ 600 / € 699
In The Box
	USB-C Charge Cable (1 m), Documentation

Availability

Officially announced
	Feb 19, 2025
Expected Announcement
September2025

Alternative variants

With 256GB internal storage

Internal storage	256GB
MSRP	$ 699 / € 829

With 512GB internal storage

Internal storage	512GB
MSRP	$ 899 / € 1079

International

5G	Bands n1, n2, n3, n5, n7, n8, n12, n20, n25, n26, n28, n30, n38, n40, n41, n48, n53, n66, n70, n75, n76, n77, n78, n79, SA, NSA, Sub-6
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3)
4G (TDD)	Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 48(3600), 53
SIM type	Nano SIM, eSIM

Links

Full specifications
Apple iPhone 17 Specs	Apple iPhone 16e Specs
PhoneArena Review
	Apple iPhone 16e Review
