Samsung Galaxy S10 5G

Announced:
Feb 20, 2019
Market status:
Released
Release date:
May 16, 2019

Display

Display size:

6.7 inches

Resolution:

1440 x 3040 pixels

Pixel density:

502 ppi

Technology:

Dynamic AMOLED

Screen-to-body ratio:

89.26 %

Features:

HDR video support, Scratch-resistant glass (Corning Gorilla Glass 6), Ambient light sensor, Proximity sensor

Camera

Rear:

Quad camera

Main camera:

12 megapixels

Hardware Features:

Optical image stabilization, Phase detection autofocus

Specifications:

Aperture size: F1.5/F2.4; Focal length: 26 mm; Sensor size: 1/2.55"; Pixel size: 1.4 μm

Second camera:

12 megapixels

Hardware Features:

Telephoto, Optical image stabilization, Phase detection autofocus

Specifications:

Optical zoom: 2x; Aperture size: F2.4; Focal Length: 52 mm; Sensor size: 1/3.6"; Pixel size: 1 μm

Third camera:

16 megapixels

Hardware Features:

Ultra-wide

Specifications:

Aperture size: F2.2

Fourth camera:

Hardware Features:

Time-of-Flight (ToF)

Flash:

LED

Video recording:

3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)

Features:

High Dynamic Range mode (HDR), Time-lapse video, Digital image stabilization, Video calling, Video sharing

Front:

10 megapixels

Features:

Dual-Camera, Autofocus, High Dynamic Range mode (HDR)

Design

Dimensions:

6.40 x 3.04 x 0.31 inches (162.6 x 77.1 x 7.94 mm)

Weight:

6.98 oz (198 g)
the average is 6 oz (172 g)

Materials:

Back: Glass (Corning Gorilla Glass 6); Frame: Aluminum

Resistance:

Water, Dust; IP 68

Biometrics:

2D Face unlock, In-screen fingerprint

Colors:

Black, Silver

Multimedia

Headphones:

3.5 mm jack

Speakers:

Earpiece, Multiple speakers

Features:

Album art cover, Background playback, Dolby Atmos, Dolby Digital, Dolby Digital Plus

Screen mirroring:

Wireless screen share

Additional microphone(s):

for Noise cancellation

Hardware & Performance

System chip:

Qualcomm Snapdragon 855

Processor:

Octa-core, 2840 MHz, Kryo 485, 64-bit, 7 nm

GPU:

Adreno 640

RAM:

8 GB

Internal storage:

512 GB

OS:

Android (9.0 Pie), Samsung One UI

Connectivity & Features

Bluetooth:

5.0

Wi-Fi:

802.11 a, b, g, n, ac, ax, dual-band; MIMO, Hotspot, Wi-Fi Direct

USB:

USB 3.1

Connector:

USB Type-C (reversible)

Features:

Mass storage device, USB OTG

Location:

GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning

Sensors:

Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer

Mobile Payment:

Samsung Pay

Other:

NFC, ANT+, UMA (Wi-Fi Calling), VoIP, Tethering, Computer sync, OTA sync

Cellular

5G:

Bands n260, n261

LTE (FDD):

Bands 2, 3, 4, 5, 7, 8, 12, 13, 18, 19, 20, 26, 28, 66

LTE (TDD):

Bands 38, 39, 40, 41, 46, 48

UMTS:

850, 900, 1900, 2100 MHz

Data:

LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s

SIM type:

Nano SIM

HD Voice:

Yes

Battery

Capacity:

4500 mAh

Type:

Not user replaceable

Charging:

Qualcomm Quick Charge 2.0, USB Power Delivery, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging, Reverse wireless charging

Stand-by time:

15.5 days (372 hours)
the average is 19 days (457 h)

Internet use:

3G: 15 hours; LTE: 16 hours; Wi-Fi: 16 hours

Phone features

Notifications:

Haptic feedback, Music ringtones, Vibration

Other features:

Voice dialing, Voice commands, Voice recording

Regulatory Approval

FCC approval:

Date approved:

Apr 05, 2019

FCC ID value:

A3LSMG977U link

FCC measured SAR:

Head:

0.30 W/kg

Body:

1.11 W/kg

Simultaneous Transmission:

1.59 W/kg

Wireless Router:

1.39 W/kg

Phablet:

3.98 W/kg

Shopping information

In The Box:

Samsung special screen protector ( already on device ), Wall adapter/USB cable/USB connector, Quick reference guide, Important consumer safety information, Product safety, and warranty brochure

MSRP price:

$ 1400

ALTERNATIVE VARIANTS

We list only the specs that are different than the main variant

Samsung Galaxy S10 5G

with 256 GB storage

Differences from the main variant:

Internal storage:

256 GB

Maximum User Storage:

225 GB

MSRP price:

$ 1300

US CARRIER AVAILABILITY

Available

Pros

  • High screen-to-body ratio (89.26 %)
  • Optical camera zoom
  • Extremely high pixel density screen (502 ppi)
  • Lots of RAM (8 GB)
  • Large camera sensor pixel size (1.4 μm)
  • Big battery (4500 mAh)

Cons

No Cons

Description

The Galaxy S10 5G is Samsung's first smartphone made to work with the 5G cellular networks of the future. It comes with the same in-display fingerprint reader and Snapdragon 855 chip found in the Galaxy S10 but has a bigger, 6.7-inch OLED screen and a larger, 4500mAh battery. The four cameras at the back include a main, 12MP dual-aperture camera, a telephoto cam for 2x zoom, a third camera with a super wide-angle lens, and a fourth Time of Flight cam made for next-level depth perception. And at the front, tucked in a cutout in the corner, is a 10-megapixel camera with autofocus and 4K video capabilities.
