Samsung Galaxy Note 20 Ultra vs Samsung Galaxy S23 Ultra Specs Comparison

Availability

Officially announced
Aug 05, 2020	Feb 01, 2023
Prices (MSRP)
12GB/128GB - $1300 12GB/256GB - €1266 12GB/512GB - $1450	8GB/256GB - $1200 | €1300

Design

Dimensions
6.49 x 3.04 x 0.32 inches 164.8 x 77.2 x 8.1 mm	6.43 x 3.07 x 0.35 inches (~0.42 inches with camera bump) 163.3 x 78 x 8.9 mm (~10.68 mm with camera bump)
Weight
7.34 oz / 208.0 g	8.25 oz / 234.0 g
Materials
Back: Glass (Corning Gorilla Glass Victus) Frame: Stainless steel	Back: Glass (Corning Gorilla Glass Victus 2) Frame: Aluminum
Resistance
Water, Dust; IP68	Water, Splash, Dust; IP68
Biometrics
2D Face unlock, Ultrasonic in-screen fingerprint	2D Face unlock, Ultrasonic in-screen fingerprint
Features
Stylus	Stylus
Keys
Right: Volume control, Lock/Unlock key	Right: Volume control, Lock/Unlock key
Colors
Mystic black, Mystic bronze, Mystic white	Phantom Black, Cream, Green, Lavender

Display

Size
6.9-inch, 91.63% screen-to-body	6.8-inch, 89.87% screen-to-body
Type
Dynamic AMOLED, 120Hz, HDR	Dynamic AMOLED, 120Hz, HDR, 1750 nits
Resolution
3088x1440px, 19.3:9 ratio, 496 PPI	3088x1440px, 19.3:9 ratio, 501 PPI
Protection
Corning Gorilla Glass Victus	Corning Gorilla Glass Victus 2

PhoneArena Display Test

Bright Max (20% APL)
Untested	1598 (Good)
Bright Min
1.6 (Good)	0.8 (Excellent)

Learn more on our PhoneArena Display Test Results page.

Hardware

System chip
Snapdragon 865+ SM8250-AB (7 nm)	Snapdragon 8 Gen 2 SM8550 (4 nm)
Processor
Octa-core 1x3.1GHz Kryo 585 3x2.42GHz Kryo 585 4x1.80GHz Kryo 585	Octa-core 1x3.36GHz Kryo Prime 4x2.8GHz Kryo Gold 3x2.0GHz Kryo Silve
GPU
Adreno 650	Adreno 740
Memory
12GB (LPDDR5)/128GB (UFS 3.0) 12GB/256GB 12GB/512GB	8GB (LPDDR5X)/256GB (UFS 4.0) 12GB/256GB 12GB/512GB 12GB/1024GB
Storage expansion
microSDXC up to 1000 GB	not expandable
OS
Android (13, 12, 11, 10)	Android (14, 13)

PhoneArena Performance Test

GeekBench 6 Single
1208	1971
GeekBench 6 Multi
3047	5115
3D Mark High
1510	3828
3D Mark Low
1097	1951

Learn more on our PhoneArena Performance Test Results page.

Battery

Type
4500 mAh, Li - Polymer	5000 mAh, Li - Ion
Charging
Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging Qi and Powermat wireless charging, Reverse wireless charging	Fast charging Qi wireless charging, Reverse wireless charging
Charge speed
	Wired: 45.0W Wireless: 15.0W

PhoneArena Battery Tests

Battery Life Estimate

4h 37min

Browsing

9h 33min

Video

7h 0min

Gaming

7h 17min

Battery Life Estimate

7h 17min

Browsing

18h 57min

Video

8h 54min

Gaming

10h 59min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Triple camera	Quad camera
Main camera
108 MP (OIS, Laser and PDAF) Aperture size: F1.8 Focal length: 26 mm Sensor size: 1/1.33" Pixel size: 0.8 μm	200 MP (OIS, PDAF) Sensor name: Samsung ISOCELL HP2 Aperture size: F1.7 Focal length: 24 mm Sensor size: 1/1.3" Pixel size: 0.6 μm
Second camera
12 MP (Ultra-wide, Autofocus) Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/2.55" Pixel size: 1.4 μm	12 MP (Ultra-wide) Sensor name: Sony IMX564 Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/2.55" Pixel size: 1.4 μm
Third camera
12 MP (Telephoto, OIS, PDAF) Optical zoom: 5.0x Aperture size: F3.0 Focal Length: 120 mm Pixel size: 1.0 μm	10 MP (Telephoto) Sensor name: Sony IMX754 Optical zoom: 10.0x Aperture size: F4.9 Focal Length: 230 mm Sensor size: 1/3.52" Pixel size: 1.12 μm
Fourth camera
	10 MP (Telephoto, OIS) Sensor name: Sony IMX754 Optical zoom: 3.0x Aperture size: F2.4 Focal Length: 69 mm Sensor size: 1/3.52" Pixel size: 1.12 μm
Flash
LED	LED
Video recording
8K UHD (24 fps), 4K UHD (60 fps), 1080p (240 fps), 720p (960 fps) OIS, HDR, Time-lapse video, Hyperlapse, Object tracking, EIS	8K UHD (30 fps), 4K UHD (60 fps), 1080p (960 fps) OIS, HDR
Front
10 MP (PDAF, HDR) Video capture: 4K UHD	12 MP (PDAF) Video capture: 4K UHD (60 fps)

PhoneArena Camera Tests

N/A

Overall

N/A


N/A

Video

147

Overall

150


144

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.0	5.3
WLAN
Wi-Fi 6 MIMO, Wi-Fi Direct, Hotspot 802.11 ax	a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Type-C, USB 3.2	Type-C, USB 3.2
Sensors
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor
Hearing aid compatible
M3/T3	M3/T4
Location
GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Other
NFC, ANT+	NFC, Ultra Wideband (UWB)

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Multiple speakers	Earpiece, Multiple speakers
Features
32-Bit DAC, Dolby Atmos, aptX, Dolby Digital, Dolby Digital Plus

Cellular

5G Bands
n2, n5, n41, n66, n71, n260, n261, SA, NSA, Sub-6, mmWave	n1, n7, n28, n41, n66, n71, n78, n258, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD) Bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 18, 19, 20, 25, 26, 28, 29, 30, 66, 71	1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 18, 19, 20, 25, 26, 28, 29, 30, 66, 71
4G (TDD) Bands
38, 39, 40, 41, 46, 48	38, 39, 40, 41, 46, 48
3G Bands
1, 2, 4, 5, 8	1, 2, 4, 5, 8
Data Speed
LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
Nano SIM	Dual Nano SIM + eSIM
HD Voice
Yes

Regulatory Approval

FCC approval
Date approved: Jul 06, 2020 FCC ID value: A3LSMN986U	Date approved: Dec 08, 2023 FCC ID value: A3LSMS918U
Measured SAR
Head: 0.78 W/kg Body: 1.04 W/kg Simultaneous Transmission: 1.59 W/kg Wireless Router: 1.18 W/kg Phablet: 3.92 W/kg	Head: 1.12 W/kg Body: 0.92 W/kg Simultaneous Transmission: 1.58 W/kg Wireless Router: 1.16 W/kg

Alternative variants

for Europe

System chip	Samsung Exynos 990 (7 nm)
Processor	Octa-core 2x2.73GHz Exynos M5 2x2.5GHz Cortex-A76 4x2.0 GHz Cortex-A55
GPU	Mali G77 MP11
Memory	256GB
Prices (MSRP)	€1266

With 12GB RAM

Memory	12GB

with 512GB storage

Memory	512GB
Prices (MSRP)	$1450

With 12GB RAM and 512GB internal storage

Memory	12GB/512GB
Prices (MSRP)	$1450 | €1589

for Verizon

5G Bands	n260, n261, mmWave
4G (FDD) Bands	2, 3, 4, 5, 7, 8, 12, 13, 18, 19, 20, 26, 28, 66
4G (TDD) Bands	38, 39, 40, 41, 46

With 12GB RAM and 1TB internal storage

Memory	12GB/1024GB
Prices (MSRP)	$1649 | €1749

International

5G Bands	n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n66, n75, n77, n78, SA, NSA, Sub-6
4G (FDD) Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 66
4G (TDD) Bands	38, 39, 40, 41
