Coolpad Legacy S vs TCL SIGNA Specs Comparison

Design

Dimensions
6 x 2.8 x 0.37 inches 152.4 x 71.1 x 9.4 mm	5.76 x 2.8 x 0.37 inches 146.3 x 71.1 x 9.4 mm
Weight
5.6 oz (159.0 g)	5.64 oz (160.0 g)
Materials
	Back: Plastic Frame: Plastic
Biometrics
2D Face unlock	2D Face unlock
Keys
Right: Volume control, Lock/Unlock key	Right: Volume control, Lock/Unlock key
Colors
	Black

Display

Size
5.5-inch	5.5-inch
Resolution
1440x720px, 18:9 ratio, 295 PPI	1440x720px, 18:9 ratio, 293 PPI
Technology
LCD	IPS LCD
Screen-to-body
70.72 %	72.56 %
Features
Ambient light sensor, Proximity sensor	Scratch-resistant glass (Dragontrail), Ambient light sensor, Proximity sensor

Hardware

System chip
MediaTek Helio A22 MT6761 (12 nm)	Qualcomm Snapdragon 429 SDM429 (12 nm)
Processor
Quad-core 2000 MHz ARM Cortex-A53	Quad-core 1900 MHz Arm Cortex-A53
GPU
PowerVR GE8300	Adreno 504
RAM
2GB	2GB (LPDDR3)
Internal storage
16GB	16GB, available to use: 8.5 GB
Storage expansion
microSDXC up to 64 GB 9	microSDXC up to 256 GB
OS
Android (9.0 Pie)	Android (10)

Battery

Capacity
2450 mAh	3000 mAh
Type
Li - Ion

Camera

Rear
Single camera	Single camera
Main camera
8 MP	8 MP (Autofocus)
Flash
LED	LED
Video recording
1920x1080 (Full HD) EIS	1920x1080 (Full HD) (30 fps)
Front
5 MP	5 MP

Connectivity & Features

Bluetooth
4.2	4.2
WLAN
802.11 b,g,n Wi-Fi Direct, Hotspot	802.11 b,g,n,ac,dual-band Wi-Fi Direct, Hotspot
USB
Type-C	Type-C
Hearing aid compatible
M4/T4	M3/T3
Location
GPS, A-GPS, Cell ID, Wi-Fi positioning	GPS, A-GPS, Cell ID, Wi-Fi positioning
Sensors
Accelerometer	Accelerometer, Compass
Other
	NFC, UMA (Wi-Fi Calling)

Multimedia

Headphones
3.5mm jack	3.5mm jack
Speakers
Earpiece, Loudspeaker	Earpiece, Loudspeaker
Screen mirroring
Wireless screen share	Wireless screen share
Radio
FM	FM
Additional microphone(s)
	Noise cancellation

Cellular

4G (FDD)
Bands 2(1900), 4(AWS-1), 5(850), 12(700 a), 13(700 c), 25(1900+), 26(850+), 66(AWS-3), 71(600)	Bands 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 12(700 a), 13(700 c), 66(AWS-3)
4G (TDD)
Bands 41(2600+)
3G
Bands 5(850), 4(1700/2100), 2(1900)	Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Data Speed
LTE Cat 4 (150/50 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s	LTE Cat 4 (150/50 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type
Nano SIM	Nano SIM
HD Voice
	Yes
VoLTE
	Yes

Regulatory Approval

FCC approval
Date approved: Aug 01, 2019 FCC ID value: R38YLCP3648A	Date approved: Jul 20, 2020 FCC ID value: 2ACCJH127
Measured SAR
Head: 0.79 W/kg Body: 1.39 W/kg Simultaneous Transmission: 1.48 W/kg Wireless Router: 1.11 W/kg	Head: 0.37 W/kg Body: 0.98 W/kg Simultaneous Transmission: 1.33 W/kg Wireless Router: 1.33 W/kg

Buyers information

MSRP
$ 100	$ 80
In The Box
Battery, Travel adapter, USB Type-C cable	4G LTE SIM card (Pre-installed), USB Type-C Wall Charger, USB cable, SIM ejector tool, Verizon brochures
