Samsung Galaxy Z Flip 5G vs Samsung Galaxy Z Flip 5 Specs Comparison

Availability

Officially announced
Jul 22, 2020	Jul 26, 2023
Prices (MSRP)
$1450	$999

Design

Dimensions
6.59 x 2.90 x 0.28 inches 167.3 x 73.6 x 7.2 mm	6.50 x 2.83 x 0.27 inches 165.1 x 71.9 x 6.9 mm
Folded
(87.4 x 73.6 x 17.3 mm)	(85.1 x 71.9 x 15.1 mm)
Weight
6.46 oz / 183.0 g	6.60 oz / 187.0 g
Materials
Frame: Aluminum	Back: Glass (Corning Gorilla Glass Victus 2) Frame: Aluminum
Resistance
None	Yes; IPX8
Biometrics
2D Face unlock, Fingerprint (touch)	Fingerprint (touch)
Keys
Right: Volume control, Lock/Unlock key
Colors
Mystic gray, Mystic bronze, Mystic white	Mint, Graphite, Cream, Lavender, Gray, Blue, Green, Yellow

Display

Size
6.7-inch, 81.04% screen-to-body	6.7-inch, 85.70% screen-to-body
Type
Dynamic AMOLED, HDR	Dynamic AMOLED, 120Hz, HDR
Resolution
2636x1080px, 22:9 ratio, 425 PPI	2640x1080px, 22:9 ratio, 426 PPI
Front cover display
	3.4 inches 720 x748 px Super AMOLED Scratch-resistant glass (Corning Gorilla Glass Victus 2)
Additional display
1.1 inches, 112 x300 px, Super AMOLED

PhoneArena Display Test

Bright Max (20% APL)
Untested	Untested
Bright Min
Untested	1 (Excellent)

Learn more on our PhoneArena Display Test Results page.

Hardware

System chip
Snapdragon 865+ SM8250-AB (7 nm)	Snapdragon 8 Gen 2 SM8550-AC (4 nm)
Processor
Octa-core 1x3.1GHz Kryo 585 3x2.42GHz Kryo 585 4x1.80GHz Kryo 585	Octa-core 1x3.36GHz Cortex-X3 2x2.8GH​z Cortex-A715 2x2.8​GHz Cortex-A710 3x2.0​GHz Cortex-A510
GPU
Adreno 650	Adreno 740
Memory
8GB (LPDDR4)/256GB	8GB/256GB 8GB/512GB
Storage expansion
not expandable	not expandable
OS
Android (12, 11, 10)	Android (13)

PhoneArena Performance Test

GeekBench 6 Single
Untested	1984
GeekBench 6 Multi
Untested	5194
3D Mark High
Untested	3700
3D Mark Low
Untested	1351

Learn more on our PhoneArena Performance Test Results page.

Battery

Type
3300 mAh, Li - Polymer	3700 mAh
Charging
Qualcomm Quick Charge 2.0 Qi wireless charging, Reverse wireless charging	Fast charging Qi wireless charging, Reverse wireless charging
Charge speed
Wired: 15.0W Wireless: 9.0W	Wired: 25.0W Wireless: 10.0W

PhoneArena Battery Tests

Battery Life Estimate

Untested

Browsing

Untested

Video

Untested

Gaming

Untested

Battery Life Estimate

5h 11min

Browsing

12h 21min

Video

7h 13min

Gaming

7h 23min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Dual camera	Dual camera
Main camera
12 MP (OIS, PDAF) Aperture size: F1.8 Focal length: 27 mm Sensor size: 1/2.55" Pixel size: 1.4 μm	12 MP (OIS, PDAF) Aperture size: F1.8 Focal length: 24 mm Pixel size: 1.8 μm
Second camera
12 MP (Ultra-wide) Aperture size: F2.2 Pixel size: 1.12 μm	12 MP (Ultra-wide) Aperture size: F2.2 Pixel size: 1.12 μm
Flash
LED	LED
Video recording
4K UHD (60 fps), 1080p (240 fps), 720p (960 fps) HDR, Time-lapse video, Hyperlapse, Continuous autofocus, EIS	Yes
Front
10 MP Video capture: 4K UHD (30 fps)	10 MP

PhoneArena Camera Tests

N/A

Overall

N/A


N/A

Video

136

Overall

137


135

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.0	5.3
WLAN
a,b,g,n,ac,Wi-Fi 6,dual-band MIMO, Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax	a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Type-C, USB 3.1	Type-C
Sensors
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer, Ambient light sensor, Proximity sensor
Hearing aid compatible
M4/T3
Location
GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Other
NFC, ANT+	NFC

Multimedia

Headphones
No 3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Multiple speakers	Earpiece, Loudspeaker
Features
Dolby Atmos, Dolby Digital, Dolby Digital Plus
Screen mirroring
Wireless screen share	Wireless screen share
Additional microphone(s)
Noise cancellation	Noise cancellation

Cellular

5G Bands
n2, n5, n25, n41, n66, n71, SA, NSA, Sub-6	5G Ready
4G (FDD) Bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 20, 25, 26, 29, 30, 66, 71
4G (TDD) Bands
38, 40, 41, 48
3G Bands
1, 2, 4, 5, 8
Data Speed
LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
Dual SIM
Yes
SIM type
Nano SIM, eSIM	Nano SIM, eSIM
HD Voice
Yes

Regulatory Approval

FCC approval
Date approved: Jul 20, 2020 FCC ID value: A3LSMF707U	Date approved: Jul 13, 2023 FCC ID value: A3LSMF731U
Measured SAR
Head: 0.46 W/kg Body: 0.90 W/kg Simultaneous Transmission: 1.59 W/kg Wireless Router: 1.35 W/kg Phablet: 3.99 W/kg	Head: 1.16 W/kg Body: 0.43 W/kg Simultaneous Transmission: 1.56 W/kg Wireless Router: 1.13 W/kg

Alternative variants

With 512GB internal storage

Memory	512GB
