HTC Merge

Posted:
Sep 21, 2010
Market status:
Released
Release date:
Apr 07, 2011

HTC Merge

Posted: Sep 21, 2010
Market status: Released
Release date: Apr 07, 2011
  • Display 3.8" 480 x 800 pixels
  • Camera 5 MP
  • Processor Qualcomm Snapdragon S2, Single core, 800 MHz
  • Storage 2 GB
  • Battery 1400 mAh
  • Fingerprint
  • Lightweight
  • Thin
  • LTE
  • Waterproof
  • NFC
  • Dual SIM

Display

Display size:

3.8 inches

Resolution:

480 x 800 pixels

Pixel density:

246 ppi

Technology:

S-LCD

Screen-to-body ratio:

55.88 %

Features:

Ambient light sensor, Proximity sensor

Camera

Rear:

Single camera

Main camera:

5 megapixels

Hardware Features:

Autofocus

Flash:

LED

Video recording:

1280x720 (HD)

Design

Dimensions:

4.75 x 2.40 x 0.54 inches (121 x 61 x 14 mm)

Weight:

6.98 oz (198 g)
the average is 6 oz (172 g)

Features:

Full keyboard

Hardware & Performance

System chip:

Qualcomm Snapdragon S2 MSM7630

Processor:

Single core, 800 MHz, Scorpion

GPU:

Adreno 205

RAM:

0.5 GB

Internal storage:

2 GB

OS:

Android (2.3, 2.2)

Battery

Capacity:

1400 mAh

Talk time:

6.30 hours
the average is 21 h (1278 min)

Stand-by time:

13.8 days (330 hours)
the average is 21 days (499 h)

Cellular

CDMA:

800, 1900 MHz

GSM:

850, 900, 1800, 1900 MHz

UMTS:

2100 MHz

Data:

HSPA, UMTS

Connectivity

Bluetooth:

2.1

Wi-Fi:

802.11 b, g, n

USB:

USB 2.0

Connector:

microUSB

Features:

Mass storage device, USB charging

Location:

GPS

Other:

Computer sync, OTA sync

Phone features

Sensors:

Accelerometer, Compass

Notifications:

Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone

Hearing aid compatibility:

M4, T4

Other features:

Voice dialing, Voice recording, TTY/TDD

Multimedia

Headphones connector:

3.5mm

Regulatory Approval

FCC approval:

Date approved:

Sep 04, 2010

FCC ID value:

NM8PD42100 link

FCC measured SAR:

Head:

0.72 W/kg

Measured in:

1900 MHz

Body:

0.49 W/kg

Measured in:

1900 MHz

Shopping information

MSRP price:

$ 150

This device is also known as HTC Lexikon, HTC ADR6325

US CARRIER AVAILABILITY

Discontinued

Pros

  • Hardware QWERTY keyboard

Cons

  • Thick body (0.54 inches)
  • No front-facing camera
  • Too little RAM
  • Low pixel density screen (246 ppi)

Description

HTC Merge is a CDMA/GSM hybrid running Android 2.2 Froyo with HTC Sense user interface, has a slide-out QWERTY keyboard, 3.8" 480x800 resolution capacitive display, and a 5MP autofocus camera with LED flash and 720p video recording.
