Asus ZenFone 3 Max

Full Specifications

This device is also known as Asus ZC520TL

Be the first to review this phone

I want it 1 user

I have it 1 user

I had it 2 users

Popular Comparisons

The Asus ZenFone 3 Max is most commonly compared with these phones:

Design
Dimensions	5.89 x 2.90 x 0.34 inches 149.5 x 73.7 x 8.55 mm
Weight	5.22 oz (148.0 g)
Biometrics	Fingerprint (touch)
Keys	Right: Volume control, Lock/Unlock key
Colors	Gold, Gray

Display
Size	5.2-inch
Resolution	1280x720px, 282 PPI
Technology	IPS LCD
Screen-to-body	67.64 %
Colors	16 777 216
Peak brightness	400 cd/m2 (nit)
Features	Ambient light sensor, Proximity sensor

Hardware
System chip	MediaTek
Processor	Quad-core
GPU	Mali-T720
RAM	3GB
Internal storage	32GB
Storage expansion	microSDXC up to 128 GB
OS	Android (7.0 Nougat, 6.0 Marshmallow), ASUS Zen UI
This device has different variants: View all

Battery
Capacity	4130 mAh
Type	Li - Ion

Camera
Rear	Single camera
Main camera	13 MP (Autofocus) Aperture size: F2.2
Flash	LED
Video recording	Yes Time-lapse video, Picture-taking during video recording, Video calling, Video sharing
Front	5 MP (HDR)

Connectivity & Features
Bluetooth	4.0, Yes
Wi-Fi	802.11 b,g,n
USB	microUSB, USB 2.0
Location	GPS, A-GPS
Sensors	Accelerometer, Compass
Other	Tethering, Computer sync, OTA sync

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Features	Album art cover, Background playback
Radio	FM

Cellular
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 17(700 b)
3G	Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Data Speed	LTE Cat 4 (150/50 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM	Yes
SIM type	Nano SIM, Micro SIM

Phone Features
Notifications	Haptic feedback
Other features	Voice dialing, Voice commands, Voice recording

Despite our efforts to provide full and correct Asus ZenFone 3 Max specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Differences from the main variant:
RAM	2GB
Internal storage	16GB
