Sony Ericsson Xperia ray

Sony Ericsson Xperia ray
Follow Following

More Photos (26)

Bookmark
Posted: 22 Jun 2011 Announced: 22 Jun 2011
Market Status: Released
Release date: 01 Sep 2011
Do you ...?
Want it48 Have it32 Had it4
Links: Sony Ericsson Xperia ray manual Sony Ericsson Xperia ray Official Page Sony Ericsson Xperia ray Preview Sony Ericsson Xperia ray Review

Sony Ericsson Xperia ray has a whiff of the Xperia arc, since it is pretty thin, at 0.37" (9.4mm), and very light at 3.53oz (100g), and also sports the same 8MP Exmor R camera sensor with a 1GHz Qualcomm chipset.

Rating

Excellent 8.5 out of 10

Excellent

9.4 out of 10

Show Full Specs Compare

Sony Ericsson Xperia ray specifications

also known as Sony Ericsson Azusa, Sony Ericsson Urushi, Sony Ericsson ST18i

Pros

Thin body, measuring less than 9.5mm/0.37inches (0.37 inches)
Small dimensions (4.37 x 2.09 x 0.37 inches)
High pixel densitiy screen, over 250ppi (297 ppi)
Fast processor (1000 MHz)
High-resolution camera (8.1 megapixels)

Cons

No cons

Design

Device type:
- Smart phone
OS:
- Android (4.0, 2.3)
Form factor:
Form factor - Refers to the form factor of a phone. The main handset designs are bar, clamshell, slide, swivel
- Candybar
Dimensions:
- 4.37 x 2.09 x 0.37 (111 x 53 x 9.4 mm)
Weight:
- 3.53 oz (100 g)
  the average is 4.2 oz (120 g)

Display

Physical size:
- 3.30 inches
Resolution:
- 480 x 854 pixels
Pixel density:
Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.
- 297 ppi
Technology:
Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.
- TFT
Colors:
Colors - Shows the number of colors that the display supports
- 16 777 216
Touchscreen:
- - Capacitive, Multi-touch
Features:
- Light sensor, Proximity sensor, Scratch-resistant glass

Battery

Talk time:
Talk time - Maximum talk time in hours
- 6.50 hours
  the average is 8 h (496 min)
Stand-by time:
- 17.9 days (430 hours)
  the average is 21 days (498 h)
Talk time (3G):
- 7.00 hours
Stand-by time (3G):
- 18.3 days (440 hours)
Capacity:
- 1500 mAh

Hardware

Processor:
Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.
- Single core, 1000 MHz
System memory:
System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.
- 512 MB RAM
Built-in storage:
- 300 MB
Storage expansion:
- Slot Type:
  - microSD, microSDHC
- Maximum card size:
  Maximum card size - Shows the capacity of the memory expansion slot that can be added
  - 32 GB

Camera

Camera:
- - 8.1 megapixels
- Flash:
  - LED
- Features:
  - Back-illuminated sensor (BSI), Auto focus, Image stabilizer, Video stabilizer, Face detection, Smile detection, Digital zoom, Geo tagging, Scenes, Self-timer
Camcorder:
- - 1280x720 (720p HD) (30 fps)
- Features:
  - Video light, Continuous autofocus in a video, Video calling
Front-facing camera:
- 0.3 megapixels VGA

Multimedia

Music player:
- Features:
  - Music recognition
Radio:
- - FM, Stereo, RDS
YouTube player:
- Yes

Internet browsing

Browser:
- - Yes
- Supports:
  - HTML, Flash
Built-in online services support:
- Facebook, Twitter

Technology

GSM:
GSM - Global System for Mobile communications. A world standard for digital cellular communications using narrowband TDMA (Time Division Multiple Access), which allows up to eight calls at a time on 800 MHz and 1800 MHz frequencies. Introduced in 1991. Is the standard most commonly used in Europe and Asia, but not in the United States. GSM phones use a Subscriber Identity Module (SIM) smart card that contains user account information. Any GSM phone becomes immediately programmed after plugging in the SIM card, thus allowing GSM phones to be easily rented or borrowed.
- 850, 900, 1800, 1900 MHz
UMTS:
UMTS - Universal Mobile Telecommunications Service, also called WCDMA, is a 3G (Third Generation) packet-based transmission of text, digitized voice, video, and multimedia at data rates up to 2 Mbps. It is based on GSM standard and is supported by major standards bodies and manufacturers
- 900, 2100 MHz
Data:
Data - Shows the particular phone's type of data. the major mobile phone data types are GPRS, CDMA2000 1xRTT, EDGE, CDMA2000 1xEV-DO, UMTS, etc.
- HSDPA 7.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS, EDGE
Positioning:
Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.
- A-GPS, Glonass
Navigation:
- Points of interest (POI), Turn-by-turn navigation, Voice navigation

Phone features

Phonebook:
- Unlimited entries, Caller groups, Multiple numbers per contact, Search by both first and last name, Picture ID, Ring ID
Organizer:
- Calendar, Alarm, Document viewer, Calculator, Barcode reader
Messaging:
- SMS, MMS, Threaded view, Predictive text input
E-mail:
- - Yes

Connectivity

Bluetooth:
- - Yes
Wi-Fi:
Wi-Fi - Wireless Local Area Network (WLAN) - used radio waves (RF) or infrared signals to send and receive data over the air. Most popular WLAN solutions today is Wi-Fi (802.11b and 802.11g) standards. 801.11b provides data speeds of around 11mbps while 802.11g can go up to 54 mbps.
- - Yes
- Mobile hotspot:
  - Yes
USB:
- - USB 2.0
- Connector:
  - microUSB
- Features:
  Features - Universal Serial Bus - is a plug-and-play interface for connection a computer and add-on devices such as joysticks, keyboards, wireless phones, scanner, cameras etc. USB supports hot-swap (ability to add a new device without having to reboot the computer). USB supports data speed of 12 megabits per second.
  - Mass storage device, USB charging
- DLNA, Tethering, Computer sync, OTA sync

Other features

Notifications:
- Haptic feedback, Music ringtones (MP3, AAC), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
Sensors:
- - Accelerometer
- Voice dialing, Voice recording

Availability

Officially announced:
- 22 Jun 2011

Shopping information

Accessories:
- Stereo portable handsfree, 4GB microSD memory card, Charger, microUSB cable for charging, Synchronisation and file transfer, User documentation

Alternative variants

We list only the specs that are different than the main variant

Sony Ericsson Xperia ray

Technology

UMTS:
UMTS - Universal Mobile Telecommunications Service, also called WCDMA, is a 3G (Third Generation) packet-based transmission of text, digitized voice, video, and multimedia at data rates up to 2 Mbps. It is based on GSM standard and is supported by major standards bodies and manufacturers
- 850, 1900, 2100 MHz

To see the full specifications with in-depth details click here.

Despite our efforts to provide full and correct Sony Ericsson Xperia ray specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.
