Samsung Galaxy S20+ Specs

Description

The Samsung Galaxy S20+ comes with a Snapdragon 865/Exynos 990 chipset, 12GB RAM and 128GB/256GB/512GB of storage, as well as a 4,500mAh battery. Quad-camera setup is on the back of the phone: a 12MP primary sensor, an ultra-wide-angle camera, a telephoto camera, and a Time of Flight sensor. The price of Galaxy S20+ starts at $1200.

This device is also known as Samsung Galaxy S20 Plus, Samsung Galaxy S20+ 5G, Samsung SM-G986U

Pros

  • High refresh rate (120Hz)
  • 5G ready
  • High screen-to-body ratio (90.94 %)
  • Supports wireless charging
  • High pixel density screen (524 PPI)

Popular Comparisons

The Samsung Galaxy S20+ is most commonly compared with these phones:

Specs Compare

Display

Benchmarks
Size: 6.7 inches
Resolution: 3200 x 1440 pixels, 20:9 ratio, 524 PPI
Technology: Dynamic AMOLED
Refresh rate: 120Hz (@1080p)
Screen-to-body: 90.94 %
Features: HDR support, Scratch-resistant glass (Corning Gorilla Glass 6), Ambient light sensor, Proximity sensor

Hardware

Benchmarks
System chip: Qualcomm Snapdragon 865 SM8250 (7 nm)
Processor: Octa-core, 1x 2.84GHz Kryo 585 + 3x 2.42GHz Kryo 585 + 4x 1.80GHz Kryo 585, 64-bit
GPU: Adreno 650
RAM: 12GB LPDDR5
Internal storage: 128GB (UFS 3.0), available to use: 104.1 GB
Storage expansion: microSDXC up to 1000 GB
Device type: Smartphone
OS: Android (13, 12, 11, 10), Samsung One UI

Battery

Benchmarks
Capacity: 4500 mAh
Type: Li - Polymer, Not user replaceable
Battery life test results: link
Charging: Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging, Reverse wireless charging
Max charge speed: Wired: 25.0W; Wireless: 15.0W

Camera

Rear: Quad camera
Main camera: 12 MP (OIS, PDAF)
Specifications: Aperture size: F1.8; Focal length: 26 mm; Sensor size: 1/1.7"; Pixel size: 1.8 μm
Second camera: 64 MP (Telephoto, OIS, PDAF)
Specifications: Optical zoom: 1.1x; Aperture size: F2.0; Focal Length: 29 mm; Sensor size: 1/1.7"; Pixel size: 0.8 μm
Third camera: 12 MP (Ultra-wide, Autofocus)
Specifications: Aperture size: F2.2; Focal Length: 13 mm; Pixel size: 1.4 μm
Fourth camera: 0.3 MP VGA (ToF 3D depth sensing)
Specifications: Aperture size: F1.0
Flash: LED
Video recording: 7680x4320 (8K UHD) (24 fps), 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Features: OIS, HDR, EIS
Front: 10 MP (PDAF, HDR)
Video capture: 3840x2160 (4K UHD) (60 fps)
Dimensions: 6.37 x 2.90 x 0.31 inches (161.9 x 73.7 x 7.8 mm)
Weight: 6.56 oz (188.0 g)
Materials: Back: Glass (Corning Gorilla Glass 6); Frame: Aluminum
Resistance: Water, Dust; IP68
Biometrics: 2D Face unlock, Ultrasonic in-screen fingerprint
Keys: Right: Volume control, Lock/Unlock key
Colors: Cosmic grey, Cloud blue, Cosmic black, Cosmic white, Aura red, Aura blue

Cellular

5G: n2, n5, n41, n66, n71, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD): Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G: Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed: LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type: Nano SIM

Multimedia

Headphones: No 3.5mm jack
Speakers: Earpiece, Multiple speakers
Features: 32-Bit DAC, Dolby Atmos, aptX, Dolby Digital, Dolby Digital Plus
Screen mirroring: Wireless screen share
Radio: FM
Additional microphone(s): for Noise cancellation

Connectivity & Features

Bluetooth: 5.0
Wi-Fi: 802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
USB: Type-C (reversible), USB 3.2
Features: Charging, Headphones port, OTG
Location: GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Sensors: Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other: NFC, ANT+

Regulatory Approval

FCC approval:
Date approved: Jan 28, 2020
FCC ID value: A3LSMG986B
Measured SAR:
Head: 0.25 W/kg
Body: 0.89 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 1.35 W/kg
Phablet: 2.95 W/kg

Buyers information

Price: $ 1200
User Manual: This is the official Samsu​ng Galaxy S20+ User Guide in English provided from the manufacturer.

Availability

Officially announced: Feb 11, 2020
Despite our efforts to provide full and correct Samsung Galaxy S20+ specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

Samsung Galaxy S20+

SM-G986F Global variant

Differences from the main variant:
System chip: Samsung Exynos 990 (7 nm)
Processor: Octa-core, 2x 2.73GHz Exynos M5 + 2x 2.5GHz Cortex-A76 + 4x 2.0GHz Cortex-A55, 64-bit
GPU: Mali G77 MP11
5G: n1, n3, n5, n7, n8, n28, n40, n77, n78, Sub-6
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 32(1500 L-band), 66(AWS-3)
Dual SIM: Shared with microSD
SIM type: Nano SIM, eSIM

Samsung Galaxy S20+

non 5G variant

Differences from the main variant:
RAM: 8GB
Weight: 6.56 oz (186.0 g)
FCC approval:
Date approved: Jan 28, 2020
FCC ID value: A3LSMG985F
Measured SAR:
Head: 0.26 W/kg
Body: 1.03 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 1.37 W/kg
Phablet: 3.00 W/kg

Samsung Galaxy S20+

with 256GB storage

Differences from the main variant:
Internal storage: 256GB

Samsung Galaxy S20+

with 512GB storage

Differences from the main variant:
Internal storage: 512GB
Price: $ 1400

Samsung Galaxy S20+

for Verizon

Differences from the main variant:
4G (FDD): Bands 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 18(800 Lower), 19(800 Upper), 20(800 DD), 26(850+), 28(700 APT), 66(AWS-3)
3G: Bands 5(850), 8(900), 2(1900), 1(2100)

Samsung Galaxy S20+

for AT&T

Differences from the main variant:
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3)
4G (TDD): Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46

Samsung Galaxy S20+

for T-Mobile

Differences from the main variant:
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 66(AWS-3), 71(600)
3G: Bands 5(850), 4(1700/2100), 2(1900), 1(2100)

Samsung Galaxy S20+

for Sprint

Differences from the main variant:
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 66(AWS-3), 71(600)
4G (TDD): Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46

Samsung Galaxy S20+

for U.S. Cellular

Differences from the main variant:
4G (FDD): Bands 2(1900), 4(AWS-1), 5(850), 12(700 a), 13(700 c), 25(1900+), 66(AWS-3), 71(600)
4G (TDD): Bands 38(2600), 39(1900+), 40(2300), 46, 48(3600)
3G: Bands 5(850), 8(900), 2(1900), 1(2100)
