HTC Magician

Posted:
Dec 15, 2004
Market status:
Released

HTC Magician

Posted: Dec 15, 2004
Market status: Released
  • Display 240 x 320 pixels
  • Camera 1.3 MP
  • Battery 1200 mAh
  • Fingerprint
  • Lightweight
  • Thin
  • LTE
  • Waterproof
  • NFC
  • Dual SIM

Display

Resolution:

240 x 320 pixels

Technology:

TFT

Camera

Rear:

Single camera

Main camera:

1.3 megapixels

Hardware Features:

Mirror, CMOS image sensor

Video recording:

Yes

Design

Dimensions:

4.20 x 2.30 x 0.72 inches (105 x 58 x 18 mm)

Weight:

5.30 oz (150 g)
the average is 6 oz (171 g)

Features:

Stylus, Soft keys

Hardware & Performance

Processor:

Single core, 416 MHz, Intel PXA270 XScale

RAM:

0.06 GB

ROM:

64 MB

OS:

Windows Mobile Professional (2003 SE)

Battery

Capacity:

1200 mAh

Talk time:

5.00 hours
the average is 22 h (1297 min)

Stand-by time:

7.9 days (190 hours)
the average is 20 days (490 h)

Cellular

GSM:

850, 1800, 1900 MHz

Connectivity

Bluetooth:

1.2

USB:

Yes

Connector:

miniUSB

Other:

Infrared, Computer sync

Phone features

Notifications:

Notification light, Polyphonic ringtones (40 voices), Vibration, Phone profiles, Speakerphone

Other features:

Voice recording

Regulatory Approval

FCC approval:

Date approved:

Feb 03, 2005

FCC ID value:

NM8MAGICIAN link

FCC measured SAR:

Head:

0.53 W/kg

Measured in:

1900 MHz

Body:

0.30 W/kg

Measured in:

1900 MHz

This device is also known as i-mate JAM, T-Mobile MDA Compact, O2 xda II mini

Pros

No Pros

Cons

  • Lacks Wi-Fi
  • The touchscreen uses resistive technology, which is not responsive
  • Thick body (0.72 inches)
  • The camera lacks autofocus
  • The camera lacks flash
  • Does not support automatic screen brightness
  • No front-facing camera
  • Too little RAM
  • Lacks GPS

Description

HTC Magician / MDA Compact is a tri-band GSM. It features 65k TFT display, 1.3 megapixels camera with MPEG4 video capture Bluetooth, IMAP / POP3 / SMTP e-mail, WAP 2.0 Internet browser, Intel PXA270 Xscale 416 MHz Processor and Touch screen.
