Motorola Moto G5 Plus

Full Specifications

Released · Mar 31, 2017

5.2-inch · 1920x1080px

This device is also known as Motorola XT1687

8.0

Read Motorola Moto G5 Plus Review

8.5

Read All User Reviews (6)

I want it 6 users

I have it 13 users

I had it 9 users

Popular Comparisons

The Motorola Moto G5 Plus is most commonly compared with these phones:

Availability
Officially announced	Feb 26, 2017
Prices (MSRP)	$229

Design
Dimensions	5.91 x 2.91 x 0.38 inches 150.2 x 74 x 9.7 mm
Weight	5.47 oz / 155.0 g
Materials	Back: Aluminum Frame: Plastic
Resistance	Splash
Biometrics	Fingerprint (touch)
Keys	Right: Volume control, Lock/Unlock key
Colors	Gold, Gray

Display
Size	5.2-inch, 67.18% screen-to-body
Type	IPS LCD
Resolution	1920x1080px, 424 PPI
Protection	Corning Gorilla Glass 3

PhoneArena Display Test
Bright Max (20 APL)	Untested
Bright Min	6 (Poor)
Learn more on our PhoneArena Display Test Results page.

Hardware
System chip	Snapdragon 625 8953
Processor	Octa-core 2000 MHz ARM Cortex-A53
GPU	Adreno 506
Memory	4GB (LPDDR3)/64GB 2GB/32GB 3GB/32GB
Storage expansion	microSDXC up to 128 GB
OS	Android (8.1 Oreo, 7.0 Nougat)
This device has different variants: View all

Battery
Type	3000 mAh, Li - Ion
Charging	Fast charging

Camera
Rear	Single camera
Main camera	12 MP (PDAF) Aperture size: F1.7 Focal length: 26 mm Sensor size: 1/2.5" Pixel size: 1.4 μm
Flash	Dual LED
Video recording	4K UHD (30 fps) EIS, Video calling, Video sharing
Front	5 MP (Wide Angle)

Connectivity & Features
Bluetooth	4.2
WLAN	a,b,g,n,dual-band Wi-Fi Direct, Hotspot 802.11 a, b, g, n
USB	microUSB, USB 2.0
Sensors	Accelerometer, Gyroscope, Compass, Ambient light sensor, Proximity sensor
Location	GPS, A-GPS, Glonass
Other	UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync
This device has different variants: View all

Multimedia
Headphones	3.5mm jack
Speakers	Earpiece, Loudspeaker
Features	Album art cover, Background playback
Screen mirroring	Wireless screen share
Radio	FM
Additional microphone(s)	Yes

Cellular
4G (FDD) Bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 25, 26
4G (TDD) Bands	38, 41
3G Bands	5, 8, 4, 2, 1
Data Speed	LTE-A Cat 6 (300/50 Mbit/s), HSPA, UMTS
SIM type	Nano SIM
HD Voice	Yes
This device has different variants: View all

Alternative variants

Differences from the main variant:
Memory	2GB/32GB

no compass

Differences from the main variant:
Memory	3GB/32GB
4G (FDD) Bands	1, 4, 5, 7, 8, 19, 20, 29
4G (TDD) Bands	38, 41
3G Bands	5, 8, 2, 1
Other	NFC

Differences from the main variant:
Dual SIM	Yes

Despite our efforts to provide full and correct Motorola Moto G5 Plus specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.
