T-Mobile REVVL

Full Specifications

Released · Aug 10, 2017

5.5-inch · 1280x720px

Be the first to review this phone

I want it 1 user

I have it 2 users

I had it 1 user

Popular Comparisons

The T-Mobile REVVL is most commonly compared with these phones:

Design
Dimensions	5.98 x 3.03 x 0.33 inches 151.9 x 77 x 8.4 mm
Weight	5.57 oz (158.0 g)
Materials	Back: Plastic
Biometrics	Fingerprint (touch)
Keys	Right: Volume control, Lock/Unlock key

Display
Size	5.5-inch
Resolution	1280x720px, 267 PPI
Technology	IPS LCD
Screen-to-body	71.34 %
Colors	16 777 216
Features	Ambient light sensor, Proximity sensor

Hardware
System chip	MediaTek MT6738 (28 nm)
Processor	Quad-core 1500 MHz ARM Cortex-A53
GPU	Mali-T860 MP2
RAM	2GB (LPDDR3)
Internal storage	32GB, available to use: 24 GB
Storage expansion	microSDXC up to 128 GB
OS	Android (7.0 Nougat)

Battery
Capacity	3000 mAh
Type	Li - Ion

Camera
Rear	Single camera
Main camera	13 MP (Autofocus)
Flash	LED
Video recording	1920x1080 (Full HD) Time-lapse video, Video calling, Video sharing
Front	5 MP (Wide Angle, Flash)

Connectivity & Features
Bluetooth	4.2
WLAN	802.11 b,g,n Wi-Fi Direct
USB	microUSB, USB 2.0
Hearing aid compatible	M4/T4
Location	GPS, A-GPS
Sensors	Accelerometer, Gesture
Other	UMA (Wi-Fi Calling), VoIP, Tethering, Computer sync, OTA sync

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Features	Album art cover, Background playback
Screen mirroring	Wireless screen share
Radio	FM

Cellular
4G (FDD)	Bands 2(1900), 4(AWS-1), 5(850), 12(700 a), 66(AWS-3)
3G	Bands 5(850), 8(900), 4(1700/2100), 2(1900)
Data Speed	LTE Cat 4 (150/50 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s
SIM type	Nano SIM
VoLTE	Yes

Phone Features
Notifications	Haptic feedback
Other features	Voice dialing, Voice commands, Voice recording, TTY/TDD

Regulatory Approval
FCC approval	Date approved: Jun 28, 2017 FCC ID value: 2ACCJB089
Measured SAR	Head: 0.20 W/kg Body: 1.28 W/kg Simultaneous Transmission: 1.38 W/kg Wireless Router: 1.28 W/kg

Buyers information
In The Box	Charger, USB Cable, Start Guide and Terms & Conditions

Availability
Officially announced	Aug 09, 2017
