Samsung Galaxy Note 20 Specs

Released

Aug 21, 2020

Display

6.7-inch
2400 x 1080 px

Camera

12 MP Main
10 MP Selfie

Battery

4300 mAh

Storage

128GB

Hardware

Qualcomm Snapdragon 865+
8GB RAM

OS

Android 13
Samsung One UI

Description

The Samsung Galaxy Note 20 specs include Snapdragon 865 chipset and an Exynos one to match in all non-US regions accompanied by 8GB of RAM and up to 256GB storage, and 4300mAh battery. At the back is situated the triple-camera setup from the Galaxy S20. A 6.7-inch sAMOLED display with a 60Hz refresh rate is at the front. S Pen and 5G come off as standard. The Galaxy Note 20 is available for starting price of $1000.

This device is also known as Samsung SM-N981U

8.0

PhoneArena Score

Samsung Galaxy Note 20 Review

User Score

Be the first to review this phone

Add Review

I want it 0 users

I have it 0 users

I had it 1 user

Deals

Deal

$999

$239

View more offers

Popular Comparisons

The Samsung Galaxy Note 20 is most commonly compared with these phones:

Specs

Display Benchmarks
Size	6.7-inch
Resolution	2400 x 1080 px, 20:9 ratio, 393 PPI
Technology	Super AMOLED Plus
Refresh rate	60Hz
Screen-to-body	89.23 %
Features	HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor

Hardware
System chip	Qualcomm Snapdragon 865+ SM8250-AB (7 nm)
Processor	Octa-core, 1x 3.1GHz Kryo 585 + 3x 2.42GHz Kryo 585 + 4x 1.80GHz Kryo 585, 64-bit
GPU	Adreno 650
RAM	8GB (LPDDR5)
Internal storage	128GB (UFS 3.0), available to use: 102.5 GB, not expandable
OS	Android (13, 12, 11, 10), Samsung One UI
Device type	Smartphone
This device has different variants: View all

Battery
Capacity	4300 mAh
Type	Li - Polymer, Not user replaceable
Charging	Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging, Reverse wireless charging

PhoneArena Battery Test
Battery Life Estimate:	5h 3min
Browsing:	11h 58min
Gaming:	6h 38min
Video:	7h 17min
Find out more details about battery and charging for all phones we have tested on our PhoneArena Battery Score page.

Camera
Rear	Triple camera
Main camera	12 MP (OIS, PDAF) Specifications: Aperture size: F1.8 Focal length: 26 mm Sensor size: 1/1.76" Pixel size: 1.8 μm
Second camera	64 MP (Telephoto, OIS, PDAF) Specifications: Aperture size: F2.0 Focal Length: 27 mm Sensor size: 1/1.7" Pixel size: 0.8 μm
Third camera	12 MP (Ultra-wide, Autofocus) Specifications: Aperture size: F2.2 Focal Length: 13 mm Sensor size: 1/2.55" Pixel size: 1.4 μm
Flash	LED
Video recording	7680x4320 (8K UHD) (24 fps), 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps) Features: OIS, HDR, Time-lapse video, Hyperlapse, Object tracking, EIS
Front	10 MP (PDAF, HDR), Video capture: 3840x2160 (4K UHD)

Design
Dimensions	6.36 x 2.96 x 0.33 inches (161.6 x 75.2 x 8.3 mm)
Weight	6.84 oz(194.0 g)
Materials	Back: Plastic
Resistance	Water, Dust; IP68
Biometrics	2D Face unlock, Ultrasonic in-screen fingerprint
Features	Stylus
Keys	Right: Volume control, Lock/Unlock key
Colors	Mystic gray, Mystic bronze, Mystic green, Mystic red

Cellular
5G	Bands n2, n5, n12, n25, n41, n66, n71, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD)	Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3)
4G (TDD)	Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G	Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed	LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type	Nano SIM
HD Voice	Yes

Multimedia
Headphones	No 3.5mm jack
Speakers	Earpiece, Multiple speakers
Features	32-Bit DAC, Dolby Atmos, aptX, Dolby Digital, Dolby Digital Plus
Screen mirroring	Wireless screen share
Radio	FM
Additional microphone(s)	Noise cancellation

Connectivity & Features
Bluetooth	5.0
Wi-Fi	802.11 a,b,g,n,ac,ax(Wi-Fi 6),dual-band MIMO, Wi-Fi Direct, Hotspot
USB	Type-C (reversible), USB 3.2, Features: Charging, Headphones port, OTG, Video out
Hearing aid compatible	M3/T3
Location	GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Sensors	Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other	NFC, ANT+

Regulatory Approval
FCC approval	Date approved: Jul 22, 2020 FCC ID value: A3LSMN981U
Measured SAR	Head: 0.41 W/kg Body: 0.92 W/kg Simultaneous Transmission: 1.59 W/kg Wireless Router: 1.22 W/kg Phablet: 3.99 W/kg
This device has different variants: View all

Buyers information
MSRP	$ 1000
In The Box	Data Cable, Travel Adapter, Ejection Pin, Quick Start Guide
This device has different variants: View all

Availability
Officially announced	Aug 05, 2020

Despite our efforts to provide full and correct Samsung Galaxy Note 20 specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

For Europe

Differences from the main variant:
System chip	Samsung Exynos 990 (7 nm)
Processor	Octa-core, 2x 2.73GHz Exynos M5 + 2x 2.5GHz Cortex-A76 + 4x 2.0 GHz Cortex-A55, 64-bit
GPU	Mali G77 MP11
Internal storage	256GB
FCC approval	Date approved: Jul 16, 2020 FCC ID value: A3LSMN981B
Measured SAR	Head: 0.29 W/kg Body: 0.72 W/kg Simultaneous Transmission: 1.60 W/kg Wireless Router: 1.24 W/kg Phablet: 1.93 W/kg
MSRP	€ 1023
