Apple iPhone 16 Pro Max vs OnePlus 13 Specs Comparison

Availability

Officially announced
Sep 09, 2024	Oct 31, 2024
Prices (MSRP)
8GB/256GB - $1199 | €1449	12GB/256GB - $900

Design

Dimensions
6.42 x 3.05 x 0.33 inches (~0.48 inches with camera bump) 163.0 x 77.6 x 8.25 mm (~12.25 mm with camera bump)	6.41 x 3.01 x 0.33 inches 162.9 x 76.5 x 8.5 mm
Weight
8.01 oz / 227.0 g	7.41 oz / 210.0 g
Materials
Back: Glass Frame: Titanium	Back: Glass Frame: Aluminum
Resistance
Water, Dust; IP68	Water, Dust; IP69
Biometrics
3D Face unlock	Ultrasonic in-screen fingerprint
Keys
Left: Volume control, Other; Right: Lock/Unlock key, Other	Right: Volume control, Lock/Unlock key
Colors
Black Titanium, White Titanium, Natural Titanium, Desert Titanium	Black, Blue, White

Display

Size
6.9-inch, 92.35% screen-to-body	6.8-inch, 90.88% screen-to-body
Type
OLED, Variable 1-120Hz, HDR, 2000 nits	AMOLED, 120Hz, 4500 nits
Resolution
2868x1320px, 19.5:9 ratio, 458 PPI	3168x1440px, 20:9 ratio, 510 PPI
Protection
Ceramic Shield	Corning Gorilla Glass Victus 2
Features
Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor

PhoneArena Display Test

Bright Max (20% APL)
2088 (Excellent)	2326 (Excellent)
Bright Min
0.93 (Excellent)	1.8 (Good)

Learn more on our PhoneArena Display Test Results page.

Hardware

System chip
Apple A18 Pro (3 nm)	Snapdragon 8 Elite SM8750-AB (3 nm)
Processor
Hexa-core 2x4.05GHz 4x2.42G​Hz	Octa-core 2x4.32GHz Oryon V2 PhoenixL 6x3.53GH​z Oryon V2 PhoenixM
GPU
Apple 6-core GPU	Adreno 830
Memory
8GB (LPDDR5)/256GB (NVMe) 8GB/512GB 8GB/1024GB	12GB (LPDDR5X)/256GB (UFS 4.0) 12GB/512GB 16GB/512GB 24GB/1024GB
Storage expansion
not expandable	not expandable
OS
iOS (18.x)	Android (15)

PhoneArena Performance Test

GeekBench 6 Single
3331	2967
GeekBench 6 Multi
8106	9081
3D Mark High
4567	6330
3D Mark Low
3009	4452

Learn more on our PhoneArena Performance Test Results page.

Battery

Type
4685 mAh, Li - Ion	6000 mAh, Si - Carbon
Charging
Fast charging Qi2 wireless charging, Reverse wired charging, MagSafe wireless charging	Fast charging Qi wireless charging, Reverse wireless charging
Charge speed
Wired: 27.0W Wireless: 25.0W	Wired: 100.0W Wireless: 50.0W

PhoneArena Battery Tests

Battery Life Estimate

8h 30min

Browsing

22h 39min

Video

10h 24min

Gaming

12h 4min

Battery Life Estimate

7h 30min

Browsing

21h 34min

Video

9h 12min

Gaming

8h 12min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Triple camera	Triple camera
Main camera
48 MP (Sensor-shift OIS, PDAF) Sensor name: Sony IMX903 Aperture size: F1.8 Focal length: 24 mm Sensor size: 1/1.28" Pixel size: 1.22 μm	50 MP (OIS, PDAF) Aperture size: F1.6 Focal length: 23 mm Sensor size: 1/1.43" Pixel size: 1.12 μm
Second camera
48 MP (Ultra-wide) Sensor name: Sony IMX972 Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/3.06" Pixel size: 0.7 μm	50 MP (Ultra-wide) Aperture size: F2.0 Focal Length: 15 mm
Third camera
12 MP (Telephoto, Periscope, Sensor-shift OIS, PDAF) Sensor name: Sony IMX913 Optical zoom: 5.0x Aperture size: F2.8 Focal Length: 120 mm Sensor size: 1/3.06" Pixel size: 1.12 μm	50 MP (Telephoto, Periscope, OIS, PDAF) Optical zoom: 3.0x Aperture size: F2.6 Focal Length: 73 mm
Flash
Dual LED	LED
Video recording
4K UHD (120 fps), 1080p (240 fps) OIS, HDR, Continuous autofocus, Picture-taking during video recording, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode	8K UHD (30 fps), 4K UHD (60 fps), 1080p (240 fps)
Front
12 MP (Time-of-Flight (ToF), Autofocus, HDR) Video capture: 4K UHD (60 fps)	32 MP Video capture: 4K UHD (30 fps)

PhoneArena Camera Tests

154

Overall

158


150

Video

145

Overall

149


141

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.3	5.4
WLAN
a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E,Wi-Fi 7 Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax	a,b,g,n,ac,Wi-Fi 6,Wi-Fi 7 Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Type-C, USB 3.2	Type-C, USB 3.2
Sensors
Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Ambient light sensor, Proximity sensor
Hearing aid compatible
M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, NavIC, Cell ID, Wi-Fi positioning, Emergency SOS via satellite (SMS sending/receiving)	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Other
NFC, Ultra Wideband (UWB)	NFC

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Multiple speakers	Earpiece, Multiple speakers
Features
Dolby Atmos

Cellular

5G Bands
n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave	n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n48, n66, n71, n75, n77, n78
4G (FDD) Bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 66, 71	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 71
4G (TDD) Bands
34, 38, 39, 40, 41, 42, 46, 48	38, 39, 40
3G Bands
1, 2, 4, 5, 8
Data Speed
LTE-A Pro Cat 18 (1200/150 Mbit/s)	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
eSIM	eSIM, Dual Nano SIM
HD Voice
Yes
VoLTE
Yes

Regulatory Approval

FCC approval
Date approved: Sep 09, 2024 FCC ID value: BCG-E8684A
Measured SAR
Head: 0.96 W/kg Body: 0.98 W/kg Simultaneous Transmission: 0.99 W/kg

Alternative variants

With 512GB internal storage

Memory	512GB
Prices (MSRP)	$1399

With 512GB internal storage

Memory	512GB

With 1TB internal storage

Memory	1024GB
Prices (MSRP)	$1599

With 16GB RAM and 512GB internal storage

Memory	16GB/512GB

International

5G Bands	n1, n2, n3, n5, n7, n8, n12, n14, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 66, 71
4G (TDD) Bands	34, 38, 39, 40, 41, 42, 48

With 24GB RAM and 1TB internal storage

Memory	24GB/1024GB
