OnePlus One

Announced
Apr 23, 2014
Market status
Released

Pros

  • Big display (5.5 inches)
  • High pixel density screen (401 ppi)
  • Lots of RAM (3072 MB RAM)
  • Fast mobile data support (4G)

Cons

  • Lacks microSD slot for storage expansion

Share

embed

Description

The OnePlus One sports the most powerful bin of Qualcomm's quad-core Snapdragon 801 (MSM8974-AC), clocked at 2.5GHz, 3GB of LPDDR3 RAM, and a 3100 mAh cell. Connectivity options include 4G LTE, 2.4G/5G Wi-Fi, and Bluetooth 4.0. Wrapped within a magnesium chassis, the One is a relatively compact 5.5-incher, measuring 152.9 x 75.9 x 8.9 mm, and weighing just 162 grams. The 1080x1920 pixel resolution screen is literally slapped on top of the chassis, so the top and bottom bezels are actually recessed. At the back we have a 13-megapixel Sony IMX214 sensor with 6 lenses and a wide, f/2.0 aperture. Lastly, the OnePlus One is powered by a customized version of CyanogenMod OS, which has been redesigned with a minimal, completely flat UI.

Do you ...?




Compare

Design

  • Device type:
    • Smart phone
  • OS:
    • PopupAndroid (6.0, 5.1, 4.4.4, 4.4) CyanogenMod UI
  • Dimensions:
    • 6.02 x 2.99 x 0.35 inches (152.9 x 75.9 x 8.9 mm)
  • Weight:
    • 5.71 oz (162 g)
      the average is 5.3 oz (151 g)
  • Colors:
    • White

Displaybenchmark

  • Physical size:
    • 5.5 inches
  • Resolution:
    • 1080 x 1920 pixels
  • Pixel density:

    Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.

    • 401 ppi
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • IPS LCD
  • Screen-to-body ratio:
    • 71.81 %
  • Features:
    • Light sensor, Proximity sensor, Scratch-resistant glass (Corning Gorilla Glass 3)

Camerabenchmark

  • Camera:
      • Popup13 megapixels
    • Flash:
      • Dual LED
    • Aperture size:

      Aperture size - The aperture of a camera is the opening through which light travels before it reaches the camera sensor. The smaller the number is, the bigger this opening is, allowing for more light to pass.

      • F2.0
    • Camera sensor size:
      • 1/3.06"
    • Features:
      • Self-timer, CMOS image sensor, Autofocus, Touch to focus, Geo tagging
    • Settings:
      • Exposure compensation, ISO control, White balance presets, Shutter speed control
    • Shooting Modes:
      • PopupHigh Dynamic Range mode (HDR), Panorama, RAW image capture, Night mode, Scenes, Effects
  • Camcorder:
      • 3840x2160 (4K), 1920x1080 (1080p HD), 1280x720 (720p HD) (120 fps)
    • Features:
      • Time-lapse video, Continuous autofocus, Video calling, Video sharing
  • Front-facing camera:
      • 5 megapixels

Hardwarebenchmark

  • System chip:

    System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.

    • Qualcomm Snapdragon 801 8974-AC
  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Quad-core, 2500 MHz, Krait 400
  • Graphics processor:
      • Adreno 330
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 3072 MB RAM
  • Built-in storage:
    • 64 GB
  • Maximum User Storage:
    • 55 GB

Batterybenchmark

  • Capacity:
    • 3100 mAh
  • Not user replaceable:
    • Yes

MultimediaPopupbenchmark

  • Music player:
    • Filter by:
      • Album, Artist, Playlists
    • Features:
      • Album art cover, Background playback
  • Speakers:
    • Earpiece, Stereo speakers

Technology

  • GSM:
    • 850, 900, 1800, 1900 MHz
  • UMTS:
    • 850, 900, 1700/2100, 1900, 2100 MHz
  • FDD LTE:
    • 700 (band 17), 1700/2100 (band 4), 1800 (band 3), 2100 (band 1), 2600 (band 7) MHz
  • TDD LTE:
    • 2300 (band 40), 2600 (band 38) MHz
  • Data:
    • LTE, UMTS
  • Micro SIM:
    • Yes
  • Positioning:

    Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.

    • GPS, A-GPS, Glonass
  • Navigation:
    • Yes

Connectivity

  • Bluetooth:
      • 4.0
  • Wi-Fi:
      • 802.11 a, b, g, n, ac, dual-band
    • Mobile hotspot:
      • Yes
  • USB:
      • USB 2.0
    • Connector:
      • microUSB
    • Features:
      • Mass storage device, USB Host, USB charging
  • Other:
    • NFC, DLNA, Tethering, Computer sync, OTA sync
specifications continue after the ad

Other features

  • Notifications:
    • Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
  • Additional microphone(s):
      • for Noise cancellation
  • Sensors:
      • Accelerometer, Gyroscope, Compass, Gesture
    • Voice dialing, Voice commands, Voice recording

Availability

  • Officially announced:
    • 23 Apr 2014

Shopping information

  • MSRP price:
    • $ 349

Regulatory Approval

  • FCC approval:

    FCC approval - The Federal Communications Commission (FCC) is an independent United States government agency, directly responsible to Congress. The FCC was established by the Communications Act of 1934 and is charged with regulating interstate and international communications by radio, television, wire, satellite and cable. The FCC's jurisdiction covers the 50 states, the District of Columbia, and U.S. possessions. Every wireless phone device that is sold in the U.S. has to be tested and approved for sale by the FCC.

    • Date approved:

      Date approved - Shows the date when the particular phone is approved by the Federal Communications Commission

      • 09 May 2014
      • FCC ID value:

        FCC ID value - Shows the FCC Identifying value of the particular phone

        2ABZ2-A0001 link
  • FCC measured SAR:

    FCC measured SAR - Working closely with federal health and safety agencies, such as the Food and Drug Administration (FDA), the FCC has adopted limits for safe exposure to radiofrequency (RF) energy. These limits are given in terms of a unit referred to as the Specific Absorption Rate (SAR), which is a measure of the amount of radio frequency energy absorbed by the body when using a mobile phone. The FCC requires cell phone manufacturers to ensure that their phones comply with these objective limits for safe exposure. Any cell phone at or below these SAR levels (that is, any phone legally sold in the U.S.) is a "safe" phone, as measured by these standards. The FCC limit for public exposure from cellular telephones is an SAR level of 1.6 watts per kilogram (1.6 W/kg).

    • Head:
      • 0.35 W/kg
    • Body:
      • 0.80 W/kg
    • Simultaneous Transmission:
      • 1.00 W/kg

To see the full specifications with in-depth details click here.


Alternative variants

We list only the specs that are different than the main variant

OnePlus One 16GB

differences:

  • Colors:
    • Black
  • Built-in storage:
    • 16 GB
  • MSRP price:
    • $ 299

Despite our efforts to provide full and correct OnePlus One specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.


If you are interested in using our specs commercially, check out our Phone specs database licensing page.
