Updated : Oct 01, 2024, 7:22 AM

Samsung Galaxy S10 Lite

Full Specifications

Released · Feb 03, 2020

This device is also known as Samsung SM-G770F/DS, Samsung SM-G770U

8.0

Read Samsung Galaxy S10 Lite Review

Be the first to review this phone

I want it 4 users

I have it 0 users

I had it 2 users

Popular Comparisons

The Samsung Galaxy S10 Lite is most commonly compared with these phones:

Design
Dimensions	6.40 x 2.98 x 0.32 inches 162.5 x 75.6 x 8.1 mm
Weight	6.56 oz (186.0 g)
Materials	Back: Glass Frame: Metal
Biometrics	2D Face unlock, Ultrasonic in-screen fingerprint
Keys	Right: Volume control, Lock/Unlock key
Colors	Prism white, Prism black, Prism blue

Display
Size	6.7-inch
Resolution	2400x1080px, 20:9 ratio, 393 PPI
Technology	Super AMOLED Plus
Screen-to-body	88.08 %
Features	HDR support, Ambient light sensor, Proximity sensor

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	1.6 (Good)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Qualcomm Snapdragon 855 SM8150 (7 nm)
Processor	Octa-core 2840 MHz Kryo 485
GPU	Adreno 640
RAM	8GB (LPDDR4)
Internal storage	128GB, available to use: 105.7 GB
Storage expansion	microSDXC up to 1000 GB
OS	Android (11, 10), Samsung One UI

Battery
Capacity	4500 mAh
Type	Li - Polymer
Charging	USB Power Delivery

PhoneArena Battery Test
Battery Life Estimate:	6h 21min
Browsing:	11h 47min
Gaming:	9h 52min
Video:	10h 30min
Learn more on our PhoneArena Battery Test Results page.

Camera
Rear	Triple camera
Main camera	48 MP (OIS, PDAF) Aperture size: F2.0 Focal length: 26 mm Sensor size: 1/2" Pixel size: 0.8 μm
Second camera	12 MP (Ultra-wide) Aperture size: F2.2 Focal Length: 12 mm
Third camera	5 MP (Macro) Aperture size: F2.4 Sensor size: 1/5" Pixel size: 1.12 μm
Flash	LED
Video recording	3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps) EIS
Front	32 MP, Video capture: 1920x1080 (Full HD)

Connectivity & Features
Bluetooth	5.0
Wi-Fi	802.11 a,b,g,n,ac,dual-band Wi-Fi Direct, Hotspot
USB	Type-C, USB 2.0
Location	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors	Accelerometer, Gyroscope, Compass, Hall (for flip covers)
Other	NFC, ANT+

Multimedia
Headphones	No 3.5mm jack
Speakers	Earpiece, Loudspeaker
Screen mirroring	Wireless screen share
Additional microphone(s)	Noise cancellation

Cellular
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 26(850+), 28(700 APT), 66(AWS-3)
4G (TDD)	Bands 38(2600), 40(2300), 41(2600+)
3G	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed	LTE-A Cat 12 (600/100 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM	Yes
SIM type	Nano SIM
HD Voice	Yes

Regulatory Approval
FCC approval	Date approved: Mar 18, 2020 FCC ID value: A3LSMG770U
Measured SAR	Head: 0.36 W/kg Body: 1.18 W/kg Simultaneous Transmission: 1.59 W/kg Wireless Router: 1.20 W/kg Phablet: 2.53 W/kg

Buyers information
MSRP	$ 650

Availability
Officially announced	Jan 03, 2020

Despite our efforts to provide full and correct Samsung Galaxy S10 Lite specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.
