LG V20

Announced:
Sep 6, 2016
Market status:
Released
Release date:
Sep 29, 2016

PhoneArena Rating:

8.0
Read Full Review

Display

Display size:

5.7 inches

Resolution:

1440 x 2560 pixels

Pixel density:

513 ppi

Technology:

IPS LCD

Screen-to-body ratio:

72.40 %

Features:

Scratch-resistant glass (Corning Gorilla Glass 4), Ambient light sensor, Proximity sensor

Additional display:

1040 x 160 pixels, Touch screen: Yes, Capacitive

Camera

Rear:

Dual camera

Main camera:

16 megapixels

Hardware Features:

Optical image stabilization, Laser autofocus

Specifications:

Aperture size: F1.8; Focal length: 29 mm; Sensor size: 1/2.8"

Second camera:

8 megapixels

Hardware Features:

Ultra-wide

Specifications:

Aperture size: F2.4; Focal Length: 12 mm; Sensor size: 1/3.2"

Video recording:

3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (30 fps), 1280x720 (HD) (120 fps)

Features:

Continuous autofocus, Object tracking, Digital image stabilization, Video calling, Video sharing

Front:

5 megapixels

Features:

Wide Angle

Design

Dimensions:

6.29 x 3.07 x 0.30 inches (159.7 x 78.1 x 7.6 mm)

Weight:

6.14 oz (174 g)
the average is 6.1 oz (173 g)

Materials:

Back: Aluminum

Resistance:

Shock; MIL-STD-810 certified

Biometrics:

Fingerprint (touch)

Colors:

Gray, Silver, Pink

Multimedia

Headphones:

3.5 mm jack

Speakers:

Earpiece, Loudspeaker

Features:

32-Bit DAC, aptX-HD

Screen mirroring:

DLNA, Wireless screen share, SlimPort

Additional microphone(s):

for Noise cancellation, Video recording

Hardware & Performance

System chip:

Qualcomm Snapdragon 820 MSM8996

Processor:

Quad-core, 2150 MHz, Kryo, 64-bit, 14 nm

GPU:

Adreno 530

RAM:

4 GB

Internal storage:

64 GB

Available to use:

50 GB

Storage expansion:

microSDXC up to 2000 GB

OS:

Android (8.0 Oreo, 7.0 Nougat), LG UX UI

Connectivity & Features

Bluetooth:

4.2

Wi-Fi:

802.11 a, b, g, n, ac, dual-band

USB:

USB Type-C (reversible), USB 2.0

Features:

Mass storage device, Video out

Location:

GPS, A-GPS, Glonass

Sensors:

Accelerometer, Gyroscope, Compass

Other:

NFC, UMA (Wi-Fi Calling), Infrared, Tethering, Computer sync, OTA sync

Cellular

LTE (FDD):

Bands 2, 3, 4, 5, 7, 12, 13, 17, 20, 25

UMTS:

850, 900, 1900, 2100 MHz

Data:

LTE-A Cat 12 (600/100 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS

HD Voice:

Yes

VoLTE:

Yes

Battery

Capacity:

3200 mAh

Type:

User replaceable

Charging:

Qualcomm Quick Charge 3.0

Talk time:

14.17 hours
the average is 20 h (1174 min)

Stand-by time:

17.8 days (426 hours)
the average is 20 days (491 h)

Phone features

Notifications:

Haptic feedback

Other features:

Voice dialing, Voice commands, Voice recording

This device is also known as LG US996

RELATED VIDEO

ALTERNATIVE VARIANTS

We list only the specs that are different than the main variant

LG V20

VS995 for Verizon Wireless

Differences from the main variant:

LTE (FDD):

Bands 2, 3, 4, 5, 7, 13, 20

Talk time:

26.08 hours
the average is 20 h (1174 min)

Stand-by time:

17.2 days (412 hours)
the average is 20 days (491 h)

FCC approval:

Date approved:

Nov 01, 2016

FCC ID value:

ZNFVS995 link

Measured SAR:

Head:

0.91 W/kg

Body:

0.83 W/kg

Simultaneous Transmission:

1.59 W/kg

Wireless Router:

0.88 W/kg

LG V20

LS997 for Sprint, Boost Mobile

Differences from the main variant:

LTE (FDD):

Bands 2, 3, 4, 5, 7, 12, 25, 26

LTE (TDD):

Bands 41

UMTS:

850, 900, 1700/2100, 1900, 2100 MHz

FCC approval:

Date approved:

Sep 07, 2016

FCC ID value:

ZNFLS997 link

Measured SAR:

Head:

0.73 W/kg

Body:

1.19 W/kg

Simultaneous Transmission:

1.59 W/kg

Wireless Router:

1.19 W/kg

LG V20

H918 for T-Mobile

Differences from the main variant:

LTE (FDD):

Bands 1, 2, 3, 4, 5, 7, 12, 13, 20, 66

Talk time:

20.00 hours
the average is 20 h (1174 min)

Stand-by time:

6.1 days (146 hours)
the average is 20 days (491 h)

FCC approval:

Date approved:

Nov 01, 2016

FCC ID value:

ZNFH918 link

Measured SAR:

Head:

0.87 W/kg

Body:

1.18 W/kg

Simultaneous Transmission:

1.59 W/kg

Wireless Router:

1.18 W/kg

LG V20

H910 for AT&T

Differences from the main variant:

LTE (FDD):

Bands 1, 2, 3, 4, 5, 7, 12, 20, 29, 30

UMTS:

850, 1900, 2100 MHz

Talk time:

23.00 hours
the average is 20 h (1174 min)

Stand-by time:

6.2 days (148 hours)
the average is 20 days (491 h)

FCC approval:

Date approved:

Nov 01, 2016

FCC ID value:

ZNFH910 link

Measured SAR:

Head:

0.87 W/kg

Body:

1.18 W/kg

Simultaneous Transmission:

1.59 W/kg

Wireless Router:

1.18 W/kg

LG V20

H990DS International version

Differences from the main variant:

Radio:

FM

LTE (FDD):

Bands 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 26, 28

LTE (TDD):

Bands 38, 39, 40, 41

UMTS:

850, 900, 1700/2100, 1800, 1900, 2100 MHz

Dual SIM:

Yes

FCC approval:

Date approved:

Nov 01, 2016

FCC ID value:

ZNFH990 link

Measured SAR:

Head:

0.36 W/kg

Body:

0.86 W/kg

Simultaneous Transmission:

1.39 W/kg

Wireless Router:

0.86 W/kg

US CARRIER AVAILABILITY

Pros

  • Extremely high pixel density screen (513 ppi)

Cons

No Cons

Description

The LG V20 isn't just another smartphone. It is a multimedia powerhouse aimed at Android enthusiasts and content creators. As such, it comes with high-end audio reproduction and recording capabilities. The duet of main cameras we knew from the LG G5 is present here as well - one camera shoots high-res regular photos, while the other sports a wide-angle lens for a greater field of view. And the top-notch hardware tucked inside the hood makes this phone an ideal proposisiton to power users, with plenty of processing might to offer. A nice addition to the whole package is the secondary always-on display situated at the front. It displays shortcuts to frequently used functions, and notifications can be shown even when the main display isn't lit. While there's no modular functionality here, the LG V20 offers a removable battery - a rarity among metal-made handsets.
