Samsung Galaxy Note10 Lite

Full Specifications

Released · Jan 21, 2020

This device is also known as Samsung SM-N770F/DS, Samsung Galaxy Note 10 Lite

8.0

Read Samsung Galaxy Note10 Lite Review

Be the first to review this phone

I want it 8 users

I have it 1 user

I had it 1 user

Popular Comparisons

The Samsung Galaxy Note10 Lite is most commonly compared with these phones:

Design
Dimensions	6.44 x 3.00 x 0.34 inches 163.7 x 76.1 x 8.7 mm
Weight	7.02 oz (199.0 g)
Materials	Back: Glass Frame: Aluminum
Biometrics	Optical in-screen fingerprint
Features	Stylus
Keys	Right: Volume control, Lock/Unlock key
Colors	Aura glow, Aura black, Aura red

Display
Size	6.7-inch
Resolution	2400x1080px, 20:9 ratio, 393 PPI
Technology	Super AMOLED
Screen-to-body	86.95 %
Features	Scratch-resistant glass (Corning Gorilla Glass), Ambient light sensor, Proximity sensor

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	1.6 (Good)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Samsung Exynos 9810 (10 nm)
Processor	Octa-core 2700 MHz Exynos M3 and ARM Cortex-A55
GPU	Mali-G72 MP18
RAM	6GB (LPDDR4)
Internal storage	128GB (UFS 2.1), available to use: 106.1 GB
Storage expansion	microSDXC up to 1000 GB
OS	Android (11, 10), Samsung One UI
This device has different variants: View all

Battery
Capacity	4500 mAh
Type	Li - Polymer
Charging	Fast charging
Charge speed	Wired: 25.0W

PhoneArena Battery Test
Battery Life Estimate:	5h 38min
Browsing:	11h 9min
Gaming:	7h 55min
Video:	9h 13min
Learn more on our PhoneArena Battery Test Results page.

Camera
Rear	Triple camera
Main camera	12 MP (OIS, PDAF) Aperture size: F1.7 Focal length: 27 mm Sensor size: 1/2.55" Pixel size: 1.4 μm
Second camera	12 MP (Ultra-wide) Aperture size: F2.2 Focal Length: 13 mm
Third camera	12 MP (Telephoto, OIS, PDAF) Optical zoom: 2.0x Aperture size: F2.4 Focal Length: 52 mm Sensor size: 1/3.6" Pixel size: 13 μm
Flash	LED
Video recording	3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps) EIS
Front	32 MP (HDR), Video capture: 1920x1080 (Full HD)

Connectivity & Features
Bluetooth	5.0
WLAN	802.11 a,b,g,n,ac,dual-band MIMO, Wi-Fi Direct, Hotspot
USB	Type-C, USB 2.0
Location	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors	Accelerometer, Gyroscope, Compass, Hall (for flip covers)
Other	NFC, ANT+

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Features	Dolby Atmos
Screen mirroring	Wireless screen share
Additional microphone(s)	Noise cancellation

Cellular
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 28(700 APT), 66(AWS-3)
4G (TDD)	Bands 38(2600), 40(2300), 41(2600+)
3G	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed	LTE-A, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM	Yes
SIM type	Nano SIM
VoLTE	Yes

Regulatory Approval
FCC approval	Date approved: Dec 16, 2019 FCC ID value: A3LSMN770F
Measured SAR	Head: 0.23 W/kg Body: 0.65 W/kg Simultaneous Transmission: 1.34 W/kg Wireless Router: 1.37 W/kg Phablet: 2.63 W/kg

Availability
Officially announced	Jan 03, 2020

Despite our efforts to provide full and correct Samsung Galaxy Note10 Lite specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

with 8GB RAM

Differences from the main variant:
RAM	8GB
