Display
Size:
6.8 inches
6.7 inches
Resolution:
3168 x 1440 pixels, 19.8:9 ratio, 513 PPI
3216 x 1440 pixels, 20.1:9 ratio, 526 PPI
Technology:
AMOLED
AMOLED
Refresh rate:
120Hz
120Hz
Screen-to-body:
90.79 %
89.79 %
Peak brightness:
1300 cd/m2 (nit)
Features:
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
HDR support, Scratch-resistant glass (Corning Gorilla Glass), Ambient light sensor, Proximity sensor
Hardware
System chip:
Qualcomm Snapdragon 865 SM8250 (7 nm)
Qualcomm Snapdragon 888 (5 nm)
Processor:
Octa-core, 2840 MHz, Kryo 585, 64-bit
Octa-core, 2840 MHz, Kryo 680, 64-bit
GPU:
Adreno 650
Adreno 660
RAM:
8GB LPDDR5
8GB LPDDR5
Internal storage:
128GB (UFS 3.0), not expandable
128GB (UFS 3.1), not expandable
Device type:
Smartphone
Smartphone
OS:
Android (11, 10), Oxygen OS UI
Android (11), OxygenOS UI
Battery
Capacity:
4510 mAh
4500 mAh
Type:
Li - Polymer, Not user replaceable
Not user replaceable
Charging:
OnePlus Warp Charge, Qi wireless charging, Reverse wireless charging
OnePlus Warp Charge, Qi wireless charging
Max charge speed:
Wired: 30.0W; Wireless: 30.0W
Wired: 65.0W; Wireless: 50.0W
Camera
Rear:
Quad camera
Quad camera
Main camera:
48 MP (OIS, Laser and PDAF)
48 MP (OIS, PDAF)
Specifications:
Aperture size: F1.8; Focal length: 25 mm; Sensor size: 1/1.4"; Pixel size: 1.12 μm
Aperture size: F1.8; Focal length: 23 mm; Sensor size: 1/1.4"; Pixel size: 1.12 μm
Second camera:
8 MP (Telephoto, OIS, Laser and PDAF)
8 MP (Telephoto, OIS, Autofocus)
Specifications:
Optical zoom: 3.0x; Aperture size: F2.4; Sensor size: 1/2"; Pixel size: 1 μm
Optical zoom: 3.3x; Aperture size: F2.4; Focal Length: 77 mm; Pixel size: 1.0 μm
Third camera:
48 MP (Ultra-wide, PDAF)
50 MP (Ultra-wide)
Specifications:
Aperture size: F2.2; Focal Length: 14 mm; Sensor size: 1/2"; Pixel size: 0.8 μm
Aperture size: F2.2; Focal Length: 14 mm; Sensor size: 1/1.56"
Fourth camera:
5 MP (Color filter)
2 MP (Black and White)
Specifications:
Aperture size: F2.4
Video recording:
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (480 fps)
7680x4320 (8K UHD) (30 fps), 3840x2160 (4K UHD) (120 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (480 fps)
Features:
OIS, HDR, EIS
OIS, HDR, Continuous autofocus, EIS
Front:
16 MP (EIS, HDR)
16 MP (EIS)
Video capture:
1920x1080 (Full HD)
Design
Dimensions:
6.51 x 2.93 x 0.33 inches (165.3 x 74.3 x 8.5 mm)
6.43 x 2.90 x 0.34 inches (163.2 x 73.6 x 8.7 mm)
Weight:
7.02 oz (199.0 g)
6.95 oz (197.0 g)
Materials:
Back: Glass (Corning Gorilla Glass 5); Frame: Aluminum
Back: Glass (Corning Gorilla Glass)
Resistance:
Water, Dust; IP68
Biometrics:
2D Face unlock, In-screen fingerprint
2D Face unlock, In-screen fingerprint
Keys:
Left: Volume control; Right: Lock/Unlock key
Left: Volume control; Right: Lock/Unlock key, Other
Colors:
Glacial green
Morning Mist, Forest Green, Stellar Black
Cellular
5G:
n2, n5, n41, n66, n71, SA, NSA
n1, n2, n3, n5, n7, n8, n20, n25, n28, n38, n40, n41, n48, n66, n71, n77, n78, NSA
LTE (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
LTE (TDD):
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
UMTS:
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 6(800), 8(900)
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900), 9(1700), 19(800)
Data Speed:
LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS
Dual SIM:
Yes
SIM type:
Nano SIM
Nano SIM
Multimedia
Headphones:
No 3.5mm jack
No 3.5mm jack
Speakers:
Earpiece, Multiple speakers
Earpiece, Loudspeaker, Multiple speakers
Features:
Dolby Atmos, aptX-HD
Dolby Atmos
Screen mirroring:
DLNA, Wireless screen share
Wireless screen share
Additional microphone(s):
for Noise cancellation
for Noise cancellation
Connectivity & Features
Bluetooth:
5.1
5.2
Wi-Fi:
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
USB:
Type-C (reversible), USB 3.1
Type-C (reversible), USB 3.1
Features:
Charging, Headphones port, OTG
Charging, Headphones port, Mass storage device
Location:
GPS, A-GPS, Glonass, Galileo, BeiDou, Dual-band positioning, Cell ID, Wi-Fi positioning
GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors:
Accelerometer, Gyroscope, Compass
Accelerometer, Gyroscope, Compass
Other:
NFC
NFC
Regulatory Approval
FCC approval:
Date approved:
Oct 12, 2020
Mar 24, 2021
FCC ID value:
2ABZ2-EE007
2ABZ2-EF14A
Measured SAR:
Head:
0.93 W/kg
1.19 W/kg
Body:
0.89 W/kg
0.75 W/kg
Simultaneous Transmission:
1.59 W/kg
1.52 W/kg
Wireless Router:
0.95 W/kg
1.19 W/kg
Buyers information
Price:
$ 899
$ 969
User Manual:
This is the official OnePlus 8 Pro User Guide in English provided from the manufacturer.
In The Box:
Warp Charge 30 Power Adapter, Warp Type-C Cable (Support USB 2.0), Quick Start Guide, Welcome Letter, Safety Information and Warranty Card, LOGO Sticker, Case, Screen Protector, SIM Tray Ejector
Warp Charge 65 Power Adapter, Warp Charge Type-C to Type-C Cable, Quick Start Guide, Welcome Letter, Safety Information and Warranty Card, OnePlus Sticker, SIM Tray Ejector
Availability
Officially announced:
Apr 14, 2020
Mar 23, 2021
