Display
Size:
6.8 inches
6.5 inches
Resolution:
3168 x 1440 pixels, 19.8:9 ratio, 513 PPI
2400 x 1080 pixels, 20:9 ratio, 402 PPI
Technology:
AMOLED
AMOLED
Refresh rate:
120Hz
90Hz
Screen-to-body:
90.79 %
88.65 %
Peak brightness:
1300 cd/m2 (nit)
1100 cd/m2 (nit)
Features:
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
Hardware
System chip:
Qualcomm Snapdragon 865 SM8250 (7 nm)
Qualcomm Snapdragon 865 SM8250 (7 nm)
Processor:
Octa-core, 2840 MHz, Kryo 585, 64-bit
Octa-core, 2840 MHz, Kryo 585, 64-bit
GPU:
Adreno 650
Adreno 650
RAM:
8GB LPDDR5
8GB LPDDR4
Internal storage:
128GB (UFS 3.0), not expandable
128GB (UFS 3.0), not expandable
Device type:
Smartphone
Smartphone
OS:
Android (11, 10), Oxygen OS UI
Android (11, 10)
Battery
Capacity:
4510 mAh
4300 mAh
Type:
Li - Polymer, Not user replaceable
Li - Polymer, Not user replaceable
Charging:
OnePlus Warp Charge, Qi wireless charging, Reverse wireless charging
OnePlus Warp Charge
Max charge speed:
Wired: 30.0W; Wireless: 30.0W
Wired: 30.0W
Camera
Rear:
Quad camera
Triple camera
Main camera:
48 MP (OIS, Laser and PDAF)
48 MP (OIS, PDAF)
Specifications:
Aperture size: F1.8; Focal length: 25 mm; Sensor size: 1/1.4"; Pixel size: 1.12 μm
Aperture size: F1.8; Focal length: 25 mm; Sensor size: 1/2"; Pixel size: 0.8 μm
Second camera:
8 MP (Telephoto, OIS, Laser and PDAF)
16 MP (Ultra-wide, PDAF)
Specifications:
Optical zoom: 3.0x; Aperture size: F2.4; Sensor size: 1/2"; Pixel size: 1 μm
Aperture size: F2.2; Focal Length: 14 mm
Third camera:
48 MP (Ultra-wide, PDAF)
2 MP (Macro)
Specifications:
Aperture size: F2.2; Focal Length: 14 mm; Sensor size: 1/2"; Pixel size: 0.8 μm
Aperture size: F2.4; Pixel size: 1.75 μm
Fourth camera:
5 MP (Color filter)
Specifications:
Aperture size: F2.4
Video recording:
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (480 fps)
3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (480 fps)
Features:
OIS, HDR, EIS
OIS, HDR, Time-lapse video, EIS
Front:
16 MP (EIS, HDR)
16 MP (EIS, HDR)
Video capture:
1920x1080 (Full HD)
1920x1080 (Full HD)
Design
Dimensions:
6.51 x 2.93 x 0.33 inches (165.3 x 74.3 x 8.5 mm)
6.31 x 2.87 x 0.31 inches (160.2 x 72.9 x 8 mm)
Weight:
7.02 oz (199.0 g)
6.35 oz (180.0 g)
Materials:
Back: Glass (Corning Gorilla Glass 5); Frame: Aluminum
Back: Glass (Corning Gorilla Glass 5); Frame: Aluminum
Biometrics:
2D Face unlock, In-screen fingerprint
2D Face unlock, In-screen fingerprint
Keys:
Left: Volume control; Right: Lock/Unlock key
Left: Volume control; Right: Lock/Unlock key
Colors:
Glacial green
Glacial green
Cellular
5G:
n2, n5, n41, n66, n71, SA, NSA
n2, n5, n41, n66, n71, SA, NSA
4G (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD):
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G:
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 6(800), 8(900)
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 6(800), 8(900)
Data Speed:
LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM:
Yes
Yes
SIM type:
Nano SIM
Nano SIM
Multimedia
Headphones:
No 3.5mm jack
No 3.5mm jack
Speakers:
Earpiece, Multiple speakers
Earpiece, Multiple speakers
Features:
Dolby Atmos, aptX-HD
Dolby Atmos, aptX-HD
Screen mirroring:
DLNA, Wireless screen share
DLNA, Wireless screen share
Additional microphone(s):
for Noise cancellation
for Noise cancellation
Connectivity & Features
Bluetooth:
5.1
5.1
Wi-Fi:
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
USB:
Type-C (reversible), USB 3.1
Type-C (reversible), USB 3.1
Features:
Charging, Headphones port, OTG
Charging, Headphones port, OTG
Location:
GPS, A-GPS, Glonass, Galileo, BeiDou, Dual-band positioning, Cell ID, Wi-Fi positioning
GPS, A-GPS, Glonass, Galileo, Dual-band positioning, Cell ID, Wi-Fi positioning
Sensors:
Accelerometer, Gyroscope, Compass
Accelerometer, Gyroscope, Compass
Other:
NFC
NFC
Regulatory Approval
FCC approval:
Date approved:
Oct 12, 2020
Jan 24, 2021
FCC ID value:
2ABZ2-EE007
2ABZ2-EE103
Measured SAR:
Head:
0.93 W/kg
1.01 W/kg
Body:
0.89 W/kg
0.78 W/kg
Simultaneous Transmission:
1.59 W/kg
1.59 W/kg
Wireless Router:
0.95 W/kg
0.92 W/kg
Buyers information
Price:
$ 899
$ 699
User Manual:
This is the official OnePlus 8 Pro User Guide in English provided from the manufacturer.
This is the official OnePlus 8 User Guide in English provided from the manufacturer.
In The Box:
Warp Charge 30 Power Adapter, Warp Type-C Cable (Support USB 2.0), Quick Start Guide, Welcome Letter, Safety Information and Warranty Card, LOGO Sticker, Case, Screen Protector, SIM Tray Ejector
Warp Charge 30 Power Adapter, Warp Type-C Cable (Support USB 2.0), Quick Start Guide, Welcome Letter, Safety Information and Warranty Card, LOGO Sticker, Screen Protector, SIM Tray Ejector
Availability
Officially announced:
Apr 14, 2020
Apr 14, 2020
