Apple iPhone 12 Pro Max vs Apple iPhone 14 Pro Max Specs Comparison

Availability

Officially announced
Oct 13, 2020	Sep 07, 2022
Prices (MSRP)
6GB/128GB - $1100	6GB/128GB - $1099 | €1479 6GB/256GB - $1199 6GB/512GB - $1399 6GB/1024GB - $1599

Design

Dimensions
6.33 x 3.07 x 0.29 inches (~0.40 inches with camera bump) 160.84 x 78.09 x 7.39 mm (~10.14 mm with camera bump)	6.33 x 3.05 x 0.31 inches (~0.474 inches with camera bump) 160.7 x 77.6 x 7.85 mm (~12.03 mm with camera bump)
Weight
8.03 oz / 228.0 g	8.47 oz / 240.0 g
Materials
Back: Glass Frame: Stainless steel	Back: Glass Frame: Stainless steel
Materials & Colors
Pacific blue, Gold, Silver, Graphite
Resistance
Water, Splash, Dust; IP68	Water, Dust; IP68
Biometrics
3D Face unlock	3D Face unlock
Keys
Left: Volume control, Other; Right: Lock/Unlock key	Left: Volume control, Other; Right: Lock/Unlock key
Colors
	Space Black, Silver, Gold, Deep Purple

Display

Size
6.7-inch, 87.45% screen-to-body	6.7-inch, 88.45% screen-to-body
Type
OLED, 60Hz, HDR, 1200 nits	OLED, Variable 1-120Hz, HDR, 2000 nits
Resolution
2778x1284px, 19.5:9 ratio, 458 PPI	2796x1290px, 19.5:9 ratio, 460 PPI
Protection
Ceramic Shield	Ceramic Shield
Features
HDR support, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor	Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor

PhoneArena Display Test

Bright Max (20% APL)
Untested	2072 (Excellent)
Bright Min
2 (Good)	1.9 (Good)

Learn more on our PhoneArena Display Test Results page.

Hardware

System chip
Apple A14 Bionic (5 nm)	Apple 16 Bionic (4 nm)
Processor
Hexa-core 3100 MHz	Hexa-core 2x3.46GHz Everest 4x2.02GHz Sawtooth
GPU
Yes	Apple GPU 5-core
Memory
6GB (LPDDR4)/128GB (NVMe) 6GB/256GB 6GB/512GB	6GB (LPDDR5)/128GB (NVMe) 6GB/256GB 6GB/512GB 6GB/1024GB
Storage expansion
not expandable	not expandable
OS
iOS (16.x, 15.x, 14.x)	iOS (18.x, 17.x, 16.x)

PhoneArena Performance Test

GeekBench 6 Single
2071	2423
GeekBench 6 Multi
4844	6306
3D Mark High
2481	3382
3D Mark Low
1792	2327

Learn more on our PhoneArena Performance Test Results page.

Battery

Type
3687 mAh, Li - Ion	4323 mAh, Li - Ion
Charging
USB Power Delivery Qi wireless charging, MagSafe wireless charging	Fast charging Qi wireless charging, MagSafe wireless charging
Charge speed
Wireless: 15.0W	Wired: 25.0W Wireless: 15.0W

PhoneArena Battery Tests

Battery Life Estimate

5h 59min

Browsing

14h 6min

Video

8h 37min

Gaming

8h 1min

Battery Life Estimate

7h 39min

Browsing

19h 5min

Video

11h 0min

Gaming

8h 39min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Triple camera	Triple camera
Main camera
12 MP (OIS, PDAF) Aperture size: F1.6 Focal length: 26 mm Pixel size: 1.7 μm	48 MP (Sensor-shift OIS, PDAF) Aperture size: F1.8 Focal length: 24 mm Sensor size: 1/1.28" Pixel size: 2.44 μm
Second camera
12 MP (Ultra-wide) Aperture size: F2.4 Focal Length: 13 mm	12 MP (Telephoto, OIS, PDAF) Optical zoom: 3.0x Aperture size: F2.8 Focal Length: 77 mm Sensor size: 1/3.5" Pixel size: 1.0 μm
Third camera
12 MP (Telephoto, OIS, PDAF) Optical zoom: 2.5x Aperture size: F2.2 Focal Length: 65 mm	12 MP (Ultra-wide, PDAF) Aperture size: F2.2 Focal Length: 13 mm Pixel size: 1.4 μm
Flash
LED	Dual LED
Video recording
4K UHD (60 fps), 1080p (240 fps), 720p (30 fps) OIS, HDR, Time-lapse video, Continuous autofocus, Picture-taking during video recording, Video light	4K UHD (60 fps), 1080p (240 fps), 720p (30 fps) OIS, HDR, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode
Front
12 MP (Time-of-Flight (ToF), EIS, HDR, Slow-motion videos) Video capture: 4K UHD (60 fps)	12 MP (Time-of-Flight (ToF), Autofocus, HDR) Video capture: 4K UHD (60 fps)

PhoneArena Camera Tests

N/A

Overall

N/A


N/A

Video

148

Overall

146


150

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.0	5.3
WLAN
Wi-Fi 6,dual-band MIMO, Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax	Wi-Fi 6 Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Lightning	Lightning
Sensors
Accelerometer, Gyroscope, Compass, Barometer, LiDAR scanner, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor
Hearing aid compatible
M3/T4	M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, Cell ID, Wi-Fi positioning	GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, Emergency SOS via satellite (SMS sending/receiving)
Other
NFC, UMA (Wi-Fi Calling)	NFC, Ultra Wideband (UWB)

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Loudspeaker	Earpiece, Multiple speakers
Features
Dolby Atmos	Dolby Atmos

Cellular

5G Bands
n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n66, n71, n77, n78, n79, n260, n261, Sub-6, mmWave	n1, n2, n3, n4, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave n1, n2, n3, n4, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, SA, NSA, Sub-6
LTE Bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 66, 71	1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 30, 32, 66, 71 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 66
TDD Bands
34, 38, 39, 40, 41, 42, 46, 48	34, 38, 39, 40, 41, 46, 48 34, 38, 39, 40, 41, 42, 46, 48
3G Bands
1, 2, 4, 5, 8	1, 2, 4, 5, 8
Data Speed
LTE-A, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
Dual SIM
Yes
SIM type
Nano SIM, eSIM	eSIM
HD Voice
Yes	Yes
VoLTE
Yes	Yes

Regulatory Approval

FCC approval
	Date approved: Sep 08, 2022 FCC ID value: BCG-E8154A
Measured SAR
	Head: 0.94 W/kg Body: 0.94 W/kg Simultaneous Transmission: 1.50 W/kg Wireless Router: 0.95 W/kg

Alternative variants

with 256GB storage

Memory	256GB
Prices (MSRP)	$1200

With 256Gb internal storage

Memory	256GB
Prices (MSRP)	$1199

with 512GB storage

Memory	512GB
Prices (MSRP)	$1400

With 512GB internal storage

Memory	512GB
Prices (MSRP)	$1399

With 1TB internal storage

Memory	1024GB
Prices (MSRP)	$1599

International

5G Bands	n1, n2, n3, n4, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n48, n66, n70, n77, n78, n79, SA, NSA, Sub-6
LTE Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 32, 66
TDD Bands	34, 38, 39, 40, 41, 42, 46, 48
SIM type	Nano SIM, eSIM
