Apple iPhone 14 Pro Max vs Apple iPhone 16 Pro Max Specs Comparison

Compare mobile phone specifications of up to three devices at once. Our specs comparison tool helps you find and compare the perfect phone for your needs.

7.4
Apple iPhone 14 Pro Max
8.0
Apple iPhone 16 Pro Max
Apple iPhone 14 Pro Max Apple iPhone 16 Pro Max
Released · Sep 16, 2022
Released · Sep 20, 2024
6.7-inch · 2796x1290px
6.9-inch · 2868x1320px
Triple camera
Triple camera
6GB · 128GB
8GB · 256GB
4323 mAh
4685 mAh
Check prices Check prices

Design

Dimensions
6.33 x 3.05 x 0.31 inches (~0.474 inches with camera bump)
160.7 x 77.6 x 7.85 mm (~12.03 mm with camera bump)
6.42 x 3.05 x 0.33 inches (~0.48 inches with camera bump)
163.0 x 77.6 x 8.25 mm (~12.25 mm with camera bump)
Weight
8.47 oz (240.0 g) 8.01 oz (227.0 g)
Materials
Back: Glass
Frame: Stainless steel
Back: Glass
Frame: Titanium
Resistance
Water, Dust; IP68 Water, Dust; IP68
Biometrics
3D Face unlock 3D Face unlock
Keys
Left: Volume control, Other; Right: Lock/Unlock key Left: Volume control, Other; Right: Lock/Unlock key, Other
Colors
Space Black, Silver, Gold, Deep Purple Black Titanium, White Titanium, Natural Titanium, Desert Titanium

Display

Size
6.7-inch 6.9-inch
Resolution
2796x1290px, 19.5:9 ratio, 460 PPI 2868x1320px, 19.5:9 ratio, 458 PPI
Technology
OLED OLED
Refresh rate
Variable 1-120Hz Variable 1-120Hz
Screen-to-body
88.45 % 92.35 %
Peak brightness
2000 cd/m2 (nit) 2000 cd/m2 (nit)
Features
Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass (Ceramic Shield), Ambient light sensor, Proximity sensor Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass (Ceramic Shield), Ambient light sensor, Proximity sensor

Hardware

System chip
Apple 16 Bionic (4 nm) Apple A18 Pro (3 nm)
Processor
Hexa-core
2x 3.46GHz Everest + 4x 2.02GHz Sawtooth
Hexa-core
2x 4.05GHz + 4x 2.42GHz
GPU
Apple GPU 5-core Apple 6-core GPU
RAM
6GB (LPDDR5) 8GB (LPDDR5)
Internal storage
128GB (NVMe) 256GB (NVMe)
Storage expansion
not expandable not expandable
OS
iOS (18.x, 17.x, 16.x) iOS (18.x)

Battery

Capacity
4323 mAh 4685 mAh
Type
Li - Ion Li - Ion
Charging
Fast charging, Qi wireless charging, MagSafe wireless charging Fast charging, Qi2 wireless charging, Reverse wired charging, MagSafe wireless charging
Charge speed
Wired: 25.0W
Wireless: 15.0W
Wired: 27.0W
Wireless: 25.0W
PhoneArena Battery Tests
Battery Life Estimate
7h 39min
Browsing
19h 5min
Video
11h 0min
Gaming
8h 39min
Battery Life Estimate
8h 30min
Browsing
22h 39min
Video
10h 24min
Gaming
12h 4min

Camera

Rear
Triple camera Triple camera
Main camera
48 MP (Sensor-shift OIS, PDAF)
Aperture size: F1.8
Focal length: 24 mm
Sensor size: 1/1.28"
Pixel size: 2.44 μm
48 MP (Sensor-shift OIS, PDAF)
Aperture size: F1.8
Focal length: 24 mm
Sensor size: 1/1.28"
Pixel size: 1.22 μm
Second camera
12 MP (Telephoto, OIS, PDAF)
Optical zoom: 3.0x
Aperture size: F2.8
Focal Length: 77 mm
Sensor size: 1/3.5"
Pixel size: 1.0 μm
12 MP (Telephoto, Periscope, Sensor-shift OIS, PDAF)
Optical zoom: 5.0x
Aperture size: F2.8
Focal Length: 120 mm
Sensor size: 1/3.06"
Pixel size: 1.12 μm
Third camera
12 MP (Ultra-wide, PDAF)
Aperture size: F2.2
Focal Length: 13 mm
Pixel size: 1.4 μm
48 MP (Ultra-wide)
Aperture size: F2.2
Focal Length: 13 mm
Sensor size: 1/3.06"
Pixel size: 0.7 μm
Flash
Dual LED Dual LED
Video recording
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (30 fps)
OIS, HDR, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode
3840x2160 (4K UHD) (120 fps), 1920x1080 (Full HD) (240 fps)
OIS, HDR, Continuous autofocus, Picture-taking during video recording, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode
Front
12 MP (Time-of-Flight (ToF), Autofocus, HDR), Video capture: 3840x2160 (4K UHD) (60 fps) 12 MP (Time-of-Flight (ToF), Autofocus, HDR), Video capture: 3840x2160 (4K UHD) (60 fps)
PhoneArena Camera Tests
148
Overall
146
150
Video
154
Overall
158
150
Video

Connectivity & Features

Bluetooth
5.3 5.3
Wi-Fi
802.11 a,b,g,n,ac,ax(Wi-Fi 6)
Wi-Fi Direct, Hotspot
802.11 a,b,g,n,ac,ax(Wi-Fi 6),Wi-Fi 7,Wi-Fi 6E
Wi-Fi Direct, Hotspot
USB
Lightning Type-C, USB 3.2
Hearing aid compatible
M3/T4 M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, Emergency SOS via satellite (SMS sending/receiving) GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, NavIC, Cell ID, Wi-Fi positioning, Emergency SOS via satellite (SMS sending/receiving)
Sensors
Accelerometer, Gyroscope, Compass, Barometer Accelerometer, Gyroscope, Compass, Barometer
Other
NFC, Ultra Wideband (UWB) NFC, Ultra Wideband (UWB)

Multimedia

Headphones
No 3.5mm jack No 3.5mm jack
Speakers
Earpiece, Multiple speakers Earpiece, Multiple speakers
Features
Dolby Atmos Dolby Atmos
Screen mirroring
Wireless screen share Wireless screen share
Additional microphone(s)
Noise cancellation Noise cancellation

Cellular

5G
Bands n1, n2, n3, n4, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD)
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600) Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 46, 48(3600)
3G
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900) Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed
LTE-A, HSDPA+ (4G) 42.2 Mbit/s LTE-A Pro Cat 18 (1200/150 Mbit/s)
SIM type
eSIM eSIM
HD Voice
Yes Yes
VoLTE
Yes Yes

Regulatory Approval

FCC approval
Date approved: Sep 08, 2022
FCC ID value: BCG-E8154A
Date approved: Sep 09, 2024
FCC ID value: BCG-E8684A
Measured SAR
Head: 0.94 W/kg
Body: 0.94 W/kg
Simultaneous Transmission: 1.50 W/kg
Wireless Router: 0.95 W/kg
Head: 0.96 W/kg
Body: 0.98 W/kg
Simultaneous Transmission: 0.99 W/kg

Buyers information

MSRP
$ 1099 / € 1479 $ 1199 / € 1449
In The Box
Phone, USB-C to Lightning Cable, Documentation USB-C Charge Cable (1 m), Documentation

Availability

Officially announced
Sep 07, 2022 Sep 09, 2024

Alternative variants

With 256Gb internal storage
Internal storage 256GB
MSRP $ 1199
With 512GB internal storage
Internal storage 512GB
MSRP $ 1399
With 512GB internal storage
Internal storage 512GB
MSRP $ 1399
With 1TB internal storage
Internal storage 1024GB
MSRP $ 1599
With 1TB internal storage
Internal storage 1024GB
MSRP $ 1599
International
5G Bands n1, n2, n3, n5, n7, n8, n12, n14, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 21(1500 Upper), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD) Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 48(3600)
International
5G Bands n1, n2, n3, n4, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3)
4G (TDD) Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 42(3500), 46, 48(3600)
SIM type Nano SIM, eSIM
