Sony Xperia XA2 Ultra

Full Specifications

Released · Feb 16, 2018

6.0-inch

Single camera

3580 mAh

4GB · 32GB

This device is also known as Sony H3223

7.8

Read Sony Xperia XA2 Ultra Review

7.7

Read All User Reviews (3)

I want it 6 users

I have it 3 users

I had it 3 users

Popular Comparisons

The Sony Xperia XA2 Ultra is most commonly compared with these phones:

•

  Sony Xperia XA2 Ultra
  vs


  Sony Xperia XA2
•

  Sony Xperia XA2 Ultra
  vs


  Sony Xperia XA1 Ultra
•

  Sony Xperia XA2 Ultra
  vs


  Sony Xperia XA3
•

  Sony Xperia XA2 Ultra
  vs


  Sony Xperia L2
•

  Sony Xperia XA2 Ultra
  vs


  Sony Xperia XA

Design
Dimensions	6.42 x 3.15 x 0.37 inches 163 x 80 x 9.5 mm
Weight	7.80 oz (221.0 g)
Materials	Back: Plastic Frame: Aluminum
Biometrics	Fingerprint (touch)
Keys	Right: Volume control, Camera shutter, Lock/Unlock key
Colors	Black, Gold, Silver, Blue

Display
Size	6.0-inch
Resolution	1920x1080px, 16:9 ratio, 367 PPI
Technology	IPS LCD
Screen-to-body	76.07 %
Colors	16 777 216
Peak brightness	500 cd/m2 (nit)
Features	Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	2 (Good)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Qualcomm Snapdragon 630 SDM630 (14 nm)
Processor	Octa-core 2200 MHz ARM Cortex-A53
GPU	Adreno 508
RAM	4GB (LPDDR4)
Internal storage	32GB, available to use: 24 GB
Storage expansion	microSDXC up to 256 GB
OS	Android (9.0 Pie, 8.0 Oreo)
This device has different variants: View all

Battery
Capacity	3580 mAh
Type	Li - Polymer
Charging	Qualcomm Quick Charge 3.0

Camera
Rear	Single camera
Main camera	23 MP (PDAF) Aperture size: F2.0 Focal length: 24 mm Sensor size: 1/2.3" Pixel size: 1.12 μm
Flash	LED
Video recording	3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (60 fps), 1280x720 (HD) (120 fps) HDR, EIS, Video calling, Video sharing
Front	16 MP (Dual-Camera, OIS, Wide Angle, Autofocus, Flash), Video capture: 1920x1080 (Full HD)

Connectivity & Features
Bluetooth	5.0
Wi-Fi	802.11 a,b,g,n,ac,dual-band Wi-Fi Direct, Hotspot
USB	Type-C, USB 2.0
Location	GPS, A-GPS, Glonass
Sensors	Accelerometer, Compass, Step detector, Step counter
Other	NFC, UMA (Wi-Fi Calling), VoIP, Tethering, Computer sync, OTA sync

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Features	aptX-HD
Screen mirroring	Wireless screen share
Radio	FM
Additional microphone(s)	Noise cancellation

Cellular
4G (FDD)	Bands 1(2100), 2(1900), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 25(1900+), 28(700 APT), 29(700 d), 66(AWS-3)
3G	Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Data Speed	LTE-A Cat 12/13 (600/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type	Nano SIM
This device has different variants: View all

Phone Features
Notifications	Haptic feedback, Music ringtones, Flight mode, Silent mode, Speakerphone
Other features	Voice dialing, Voice commands, Voice recording, TTY/TDD

Regulatory Approval
FCC approval	Date approved: May 25, 2018 FCC ID value: PY7-67442A
Measured SAR	Head: 0.50 W/kg Body: 0.49 W/kg Simultaneous Transmission: 1.57 W/kg Wireless Router: 1.00 W/kg

Buyers information
In The Box	USB Type-C cable for charging and user documentation

Availability
Officially announced	Jan 08, 2018

Despite our efforts to provide full and correct Sony Xperia XA2 Ultra specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Dual SIM

Differences from the main variant:
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 5(850), 7(2600), 8(900), 20(800 DD)
4G (TDD)	Bands 38(2600)
3G	Bands 5(850), 8(900), 2(1900), 1(2100)
Dual SIM	Yes

Dual SIM and 64 GB storage

Differences from the main variant:
Internal storage	64GB, available to use: 55 GB
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 5(850), 7(2600), 8(900), 28(700 APT)
4G (TDD)	Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
3G	Bands 5(850), 8(900), 2(1900), 1(2100)
Dual SIM	Yes

Differences from the main variant:
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 5(850), 7(2600), 8(900), 20(800 DD)
4G (TDD)	Bands 38(2600)
3G	Bands 5(850), 8(900), 2(1900), 1(2100)
