Apple iPhone 14 Pro Max vs Apple iPhone 16 Pro Max Specs Comparison

Compare mobile phone specifications of up to three devices at once. Our specs comparison tool helps you find and compare the perfect phone for your needs.

7.4	8.0
Apple iPhone 14 Pro Max	Apple iPhone 16 Pro Max
Released · Sep 16, 2022	Released · Sep 20, 2024
6.7-inch	6.9-inch
Triple camera	Triple camera
6GB · 128GB	8GB · 256GB
4323 mAh	4685 mAh
Check prices	Check prices

Availability

Officially announced
Sep 07, 2022	Sep 09, 2024
Prices (MSRP)
$1099 \| €1479	$1199 \| €1449

Design

Dimensions
6.33 x 3.05 x 0.31 inches (~0.474 inches with camera bump) 160.7 x 77.6 x 7.85 mm (~12.03 mm with camera bump)	6.42 x 3.05 x 0.33 inches (~0.48 inches with camera bump) 163.0 x 77.6 x 8.25 mm (~12.25 mm with camera bump)
Weight
8.47 oz (240.0 g)	8.01 oz (227.0 g)
Materials
Back: Glass Frame: Stainless steel	Back: Glass Frame: Titanium
Resistance
Water, Dust; IP68	Water, Dust; IP68
Biometrics
3D Face unlock	3D Face unlock
Keys
Left: Volume control, Other; Right: Lock/Unlock key	Left: Volume control, Other; Right: Lock/Unlock key, Other
Colors
Space Black, Silver, Gold, Deep Purple	Black Titanium, White Titanium, Natural Titanium, Desert Titanium

Display

Size
6.7-inch, 88.45% screen-to-body	6.9-inch, 92.35% screen-to-body
Type
OLED, Variable 1-120Hz, HDR, 2000 nits	OLED, Variable 1-120Hz, HDR, 2000 nits
Resolution
2796x1290px, 19.5:9 ratio, 460 PPI	2868x1320px, 19.5:9 ratio, 458 PPI
Protection
Ceramic Shield	Ceramic Shield
Features
Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor	Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor

Hardware

System chip
Apple 16 Bionic (4 nm)	Apple A18 Pro (3 nm)
Processor
Hexa-core 2x3.46GHz Everest 4x2.02GHz Sawtooth	Hexa-core 2x4.05GHz 4x2.42GHz
GPU
Apple GPU 5-core	Apple 6-core GPU
Memory
6GB (LPDDR5)/128GB (NVMe) 6GB/256GB 6GB/512GB 6GB/1024GB	8GB (LPDDR5)/256GB (NVMe) 8GB/512GB 8GB/1024GB
Storage expansion
not expandable	not expandable
OS
iOS (18.x, 17.x, 16.x)	iOS (18.x)

Battery

Type
4323 mAh, Li - Ion	4685 mAh, Li - Ion
Charging
Fast charging Qi wireless charging, MagSafe wireless charging	Fast charging Qi2 wireless charging, Reverse wired charging, MagSafe wireless charging
Charge speed
Wired: 25.0W Wireless: 15.0W	Wired: 27.0W Wireless: 25.0W

Battery Life Estimate

7h 39min

Browsing

19h 5min

Video

11h 0min

Gaming

8h 39min

Battery Life Estimate

8h 30min

Browsing

22h 39min

Video

10h 24min

Gaming

12h 4min

Camera

Rear
Triple camera	Triple camera
Main camera
48 MP (Sensor-shift OIS, PDAF) Aperture size: F1.8 Focal length: 24 mm Sensor size: 1/1.28" Pixel size: 2.44 μm	48 MP (Sensor-shift OIS, PDAF) Sensor name: Sony IMX903 Aperture size: F1.8 Focal length: 24 mm Sensor size: 1/1.28" Pixel size: 1.22 μm
Second camera
12 MP (Telephoto, OIS, PDAF) Optical zoom: 3.0x Aperture size: F2.8 Focal Length: 77 mm Sensor size: 1/3.5" Pixel size: 1.0 μm	48 MP (Ultra-wide) Sensor name: Sony IMX972 Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/3.06" Pixel size: 0.7 μm
Third camera
12 MP (Ultra-wide, PDAF) Aperture size: F2.2 Focal Length: 13 mm Pixel size: 1.4 μm	12 MP (Telephoto, Periscope, Sensor-shift OIS, PDAF) Sensor name: Sony IMX913 Optical zoom: 5.0x Aperture size: F2.8 Focal Length: 120 mm Sensor size: 1/3.06" Pixel size: 1.12 μm
Flash
Dual LED	Dual LED
Video recording
4K UHD (60 fps), 1080p (240 fps), 720p (30 fps) OIS, HDR, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode	4K UHD (120 fps), 1080p (240 fps) OIS, HDR, Continuous autofocus, Picture-taking during video recording, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode
Front
12 MP (Time-of-Flight (ToF), Autofocus, HDR) Video capture: 4K UHD (60 fps)	12 MP (Time-of-Flight (ToF), Autofocus, HDR) Video capture: 4K UHD (60 fps)

148

Overall

146


150

Video

154

Overall

158


150

Video

Connectivity & Features

Bluetooth
5.3	5.3
WLAN
a,b,g,n,ac,Wi-Fi 6 Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax	a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E,Wi-Fi 7 Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Lightning	Type-C, USB 3.2
Sensors
Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor
Hearing aid compatible
M3/T4	M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, Emergency SOS via satellite (SMS sending/receiving)	GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, NavIC, Cell ID, Wi-Fi positioning, Emergency SOS via satellite (SMS sending/receiving)
Other
NFC, Ultra Wideband (UWB)	NFC, Ultra Wideband (UWB)

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Multiple speakers	Earpiece, Multiple speakers
Features
Dolby Atmos	Dolby Atmos
Screen mirroring
Wireless screen share
Additional microphone(s)
Noise cancellation

Cellular

5G Bands
n1, n2, n3, n4, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave	n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD) Bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 30, 32, 66, 71	1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 66, 71
4G (TDD) Bands
34, 38, 39, 40, 41, 46, 48	34, 38, 39, 40, 41, 42, 46, 48
3G Bands
1, 2, 4, 5, 8	1, 2, 4, 5, 8
Data Speed
LTE-A, HSDPA+ (4G) 42.2 Mbit/s	LTE-A Pro Cat 18 (1200/150 Mbit/s)
SIM type
eSIM	eSIM
HD Voice
Yes	Yes
VoLTE
Yes	Yes

Regulatory Approval

FCC approval
Date approved: Sep 08, 2022 FCC ID value: BCG-E8154A	Date approved: Sep 09, 2024 FCC ID value: BCG-E8684A
Measured SAR
Head: 0.94 W/kg Body: 0.94 W/kg Simultaneous Transmission: 1.50 W/kg Wireless Router: 0.95 W/kg	Head: 0.96 W/kg Body: 0.98 W/kg Simultaneous Transmission: 0.99 W/kg

Alternative variants

With 256Gb internal storage


Memory	256GB
Prices (MSRP)	$1199

With 512GB internal storage


Memory	512GB
Prices (MSRP)	$1399

With 512GB internal storage


Memory	512GB
Prices (MSRP)	$1399

With 1TB internal storage


Memory	1024GB
Prices (MSRP)	$1599

With 1TB internal storage


Memory	1024GB
Prices (MSRP)	$1599

International


5G Bands	n1, n2, n3, n5, n7, n8, n12, n14, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 66, 71
4G (TDD) Bands	34, 38, 39, 40, 41, 42, 48

International


5G Bands	n1, n2, n3, n4, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 66
4G (TDD) Bands	34, 38, 39, 40, 41, 42, 46, 48
SIM type	Nano SIM, eSIM
