TCL SIGNA

Full Specifications

Released · Sep 25, 2020

5.5-inch · 1440x720px

Be the first to review this phone

I want it 0 users

I have it 0 users

I had it 0 users

Popular Comparisons

The TCL SIGNA is most commonly compared with these phones:

Availability
Prices (MSRP)	$80

Design
Dimensions	5.76 x 2.8 x 0.37 inches 146.3 x 71.1 x 9.4 mm
Weight	5.64 oz / 160.0 g
Materials	Back: Plastic Frame: Plastic
Biometrics	2D Face unlock
Keys	Right: Volume control, Lock/Unlock key
Colors	Black

Display
Size	5.5-inch, 72.56% screen-to-body
Type	IPS LCD
Resolution	1440x720px, 18:9 ratio, 293 PPI
Protection	Dragontrail

Hardware
System chip	Snapdragon 429 SDM429 (12 nm)
Processor	Quad-core 1900 MHz Arm Cortex-A53
GPU	Adreno 504
Memory	2GB (LPDDR3)/16GB
Storage expansion	microSDXC up to 256 GB
OS	Android (10)

Battery
Type	3000 mAh

Camera
Rear	Single camera
Main camera	8 MP (Autofocus)
Flash	LED
Video recording	1080p (30 fps)
Front	5 MP

Connectivity & Features
Bluetooth	4.2
WLAN	b,g,n,ac,dual-band Wi-Fi Direct, Hotspot 802.11 b, g, n, ac
USB	Type-C
Sensors	Accelerometer, Compass, Ambient light sensor, Proximity sensor
Hearing aid compatible	M3/T3
Location	GPS, A-GPS, Cell ID, Wi-Fi positioning
Other	NFC, UMA (Wi-Fi Calling)

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Screen mirroring	Wireless screen share
Radio	FM
Additional microphone(s)	Noise cancellation

Cellular
4G (FDD) Bands	2, 3, 4, 5, 7, 12, 13, 66
3G Bands	5, 8, 4, 2, 1
Data Speed	LTE Cat 4 (150/50 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type	Nano SIM
HD Voice	Yes
VoLTE	Yes

Regulatory Approval
FCC approval	Date approved: Jul 20, 2020 FCC ID value: 2ACCJH127
Measured SAR	Head: 0.37 W/kg Body: 0.98 W/kg Simultaneous Transmission: 1.33 W/kg Wireless Router: 1.33 W/kg
