Samsung Galaxy Z Flip 5 vs Samsung Galaxy Z Fold 5 Specs Comparison

Availability

Officially announced
Jul 26, 2023	Jul 26, 2023
Prices (MSRP)
$999	$1799

Design

Dimensions
6.50 x 2.83 x 0.27 inches 165.1 x 71.9 x 6.9 mm	6.10 x 5.11 x 0.24 inches 154.9 x 129.9 x 6.1 mm
Folded
(85.1 x 71.9 x 15.1 mm)	6.10 x2.64 x0.52 inches (154.9 x 67.1 x 13.4 mm)
Weight
6.60 oz (187.0 g)	8.92 oz (253.0 g)
Materials
Back: Glass (Corning Gorilla Glass Victus 2) Frame: Aluminum	Back: Glass (Corning Gorilla Glass Victus 2) Frame: Aluminum
Resistance
Yes; IPX8	Water; IPX8
Biometrics
Fingerprint (touch)	Fingerprint (touch)
Keys
	Right: Volume control, Lock/Unlock key
Colors
Mint, Graphite, Cream, Lavender, Gray, Blue, Green, Yellow	Icy Blue, Phantom Black, Cream, Gray, Blue

Display

Size
6.7-inch, 85.70% screen-to-body	7.6-inch, 91.12% screen-to-body
Type
Dynamic AMOLED, 120Hz, HDR	Dynamic AMOLED, 120Hz, HDR, 1750 nits
Resolution
2640x1080px, 22:9 ratio, 426 PPI	2176x1812px, 21.6:18 ratio, 373 PPI
Features
	Folding inside the device, HDR support, Ambient light sensor, Proximity sensor
Front cover display
3.4 inches 720 x748 px Super AMOLED Scratch-resistant glass (Corning Gorilla Glass Victus 2)	6.2 inches 2316 x904 px Dynamic AMOLED 120Hz refresh rate, Scratch-resistant glass (Corning Gorilla Glass Victus 2), Ambient light sensor, Proximity senso

Hardware

System chip
Snapdragon 8 Gen 2 SM8550-AC (4 nm)	Snapdragon 8 Gen 2 SM8550-AC (4 nm)
Processor
Octa-core 1x3.36GHz Cortex-X3 2x2.8GH​z Cortex-A715 2x2.8​GHz Cortex-A710 3x2.0​GHz Cortex-A510	Octa-core 1x3.36GHz Cortex-X3 2x2.8GH​z Cortex-A715 2x2.8​GHz Cortex-A710 3x2.0​GHz Cortex-A510
GPU
Adreno 740	Adreno 740
Memory
8GB/256GB 8GB/512GB	12GB (LPDDR5X)/256GB (UFS 4.0) 12GB/512GB 12GB/1024GB
Storage expansion
not expandable	not expandable
OS
Android (13)	Android (14, 13)

Battery

Type
3700 mAh	4400 mAh, Li - Polymer
Charging
Fast charging Qi wireless charging, Reverse wireless charging	Fast charging Qi wireless charging, Reverse wireless charging
Charge speed
Wired: 25.0W Wireless: 10.0W	Wired: 25.0W Wireless: 15.0W

PhoneArena Battery Tests

Battery Life Estimate

5h 11min

Browsing

12h 21min

Video

7h 13min

Gaming

7h 23min

Battery Life Estimate

4h 41min

Browsing

9h 22min

Video

6h 30min

Gaming

9h 27min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Dual camera	Triple camera
Main camera
12 MP (OIS, PDAF) Aperture size: F1.8 Focal length: 24 mm Pixel size: 1.8 μm	50 MP (OIS, PDAF) Aperture size: F1.8 Focal length: 23 mm Sensor size: 1/1.56" Pixel size: 1.0 μm
Second camera
12 MP (Ultra-wide) Aperture size: F2.2 Pixel size: 1.12 μm	12 MP (Ultra-wide) Aperture size: F2.2 Focal Length: 12 mm Sensor size: 1/3.06" Pixel size: 1.12 μm
Third camera
	10 MP (Telephoto) Aperture size: F2.4 Focal Length: 66 mm Sensor size: 1/3.94" Pixel size: 1.0 μm
Flash
LED	LED
Video recording
Yes	8K UHD (30 fps), 4K UHD (60 fps)
Front
10 MP	4 MP (Under-screen) Folded: 10 MP

PhoneArena Camera Tests

136

Overall

137


135

Video

140

Overall

144


135

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.3	5.3
WLAN
a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax	a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Type-C	Type-C
Sensors
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer, Ambient light sensor, Proximity sensor
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Other
NFC	NFC

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Loudspeaker	Earpiece, Multiple speakers
Screen mirroring
Wireless screen share
Additional microphone(s)
Noise cancellation

Cellular

5G Bands
5G Ready	n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n29, n30, n40, n41, n66, n78, 5G Ready
4G (FDD) Bands
	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 66
4G (TDD) Bands
	38, 39, 40, 41
3G Bands
	1, 2, 4, 5, 8
Data Speed
LTE-A, HSDPA+ (4G) 42.2 Mbit/s	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
Nano SIM, eSIM	Dual Nano SIM + eSIM

Regulatory Approval

FCC approval
Date approved: Jul 13, 2023 FCC ID value: A3LSMF731U	Date approved: Jun 26, 2023 FCC ID value: A3LSMF946U
Measured SAR
Head: 1.16 W/kg Body: 0.43 W/kg Simultaneous Transmission: 1.56 W/kg Wireless Router: 1.13 W/kg	Head: 1.16 W/kg Body: 1.07 W/kg Simultaneous Transmission: 1.57 W/kg

Alternative variants

With 512GB internal storage

Memory	512GB

With 512GB internal storage

Memory	512GB

With 1TB internal storage

Memory	1024GB
