Display
Size:
6.2 inches
6.2 inches
Resolution:
2960 x 1440 pixels, 18.5:9 ratio, 529 PPI
2960 x 1440 pixels, 18.5:9 ratio, 531 PPI
Technology:
Super AMOLED
Super AMOLED
Screen-to-body:
83.32 %
83.68 %
Features:
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
Hardware
System chip:
Qualcomm Snapdragon 835 MSM8998 (10 nm)
Qualcomm Snapdragon 845 SDM845 (10 nm)
Processor:
Octa-core, 2450 MHz, Kryo 280, 64-bit
Octa-core, 2800 MHz, Kryo 385, 64-bit
GPU:
Adreno 540
Adreno 630
RAM:
4GB LPDDR4
6GB LPDDR4
Internal storage:
64GB
64GB
Storage expansion:
microSDXC up to 256 GB
microSDXC up to 400 GB
Device type:
Smartphone
Smartphone
OS:
Android (9.0 Pie, 8.0 Oreo, 7.0 Nougat), Samsung One UI
Android (10, 9.0 Pie, 8.0 Oreo), Samsung One UI
Battery
Capacity:
3500 mAh
3500 mAh
Type:
Li - Ion, Not user replaceable
Li - Ion, Not user replaceable
Charging:
Qualcomm Quick Charge 2.0, Qi and Powermat wireless charging
Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging
Camera
Rear:
Single camera
Dual camera
Main camera:
12 MP (OIS, PDAF)
12 MP (OIS, PDAF)
Specifications:
Aperture size: F1.7; Focal length: 26 mm; Sensor size: 1/2.55"; Pixel size: 1.4 μm
Aperture size: F1.5/F2.4; Focal length: 26 mm; Sensor size: 1/2.55"; Pixel size: 1.4 μm
Second camera:
12 MP (Telephoto, OIS, Autofocus)
Specifications:
Optical zoom: 2.0x; Aperture size: F2.4; Focal Length: 52 mm; Sensor size: 1/3.6"; Pixel size: 1 μm
Video recording:
3840x2160 (4K UHD) (30 fps), 2560x1440 (QHD), 1920x1080 (Full HD) (60 fps), 1280x720 (HD) (240 fps)
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Features:
HDR, Time-lapse video, Hyperlapse, Continuous autofocus, Object tracking, Picture-taking during video recording, Video light, EIS, Video calling, Video sharing
HDR, Time-lapse video, Hyperlapse, Continuous autofocus, Object tracking, Picture-taking during video recording, EIS, Video calling, Video sharing
Front:
8 MP (Wide Angle, Autofocus, HDR)
8 MP (Autofocus, HDR)
Video capture:
2560x1440 (QHD) (30 fps)
2560x1440 (QHD) (30 fps)
Design
Dimensions:
6.28 x 2.89 x 0.32 inches (159.5 x 73.4 x 8.1 mm)
6.22 x 2.91 x 0.33 inches (158.1 x 73.8 x 8.5 mm)
Weight:
6.10 oz (173.0 g)
6.67 oz (189.0 g)
Materials:
Back: Glass (Corning Gorilla Glass 5); Frame: Aluminum
Back: Glass (Corning Gorilla Glass 5); Frame: Aluminum
Resistance:
Water, Dust; IP68
Water, Dust; IP68
Biometrics:
Iris scanner, 2D Face unlock, Fingerprint (touch)
Iris scanner, 2D Face unlock, Fingerprint (touch)
Features:
Notification light
Keys:
Left: Volume control, Other; Right: Lock/Unlock key
Left: Volume control, Other; Right: Lock/Unlock key
Colors:
Midnight black, Orchid gray, Arctic silver, Coral blue, Maple gold, Rose pink
Midnight black, Coral blue, Titanium gray, Lilac purple, Burgundy red, Sunrise gold, Ice blue, Polaris blue
Cellular
4G (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD):
Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46
3G:
Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Data Speed:
LTE-A Pro Cat 16 (1000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA
SIM type:
Nano SIM
Nano SIM
HD Voice:
Yes
Multimedia
Headphones:
3.5mm jack
3.5mm jack
Speakers:
Earpiece, Loudspeaker
Earpiece, Multiple speakers
Features:
Album art cover, Background playback
32-Bit DAC, Dolby Atmos, aptX-HD
Screen mirroring:
DLNA, Wireless screen share, MHL
Wireless screen share
Radio:
FM
Additional microphone(s):
for Noise cancellation
for Noise cancellation
Connectivity & Features
Bluetooth:
5.0, EDR
5.0
Wi-Fi:
802.11 a, b, g, n, ac, dual-band; MIMO, Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, dual-band; MIMO, Wi-Fi Direct, Hotspot
USB:
Type-C (reversible), USB 3.1
Type-C (reversible), USB 3.1
Features:
Charging, Mass storage device
Charging, OTG, Video out
Location:
GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
GPS, A-GPS, Glonass, Galileo, BeiDou
Sensors:
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other:
NFC, ANT+, UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync
NFC, ANT+
Hearing aid compatible:
M3, T3
Regulatory Approval
FCC approval:
Date approved:
Apr 06, 2017
Jan 11, 2018
FCC ID value:
A3LSMG955U
A3LSMG965U
Measured SAR:
Head:
0.33 W/kg
0.36 W/kg
Body:
0.29 W/kg
0.79 W/kg
Simultaneous Transmission:
1.55 W/kg
1.59 W/kg
Wireless Router:
0.19 W/kg
1.04 W/kg
Phablet:
3.94 W/kg
Buyers information
Price:
$ 840
Availability
Officially announced:
Mar 29, 2017
Feb 25, 2018
