T-Mobile Revvl 5G Specs


T-Mobile Revvl 5G specs include a 6.5-inch FHD+ display, Snapdragon 765 processor with 6GB RAM and 128GB expandable storage, and 4500mAh battery. There is a triple-camera setup with a 48MP main sensor on the back. The selfie camera is 16MP. The Revvl 5G is available from T-Mobile and Metro for $400 and as the name says, the phone is 5G ready.


  • 5G ready


  • Carrier-locked phone
  • Thick body (0.37 inches)

Popular Comparisons

The T-Mobile Revvl 5G is most commonly compared with these phones:

Specs Compare


Size: 6.5 inches
Resolution: 2340 x 1080 pixels, 19.5:9 ratio, 395 PPI
Screen-to-body: 83.07 %
Features: Ambient light sensor, Proximity sensor


System chip: Qualcomm Snapdragon 765 SM7250-AA (7 nm)
Processor: Octa-core, 2400 MHz, Kryo 475, 64-bit
GPU: Adreno 620
Internal storage: 128GB
Storage expansion: microSDXC up to 256 GB
Device type: Smartphone
OS: Android (10)


Capacity: 4500 mAh
Type: Not user replaceable


Rear: Triple camera
Main camera: 48 MP (PDAF)
Second camera: 8 MP (Ultra-wide)
Third camera: 5 MP (Macro)
Video recording: Yes
Front: 16 MP
Video capture: 1920x1080 (Full HD)
Dimensions: 6.51 x 3 x 0.37 inches (165.4 x 76.2 x 9.4 mm)
Weight: 7.58 oz (215.0 g)
Materials: Back: Plastic
Biometrics: 2D Face unlock, Fingerprint (touch)
Keys: Right: Volume control, Lock/Unlock key
Colors: Nebula black


Carrier locked: Yes
5G: n2, n25, n41, n66, n71, SA, NSA
4G (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 7(2600), 8(900), 12(700 a), 13(700 c), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 66(AWS-3), 71(600)
4G (TDD): Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
3G: Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Data Speed: LTE, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS
SIM type: Nano SIM


Headphones: 3.5mm jack
Speakers: Earpiece, Loudspeaker
Screen mirroring: Wireless screen share
Additional microphone(s): for Noise cancellation

Connectivity & Features

Bluetooth: 5.0
Wi-Fi: 802.11 a, b, g, n, ac; Wi-Fi Direct, Hotspot
USB: Type-C (reversible)
Features: Charging
Location: GPS, A-GPS, Cell ID, Wi-Fi positioning
Sensors: Accelerometer
Other: NFC
Hearing aid compatible: M3, T4

Regulatory Approval

FCC approval:
Date approved: Jul 28, 2020
FCC ID value: 2ACCJN039
Measured SAR:
Head: 1.34 W/kg
Body: 0.87 W/kg
Simultaneous Transmission: 1.54 W/kg
Wireless Router: 1.12 W/kg
Phablet: 3.95 W/kg

Buyers information

Price: $ 400
In The Box: Quick Start Guide, Charger Head, Data cable, Product Safety Information, SIM Tool


Officially announced: Aug 27, 2020
Despite our efforts to provide full and correct T-Mobile Revvl 5G specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please


If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Carrier Availability


T-Mobile Since Sep 4, 2020
Metro by T-Mobile Since Sep 4, 2020
