Apple iPhone 16 Pro Max vs Google Pixel 9 Pro Specs Comparison

Compare mobile phone specifications of up to three devices at once. Our specs comparison tool helps you find and compare the perfect phone for your needs.

8.0
Apple iPhone 16 Pro Max
7.3
Google Pixel 9 Pro
Apple iPhone 16 Pro Max Google Pixel 9 Pro
Released · Sep 20, 2024
Released · Sep 04, 2024
6.9-inch · 2868x1320px
6.3-inch · 2856x1280px
Triple camera
Triple camera
8GB · 256GB
16GB · 128GB
4685 mAh
4700 mAh
Check prices Check prices

Availability

Officially announced
Sep 09, 2024 Aug 13, 2024
MSRP
$ 1199 / € 1449 $ 999 / € 1229

Design

Dimensions
6.42 x 3.05 x 0.33 inches (~0.48 inches with camera bump)
163.0 x 77.6 x 8.25 mm (~12.25 mm with camera bump)
6.02 x 2.83 x 0.33 inches (~0.47 inches with camera bump)
152.8 x 72.0 x 8.5 mm (~12 mm with camera bump)
Weight
8.01 oz (227.0 g) 7.02 oz (199.0 g)
Materials
Back: Glass
Frame: Titanium
Back: Glass (Corning Gorilla Glass Victus)
Frame: Aluminum
Resistance
Water, Dust; IP68 Water, Dust; IP68
Biometrics
3D Face unlock Ultrasonic in-screen fingerprint
Keys
Left: Volume control, Other; Right: Lock/Unlock key, Other Right: Volume control, Lock/Unlock key
Colors
Black Titanium, White Titanium, Natural Titanium, Desert Titanium Obsidian, Porcelain, Hazel, Rose Quartz

Display

Size
6.9-inch, 92.35% screen-to-body 6.3-inch, 86.95% screen-to-body
Type
OLED, Variable 1-120Hz, HDR, 2000 nits OLED, 120Hz, HDR, 3000 nits
Resolution
2868x1320px, 19.5:9 ratio, 458 PPI 2856x1280px, 20:9 ratio, 497 PPI
Protection
Ceramic Shield Corning Gorilla Glass Victus 2
Features
Super Retina XDR, HDR support, Oleophobic coating, Scratch-resistant glass, Ambient light sensor, Proximity sensor

Hardware

System chip
Apple A18 Pro (3 nm) Google Tensor G4 (4 nm)
Processor
Hexa-core
2x4.05GHz
4x2.42G​Hz
Octa-core
1x3.1GHz Cortex-X4
3x2.6GH​z Cortex-A720
4x1.9​2GHz Cortex-A520
GPU
Apple 6-core GPU Mali-G715 MC7
Memory
8GB (LPDDR5)/256GB (NVMe)
8GB/512GB
8GB/1024GB
16GB (LPDDR5X)/128GB (UFS 3.1)
16GB/256GB
16GB/512GB
16GB/1024GB
Storage expansion
not expandable not expandable
OS
iOS (18.x) Android (15, 14)

Battery

Type
4685 mAh, Li - Ion 4700 mAh, Li - Ion
Charging
Fast charging
Qi2 wireless charging, Reverse wired charging, MagSafe wireless charging
Fast charging
Qi wireless charging, Reverse wireless charging
Charge speed
Wired: 27.0W
Wireless: 25.0W
Wired: 27.0W
Wireless: 21.0W
PhoneArena Battery Tests
Battery Life Estimate
8h 30min
Browsing
22h 39min
Video
10h 24min
Gaming
12h 4min
Battery Life Estimate
6h 53min
Browsing
17h 0min
Video
10h 11min
Gaming
7h 21min

Camera

Rear
Triple camera Triple camera
Main camera
48 MP (Sensor-shift OIS, PDAF)
Sensor name: Sony IMX903
Aperture size: F1.8
Focal length: 24 mm
Sensor size: 1/1.28"
Pixel size: 1.22 μm
50 MP (OIS, PDAF)
Sensor name: Samsung GNK
Aperture size: F1.7
Focal length: 25 mm
Sensor size: 1/1.31"
Pixel size: 1.2 μm
Second camera
48 MP (Ultra-wide)
Sensor name: Sony IMX972
Aperture size: F2.2
Focal Length: 13 mm
Sensor size: 1/3.06"
Pixel size: 0.7 μm
48 MP (Ultra-wide)
Sensor name: Sony IMX858
Aperture size: F1.7
Sensor size: 1/2.55"
Third camera
12 MP (Telephoto, Periscope, Sensor-shift OIS, PDAF)
Sensor name: Sony IMX913
Optical zoom: 5.0x
Aperture size: F2.8
Focal Length: 120 mm
Sensor size: 1/3.06"
Pixel size: 1.12 μm
48 MP (Telephoto)
Sensor name: Sony IMX858
Optical zoom: 5.0x
Aperture size: F2.8
Focal Length: 113 mm
Sensor size: 1/2.55"
Flash
Dual LED LED
Video recording
4K UHD (120 fps), 1080p (240 fps)
OIS, HDR, Continuous autofocus, Picture-taking during video recording, 10-bit HDR, Dolby Vision HDR, ProRes, Cinematic mode
4K UHD (60 fps), 1080p (240 fps)
Front
12 MP (Time-of-Flight (ToF), Autofocus, HDR)
Video capture: 4K UHD (60 fps)
42 MP (PDAF)
Video capture: 4K UHD (60 fps)
PhoneArena Camera Tests
154
Overall
158
150
Video
151
Overall
159
142
Video

Connectivity & Features

Bluetooth
5.3 5.3
WLAN
a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E,Wi-Fi 7
Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, ax
a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E,Wi-Fi 7
Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, ax
USB
Type-C, USB 3.2 Type-C, USB 3.2
Sensors
Accelerometer, Gyroscope, Compass, Barometer, Ambient light sensor, Proximity sensor Accelerometer, Gyroscope, Compass, Barometer, Emergency SOS via satellite (SMS sending/receiving), Ambient light sensor, Proximity sensor
Hearing aid compatible
M3/T4 M3/T4
Location
GPS, A-GPS, Glonass, Galileo, BeiDou, QZSS, NavIC, Cell ID, Wi-Fi positioning, Emergency SOS via satellite (SMS sending/receiving) GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Other
NFC, Ultra Wideband (UWB) NFC

Multimedia

Headphones
No 3.5mm jack No 3.5mm jack
Speakers
Earpiece, Multiple speakers Earpiece, Multiple speakers
Features
Dolby Atmos

Cellular

5G
Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, n258, n260, n261, SA, NSA, Sub-6, mmWave Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n258, n260, n261, mmWave
4G (FDD)
Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600) Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29(700 d), 30(2300 WCS), 66(AWS-3), 71(600)
4G (TDD)
Bands 34, 38, 39, 40, 41, 42, 46, 48 Bands 38, 40, 41, 48
3G
Bands 1, 2, 4, 5, 8 Bands 1, 2, 4, 5, 6, 8, 19
Data Speed
LTE-A Pro Cat 18 (1200/150 Mbit/s) LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
eSIM Nano SIM, eSIM
HD Voice
Yes
VoLTE
Yes

Regulatory Approval

FCC approval
Date approved: Sep 09, 2024
FCC ID value: BCG-E8684A
Measured SAR
Head: 0.96 W/kg
Body: 0.98 W/kg
Simultaneous Transmission: 0.99 W/kg

Alternative variants

With 512GB internal storage
Memory 512GB
MSRP $ 1399
With 256GB internal storage
Memory 256GB
MSRP $ 1099
With 1TB internal storage
Memory 1024GB
MSRP $ 1599
With 512GB internal storage
Memory 512GB
MSRP $ 1219
International
5G Bands n1, n2, n3, n5, n7, n8, n12, n14, n25, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD) Bands 34, 38, 39, 40, 41, 42, 48
With 1TB internal storage
Memory 1024GB
MSRP $ 1449
International
5G Bands n1, n2, n3, n5, n7, n8, n12, n14, n20, n25, n28, n30, n38, n40, n41, n66, n71, n75, n77, n78, n79, SA, NSA, Sub-6
4G (FDD) Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29(700 d), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
4G (TDD) Bands 38, 39, 40, 41, 42, 48
