Google Pixel XL vs Google Pixel vs Samsung Galaxy S7 edge: size and specs comparisons

6comments
With the Galaxy Note 7 fiasco now seemingly over, the Galaxy S7 edge is now once again the best-spec'd and most advanced Samsung phone on the shelves. This makes it prey as well as a predator to Google's brand new Pixel XL, its large new handset that is targeted at the mainstream market, much in contrast with its geekier predecessor - the Nexus 6P.

It looks like these two devices are about to clash rather soon and so far the battle appears to be pretty much tied - the Pixel XL will likely be one step ahead in certain aspects but will be dogging the Galaxy S7 edge in several as well. For example, the Pixel XL is arguably not so impressive in terms of overall design (some even might call it an ugly duckling), but it does offer a more fluid and snappy user experience overall.

Admittedly, we are mostly excited for comparing the cameras of the Pixel/Pixel XL and the S7 edge in a direct duel, as both devices are obviously pretty well-endowed in the camera department. Until we get the chance to show you the outcome of this exciting camera battle, we can only satiate our hunger for comparisons by putting the Pixel XL against the Galaxy S7 edge in a specs and size comparison!

First things first, let's check the size differences between the three and see how the stack up against one another. The largest among the three is the 5.5-inch Pixel XL, towering at 6.09 x 2.98 x 0.34 inches (154.72 x 75.74 x 8.6 mm) and tipping the scales at 5.93 oz (168 gr). Second comes the 5.5-inch S7 edge, which boasts a superior screen-to-body ratio and clocks in at 5.94 x 2.86 x 0.30 inches (150.9 x 72.6 x 7.7 mm); the whole shebang weighs no more than 5.54 oz, or 157 gr. Finally, we've got the 5-inch Google Pixel, which stands at 5.66 x 2.74 x 0.34 inches (143.84 x 69.54 x 8.58 mm) and weighs 5.04 oz (143 gr). Here's how the three compare visually:

Google Pixel XL
Dimensions

6.09 x 2.98 x 0.34 inches

154.72 x 75.74 x 8.6 mm

Weight

5.93 oz (168 g)

Google Pixel
Dimensions

5.66 x 2.74 x 0.34 inches

143.84 x 69.54 x 8.58 mm

Weight

5.04 oz (143 g)

Samsung Galaxy S7 edge
Dimensions

5.94 x 2.86 x 0.3 inches

150.9 x 72.6 x 7.7 mm

Weight

5.54 oz (157 g)

Google Pixel XL
Dimensions

6.09 x 2.98 x 0.34 inches

154.72 x 75.74 x 8.6 mm

Weight

5.93 oz (168 g)

Google Pixel
Dimensions

5.66 x 2.74 x 0.34 inches

143.84 x 69.54 x 8.58 mm

Weight

5.04 oz (143 g)

Samsung Galaxy S7 edge
Dimensions

5.94 x 2.86 x 0.3 inches

150.9 x 72.6 x 7.7 mm

Weight

5.54 oz (157 g)

See the full Google Pixel XL vs Google Pixel vs Samsung Galaxy S7 edge size comparison or compare them to other phones using our Size Comparison tool.

With that out of the way, we've got nothing else to do than compare the specs of the three and see how do they fare against one another. Check out the full specs of all three phones right below.

Google Pixel XL Google Pixel Samsung Galaxy S7 edge

Design

Dimensions
6.09 x 2.98 x 0.34 inches
154.72 x 75.74 x 8.6 mm
5.66 x 2.74 x 0.34 inches
143.84 x 69.54 x 8.58 mm
5.94 x 2.86 x 0.30 inches
150.9 x 72.6 x 7.7 mm
Weight
5.93 oz (168.0 g) 5.04 oz (143.0 g) 5.54 oz (157.0 g)
Materials
Back: Aluminum, Glass Back: Aluminum, Glass Back: Glass (Corning Gorilla Glass 4)
Frame: Aluminum
Resistance
Splash, Dust; IP53 Splash, Dust; IP53 Water, Dust; IP68
Biometrics
Fingerprint (touch) Fingerprint (touch) Fingerprint (touch)
Features
Notification light Notification light Touch sensitive control keys
Keys
Right: Volume control, Lock/Unlock key Right: Volume control, Lock/Unlock key Left: Volume control; Right: Lock/Unlock key
Colors
Black, Gray, Blue Black, Gray, White Black, Gold, Silver, White, Pink gold, Black pearl, Coral blue

Display

Size
5.5-inch 5.0-inch 5.5-inch
Resolution
2560x1440px, 16:9 ratio, 534 PPI 1920x1080px, 16:9 ratio, 441 PPI 2560x1440px, 534 PPI
Technology
AMOLED AMOLED Super AMOLED
Screen-to-body
71.22 % 68.88 % 76.09 %
Features
Oleophobic coating, Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor Oleophobic coating, Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor

Hardware

System chip
Qualcomm Snapdragon 821 MSM8996 Pro Qualcomm Snapdragon 821 MSM8996 Pro Qualcomm Snapdragon 820 MSM8996 (14 nm)
Processor
Quad-core
2150 MHz
Kryo
Quad-core
2150 MHz
Kryo
Quad-core
2200 MHz
Kryo
GPU
Adreno 530 Adreno 530 Adreno 530
RAM
4GB (LPDDR4) 4GB (LPDDR4) 4GB (LPDDR4)
Internal storage
128GB 128GB 32GB, available to use: 24.4 GB
Storage expansion
not expandable not expandable microSDXC up to 200 GB
OS
Android (10, 9.0 Pie, 8.1 Oreo, 8.0 Oreo, 7.1 Nougat) Android (10, 9.0 Pie, 8.1 Oreo, 8.0 Oreo, 7.1 Nougat) Android (8.0 Oreo, 7.0 Nougat, 6.0 Marshmallow), Samsung TouchWiz UI

Battery

Capacity
3450 mAh 2770 mAh 3600 mAh
Type
Li - Ion Li - Ion Li - Ion
Charging
USB Power Delivery USB Power Delivery Qualcomm Quick Charge 2.0, Qi and Powermat wireless charging

Camera

Rear
Single camera Single camera Single camera
Main camera
12.3 MP (Laser and PDAF)
Aperture size: F2.0
Sensor size: 1/2.3"
Pixel size: 1.55 μm
12.3 MP (Laser and PDAF)
Aperture size: F2.0
Sensor size: 1/2.3"
Pixel size: 1.55 μm
12 MP (OIS, PDAF)
Aperture size: F1.7
Focal length: 26 mm
Sensor size: 1/2.5"
Pixel size: 1.4 μm
Flash
Dual LED Dual LED LED
Video recording
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (120 fps), 1280x720 (HD) (240 fps)
Video calling, Video sharing
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (120 fps), 1280x720 (HD) (240 fps)
Video calling, Video sharing
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (60 fps), 1280x720 (HD) (240 fps)
HDR, Picture-taking during video recording, Video calling, Video sharing
Front
8 MP, Video capture: 1920x1080 (Full HD) 8 MP, Video capture: 1920x1080 (Full HD) 5 MP (HDR)

Connectivity & Features

Bluetooth
4.2 4.2 4.2
WLAN
802.11 b,g,n,ac,dual-band
MIMO, Wi-Fi Direct, Hotspot
802.11 a,b,g,n,ac,dual-band
MIMO, Wi-Fi Direct, Hotspot
802.11 a,b,g,n,ac,dual-band,e
Multiple antennas, MIMO, Wi-Fi Direct, Hotspot
USB
Type-C, USB 3.0 Type-C, USB 3.0 microUSB, USB 2.0
Hearing aid compatible
M4/T4 M4/T4 M4/T3
Location
GPS, A-GPS, Glonass GPS, A-GPS, Glonass GPS, A-GPS, Glonass
Sensors
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other
NFC, UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync NFC, UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync NFC, ANT+, UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync

Multimedia

Headphones
3.5mm jack 3.5mm jack 3.5mm jack
Speakers
Earpiece, Loudspeaker Earpiece, Loudspeaker Earpiece, Loudspeaker
Features
Album art cover, Background playback aptX-HD Album art cover, Background playback
Screen mirroring
Wireless screen share
Additional microphone(s)
Noise cancellation Noise cancellation Noise cancellation

Cellular

4G (FDD)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS) Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 18(800 Lower), 19(800 Upper), 20(800 DD), 29(700 d), 30(2300 WCS)
4G (TDD)
Bands 41(2600+) Bands 41(2600+) Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
3G
Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100) Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900) Bands 1(2100), 2(1900), 4(1700/2100), 5(850)
Data Speed
LTE-A Cat 11 (600/75 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA, UMTS LTE-A Cat 11 (600/75 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, UMTS LTE-A Cat 9 (450/50 Mbit/s), HSPA
SIM type
Nano SIM Nano SIM Nano SIM
HD Voice
Yes Yes Yes
VoLTE
Yes

Regulatory Approval

FCC approval
Date approved: Feb 12, 2017
FCC ID value: NM8G-2PW2100
Date approved: Feb 12, 2017
FCC ID value: NM8G-2PW4100
Date approved: Feb 12, 2016
FCC ID value: A3LSMG935F
Measured SAR
Head: 0.89 W/kg
Measured in: 1900 MHz
Body: 0.56 W/kg
Measured in: 1900 MHz
Simultaneous Transmission: 1.15 W/kg
Wireless Router: 0.56 W/kg
Head: 0.92 W/kg
Measured in: 1900 MHz
Body: 0.58 W/kg
Measured in: 1900 MHz
Simultaneous Transmission: 1.08 W/kg
Wireless Router: 0.58 W/kg
Head: 0.27 W/kg
Body: 0.66 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 0.96 W/kg

Buyers information

MSRP
$ 869 $ 749 $ 799
In The Box
USB-C 18W adaptor with USB-PD, A-C cable (USB 3.0), C-C cable (USB 2.0), SIM tool, Quick switch adapter, In box promos and collateral

Availability

Officially announced
Oct 04, 2016 Oct 04, 2016 Feb 21, 2016
