Samsung Fascinate

Jun 28, 2010
Market status
Release date
Sep 8, 2010

US carrier availability

Discontinued: Verizon, U.S. Cellular, Alltel


No pros


  • Low pixel density screen (233 ppi)
  • Single-core processor
  • Too little RAM memory (384 MB RAM)
  • Low resolution display (480 x 800 pixels)
  • Low-resolution camera (5 megapixels)
  • No front-facing camera




Samsung Galaxy S Fascinate looks very similar to the Samsung Beam. It utilizes a large 4-inch WVGA Super AMOLED screen, a 1GHz processor and the Android 2.1 operating system. The camera is 5MP with option for 720p HD video recording at 30 frames per second. Other goodies include 3G, Wi-Fi, A-GPS, HD video playback, as well as playback for many other formats like FLAC, and MKV.

Do you ...?

Unlock this phone Compare


  • Device type:
    • Smart phone
  • OS:
    • Android (2.3, 2.2, 2.1)
  • Dimensions:
    • 4.92 x 2.53 x 0.39 inches (125 x 64 x 10 mm)
  • Weight:
    • 4.16 oz (118 g)
      the average is 5.1 oz (145 g)


  • Physical size:
    • 4.0 inches
  • Resolution:
    • 480 x 800 pixels
  • Pixel density:

    Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.

    • 233 ppi
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • Super AMOLED
  • Screen-to-body ratio:
    • 56.71 %
  • Colors:
    • 16 777 216
  • Touchscreen:
      • Multi-touch
  • Features:
    • Light sensor, Proximity sensor, Scratch-resistant glass (Corning Gorilla Glass)


  • Camera:
      • 5 megapixels
    • Flash:
      • LED
    • Features:
      • Autofocus, Smile detection, Digital zoom, Self-timer
    • Settings:
      • ISO control
    • Shooting Modes:
      • Burst mode, Panorama, Effects
  • Camcorder:
      • 1280x720 (720p HD) (30 fps)


  • System chip:

    System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.

    • Samsung Exynos 3
  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Single core, 1000 MHz, ARM Cortex-A8
  • Graphics processor:
      • PowerVR SGX540
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 384 MB RAM / 512 MB ROM
  • Built-in storage:
    • 2 GB
  • Storage expansion:
    • microSD, microSDHC up to 32 GB


  • Talk time:
    • 7.00 hours
      the average is 13 h (799 min)
  • Stand-by time:
    • 13.0 days (312 hours)
      the average is 18 days (420 h)
  • Capacity:
    • 1500 mAh


  • YouTube player:
    • Yes

Internet browsing

  • Built-in online services support:
    • Facebook, MySpace, Twitter


  • CDMA:

    CDMA - Code Division Multiple Access. A technique of multiplexing, also called spread spectrum, in which analog signals are converted into digital form for transmission. For each communication channel, the signals are encoded in a sequence known to the transmitter and the receiver for that channel. The foremost application is digital cellular phone technology from QUALCOMM that operates in the 800MHz band and 1.9GHz PCS band. CDMA phones are noted for their excellent call quality and long battery life.

    • 800, 1900 MHz
  • Data:
    • EV-DO Rev.A
  • Positioning:

    Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.

    • GPS, E911
  • Navigation:
    • Yes
specifications continue after the ad


  • Bluetooth:
      • 3.0
  • Wi-Fi:
      • 802.11 b, g, n
    • Mobile hotspot:
      • Yes
  • USB:
      • USB 2.0
    • Connector:
      • microUSB
    • Features:
      • Mass storage device, USB charging
  • Other:
    • DLNA, Computer sync, OTA sync

Other features

  • Notifications:
    • Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
  • Sensors:
      • Accelerometer, Compass
  • Hearing aid compatibility:
      • M4
    • Voice dialing, Voice commands, Voice recording, TTY/TDD


  • Officially announced:
    • 28 Jun 2010

Shopping information

  • MSRP price:
    • $ 200

To see the full specifications with in-depth details click here.

This device is also known as Samsung Mesmerize, Samsung Showcase i500

Despite our efforts to provide full and correct Samsung Fascinate specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.
