Posted: 19 Oct 2011 Announced: 19 Oct 2011
Market Status: Released
Release date: 23 Oct 2011
Do you ...?
Want it27 Have it11 Had it4
US carrier availability: Sprint - Available (Since 23 Oct 2011) Boost Mobile - Upcoming Expected release date: 31 May 2012
Links: HTC EVO Design 4G manual HTC EVO Design 4G Review

Sprint's HTC EVO Design 4G brings 4G WiMAX speeds at a relatively affordable price. It doesn't compensate on sheer processing power, though, as the 4-inch qHD device comes with a single-core 1.2GHz processor. On the back, there's a 5-megapixel camera capable of recording 720p videos. Finally, this all runs on Android Gingerbread, skinned with HTC Sense.

Rating

Good 8 out of 10

Excellent 9.3 out of 10

Show Full Specs Compare

HTC EVO Design 4G specifications

also known as HTC Hero 4G, HTC Kingdom

Pros

Dual-mode CDMA/GSM phone
Fast mobile data support (4G)
High pixel densitiy screen, over 250ppi (275 ppi)
High-resolution display (540 x 960 pixels)
Very fast processor (1200 MHz)
Lots of RAM (768 MB RAM)

Cons

No cons

Design

Device type:
- Smart phone
OS:
- Android (2.3.3)
Form factor:
Form factor - Refers to the form factor of a phone. The main handset designs are bar, clamshell, slide, swivel
- Candybar
Dimensions:
- 4.80 x 2.40 x 0.50 (122 x 61 x 13 mm)
Weight:
- 5.20 oz (147 g)
  the average is 4.2 oz (120 g)

Display

Physical size:
- 4.00 inches
Resolution:
- 540 x 960 pixels
Pixel density:
Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.
- 275 ppi
Technology:
Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.
- S-LCD
Colors:
Colors - Shows the number of colors that the display supports
- 16 777 216
Touchscreen:
- - Capacitive, Multi-touch
Features:
- Light sensor, Proximity sensor

Battery

Talk time:
Talk time - Maximum talk time in hours
- 6.00 hours
  the average is 8 h (496 min)
Capacity:
- 1520 mAh

Hardware

System chip:
System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.
- Qualcomm MSM8665
Processor:
Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.
- Single core, 1200 MHz
Graphics processor:
- - Yes
System memory:
System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.
- 768 MB RAM
Built-in storage:
- 4000 MB
Storage expansion:
- Slot Type:
  - microSD, microSDHC
- Maximum card size:
  Maximum card size - Shows the capacity of the memory expansion slot that can be added
  - 32 GB

Camera

Camera:
- - 5 megapixels
- Features:
  - Auto focus
Camcorder:
- - 1280x720 (720p HD) (30 fps)
- Features:
  - Video calling
Front-facing camera:
- 1.3 megapixels

Multimedia

Radio:
- - FM, FM Transmiter
YouTube player:
- Yes

Internet browsing

Browser:
- - Yes
- Supports:
  - HTML, XHTML, Flash

Technology

CDMA:
CDMA - Code Division Multiple Access. A technique of multiplexing, also called spread spectrum, in which analog signals are converted into digital form for transmission. For each communication channel, the signals are encoded in a sequence known to the transmitter and the receiver for that channel. The foremost application is digital cellular phone technology from QUALCOMM that operates in the 800MHz band and 1.9GHz PCS band. CDMA phones are noted for their excellent call quality and long battery life.
- 800, 1900 MHz
GSM:
GSM - Global System for Mobile communications. A world standard for digital cellular communications using narrowband TDMA (Time Division Multiple Access), which allows up to eight calls at a time on 800 MHz and 1800 MHz frequencies. Introduced in 1991. Is the standard most commonly used in Europe and Asia, but not in the United States. GSM phones use a Subscriber Identity Module (SIM) smart card that contains user account information. Any GSM phone becomes immediately programmed after plugging in the SIM card, thus allowing GSM phones to be easily rented or borrowed.
- 850, 900, 1800, 1900 MHz
UMTS:
UMTS - Universal Mobile Telecommunications Service, also called WCDMA, is a 3G (Third Generation) packet-based transmission of text, digitized voice, video, and multimedia at data rates up to 2 Mbps. It is based on GSM standard and is supported by major standards bodies and manufacturers
- 2100 MHz
Data:
Data - Shows the particular phone's type of data. the major mobile phone data types are GPRS, CDMA2000 1xRTT, EDGE, CDMA2000 1xEV-DO, UMTS, etc.
- UMTS, EDGE, EV-DO Rev.A, WiMAX
Positioning:
Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.
- GPS
Navigation:
- Yes

Phone features

Phonebook:
- Unlimited entries, Caller groups, Multiple numbers per contact, Search by both first and last name, Picture ID, Ring ID
Organizer:
- Calendar, Alarm, Calculator
Messaging:
- SMS, MMS, Threaded view, Predictive text input
E-mail:
- - IMAP, POP3, SMTP, Microsoft Exchange

Connectivity

Bluetooth:
- - 3.0
Wi-Fi:
Wi-Fi - Wireless Local Area Network (WLAN) - used radio waves (RF) or infrared signals to send and receive data over the air. Most popular WLAN solutions today is Wi-Fi (802.11b and 802.11g) standards. 801.11b provides data speeds of around 11mbps while 802.11g can go up to 54 mbps.
- - 802.11 b, g, n
- Mobile hotspot:
  - Yes
USB:
- - USB 2.0
- Connector:
  - microUSB
- Features:
  Features - Universal Serial Bus - is a plug-and-play interface for connection a computer and add-on devices such as joysticks, keyboards, wireless phones, scanner, cameras etc. USB supports hot-swap (ability to add a new device without having to reboot the computer). USB supports data speed of 12 megabits per second.
  - Mass storage device, USB charging
- DLNA, Computer sync, OTA sync

Other features

Notifications:
- Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
Sensors:
- - Accelerometer, Compass
Hearing aid compatibility:
- - M4, T4
- Voice recording, TTY/TDD

Availability

Officially announced:
- 19 Oct 2011

Shopping information

Accessories:
- Standard Lithium Ion Battery, AC Charger, 8GB MicroSD card (inserted), Micro USB Cable, SIM Card (inserted)
MSRP price:
- - 400 $

To see the full specifications with in-depth details click here.

Despite our efforts to provide full and correct HTC EVO Design 4G specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please LET US KNOW.
