HTC One max

Announced:
Oct 14, 2013
Market status:
Released

PhoneArena Rating:

8.3
Read Full Review

HTC One max

Announced: Oct 14, 2013
Market status: Released

PhoneArena Rating:

8.3
Read Full Review
  • Display 5.9" 1080 x 1920 pixels
  • Camera 4 MP / 2.1 MP front
  • Processor Qualcomm Snapdragon 600, Quad-core, 1700 MHz
  • Storage 32 GB + microSDXC
  • Battery 3300 mAh(25h 3G talk time)
  • Fingerprint
  • Lightweight
  • Thin
  • LTE
  • Waterproof
  • NFC
  • Dual SIM*

Display

  • benchmark

Display size:

5.9 inches

Resolution:

1080 x 1920 pixels

Pixel density:

373 ppi

Technology:

S-LCD 3

Screen-to-body ratio:

70.63 %

Features:

Ambient light sensor, Proximity sensor

Camera

  • benchmark

Rear:

Single camera

Main camera:

4 megapixels

Hardware Features:

Autofocus, Back-illuminated sensor (BSI)

Specifications:

Aperture size: F2.0; Focal length: 28 mm; Sensor size: 1/3"; Pixel size: 2 μm

Flash:

LED

Video recording:

1920x1080 (Full HD) (30 fps), 1280x720 (HD) (60 fps)

Features:

High Dynamic Range mode (HDR), Continuous autofocus

Front:

2.1 megapixels

Design

Dimensions:

6.48 x 3.25 x 0.41 inches (164.5 x 82.5 x 10.29 mm)

Weight:

7.65 oz (217 g)
the average is 6 oz (172 g)

Materials:

Back: Aluminum

Biometrics:

Fingerprint (swipe)

Features:

Touch sensitive control keys

Hardware & Performance

  • benchmark

System chip:

Qualcomm Snapdragon 600 APQ8064T

Processor:

Quad-core, 1700 MHz, Krait 300

GPU:

Adreno 320

RAM:

2 GB

Internal storage:

32 GB

Storage expansion:

up to 64 GB

OS:

Android (4.4.2, 4.4, 4.3), HTC Sense UI

Battery

  • benchmark

Capacity:

3300 mAh

Talk time:

28.00 hours
the average is 22 h (1323 min)

Stand-by time:

16.4 days (393 hours)
the average is 21 days (509 h)

Talk time (3G):

25.00 hours
the average is 23 h (1397 min)

Stand-by time (3G):

24.4 days (585 hours)
the average is 28 days (669 h)

Cellular

LTE (FDD):

Bands 3, 7, 8, 18

UMTS:

900, 1900, 2100 MHz

GSM:

850, 900, 1800, 1900 MHz

Data:

LTE, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS

SIM type:

Micro SIM

Connectivity

Bluetooth:

4.0

Wi-Fi:

802.11 a, b, g, n, ac, dual-band

USB:

USB 2.0

Connector:

microUSB

Features:

Mass storage device, USB charging, Video out

HDMI:

Yes

Location:

GPS, A-GPS, Glonass

Other:

NFC, Infrared, Tethering, Computer sync, OTA sync

Phone features

Sensors:

Accelerometer, Gyroscope, Compass

Notifications:

Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone

Other features:

Voice dialing, Voice commands, Voice recording

Multimedia

  • benchmark

Screen mirroring:

DLNA, MHL, TV-out

Radio:

FM, Stereo, RDS

Speakers:

Earpiece, Multiple speakers

Headphones connector:

3.5mm

Regulatory Approval

FCC approval:

Date approved:

Sep 30, 2013

FCC ID value:

NM80P3P100 link

FCC measured SAR:

Head:

0.95 W/kg

Body:

0.51 W/kg

Simultaneous Transmission:

1.58 W/kg

Wireless Router:

0.51 W/kg

This device is also known as HTC T6

ALTERNATIVE VARIANTS

We list only the specs that are different than the main variant

HTC One max

with 16 GB storage

Differences from the main variant:

Internal storage:

16 GB

HTC One max

for Asia

Differences from the main variant:

LTE (FDD):

Bands 1, 3, 7, 8

UMTS:

850, 900, 1900, 2100 MHz

HTC One max

for Sprint

Differences from the main variant:

LTE (FDD):

Bands 25, 26

LTE (TDD):

Bands 41

UMTS:

1900, 2100 MHz

GSM:

850, 900, 1800, 1900 MHz

CDMA:

800, 1900 MHz

Data:

LTE, HSDPA 14.4 Mbit/s, UMTS

HTC One max

for Verizon Wireless

Differences from the main variant:

LTE (FDD):

Bands 4, 13

UMTS:

850, 900, 1900, 2100 MHz

GSM:

850, 900, 1800, 1900 MHz

CDMA:

800, 1900 MHz

Data:

LTE, HSDPA 14.4 Mbit/s, UMTS

HTC One max

Dual SIM support

Differences from the main variant:

Dual SIM:

Yes

US CARRIER AVAILABILITY

Discontinued

Pros

  • Large camera sensor pixel size (2 μm)

Cons

  • Thick body (0.41 inches)
  • Too little RAM
  • Low pixel density screen (373 ppi)

Description

Clad in an aluminum body, the HTC One Max looks like a natural addition to the One and One mini - three's a family, and now HTC has most every market niche covered. It's not a unibody design, though, so thankfully you can pry off the battery cover and add a microSD card for more storage to load all those movies you are going to carry. The battery compartment is sealed, but it's a 3300 mAh unit, so no sweat, at least until we do the first battery tests. The phablet is not for the faint of heart, though, as with its 164.5 x 82.5 x 10.29 mm dimensions and 217g of weight, it is one "supersized" handset, as HTC itself is calling it in the description. You get your excellent BoomSound speakers at the front, but the back strays away from the One portfolio design paradigm, adding a flat and square fingerprint scanner, which can unlock your handset or start up to three favorite applications immediately upon touching it with three different fingerprints - a pretty svelte idea.
