Motorola Moto M

Full Specifications

Released · Nov 11, 2016

5.5-inch · 1920x1080px

Single camera

3050 mAh

4GB · 32GB

MediaTek Helio P15

Android 7.0 Nougat

6.5

Read Motorola Moto M Review

Be the first to review this phone

I want it 0 users

I have it 1 user

I had it 1 user

Popular Comparisons

The Motorola Moto M is most commonly compared with these phones:

•

  Motorola Moto M
  vs


  Karbonn K9 Viraat
•

  Motorola Moto M
  vs


  Google Pixel 8
•

  Motorola Moto M
  vs


  Samsung Galaxy S23
•

  Motorola Moto M
  vs


  Google Pixel 8 Pro
•

  Motorola Moto M
  vs


  Samsung Galaxy S23 Ultra

Design
Dimensions	5.96 x 2.97 x 0.31 inches 151.35 x 75.35 x 7.85 mm
Weight	5.75 oz (163.0 g)
Materials	Back: Metal
Resistance	Splash
Biometrics	Fingerprint (touch)
Keys	Right: Volume control, Lock/Unlock key
Colors	Gold, Gray, Silver

Display
Size	5.5-inch
Resolution	1920x1080px, 401 PPI
Technology	IPS LCD
Screen-to-body	73.02 %
Features	Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	7 (Poor)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	MediaTek Helio P15
Processor	Octa-core 2200 MHz ARM Cortex-A53
GPU	Mali-T860 MP2
RAM	4GB (LPDDR3)
Internal storage	32GB
Storage expansion	microSDXC up to 128 GB
OS	Android (7.0 Nougat, 6.0 Marshmallow)

Battery
Capacity	3050 mAh
Type	Li - Polymer
Charging	Fast charging

Camera
Rear	Single camera
Main camera	16 MP (PDAF) Aperture size: F2.0 Pixel size: 1 μm
Flash	Dual LED
Video recording	1920x1080 (Full HD) Video calling, Video sharing
Front	8 MP

Connectivity & Features
Bluetooth	4.1
Wi-Fi	802.11 a,b,g,n,ac,dual-band MIMO
USB	Type-C
Location	GPS, A-GPS, Glonass, BeiDou
Sensors	Accelerometer, Gyroscope, Compass
Other	Tethering, Computer sync, OTA sync

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Features	Dolby Atmos, Album art cover, Background playback
Screen mirroring	Wireless screen share
Additional microphone(s)	Yes

Cellular
4G (FDD)	Bands 1(2100), 3(1800), 5(850), 7(2600), 8(900), 20(800 DD)
4G (TDD)	Bands 38(2600), 40(2300), 41(2600+)
3G	Bands 5(850), 8(900), 2(1900), 1(2100)
Data Speed	LTE-A Cat 6 (300/50 Mbit/s), HSPA
Dual SIM	Yes
SIM type	Nano SIM
VoLTE	Yes

Availability
Officially announced	Nov 08, 2016
