LG Wing

Description

LG Wing is the first device part of the Explorer Project and has a unique form factor. The main 6.8-inch OLED display rotates clockwise 90 degrees and reveals a 3.9-inch secondary OLED display. Despite the cool form factor, other specs are pretty midrange - Snapdragon 765G, 8GB RAM, 128GB/256GB storage, and 400mAh battery. There are three camera sensors on the back of the phone that can be used as a Gimbal Motion Camera, while the selfie shooter is a pop-up one. The LG Wing price is $1000, available through Verizon, AT&T and T-Mobile.

This device is also known as LG LM-F100VM

Pros

  • 5G ready
  • High screen-to-body ratio (87.09 %)
  • Supports wireless charging

Cons

  • Thick body (0.43 inches)

Popular Comparisons

The LG Wing is most commonly compared with these phones:

Specs Compare

Display

Benchmarks
Size: 6.8 inches
Resolution: 2460 x 1080 pixels, 20.5:9 ratio, 395 PPI
Technology: P-OLED
Screen-to-body: 87.09 %
Features: 60Hz refresh rate, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
Additional display: 3.9 inches, 1080 pixels 1240 x, OLED

Hardware

Benchmarks
System chip: Qualcomm Snapdragon 765G SM7250-AB
Processor: Octa-core, 2400 MHz, Kryo 475, 64-bit, 7 nm
GPU: Adreno 620
RAM: 8GB
Internal storage: 256GB, available to use: 224 GB
Storage expansion: microSDXC up to 2000 GB
Device type: Smartphone
OS: Android (10)

Battery

Benchmarks
Capacity: 4000 mAh
Type: Not user replaceable
Battery life test results: link
Charging: Qualcomm Quick Charge 4+, Qi wireless charging
Max charge speed: Wired: 25.0W; Wireless: 13.0W

Camera

Benchmarks
Rear: Triple camera Camera samples
Main camera: 64 MP (OIS, PDAF)
Specifications: Aperture size: F1.8; Focal length: 25 mm; Sensor size: 1/1.7"; Pixel size: 0.8 μm
Second camera: 13 MP (Ultra-wide)
Specifications: Aperture size: F1.9; Sensor size: 1/3.4"; Pixel size: 1 μm
Third camera: 12 MP (Ultra-wide)
Specifications: Aperture size: F2.2; Sensor size: 1/2.55"; Pixel size: 1.4 μm
Video recording: 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD)
Features: EIS
Front: 32 MP (Pop-up, HDR)
Video capture: 1920x1080 (Full HD)
Dimensions: 6.67 x 2.93 x 0.43 inches (169.5 x 74.5 x 10.9 mm)
Weight: 9.17 oz (260.0 g)
Materials: Back: Glass (Corning Gorilla Glass 5); Frame: Aluminum
Resistance: Splash, Dust; IP54; MIL-STD-810 certified
Biometrics: In-screen fingerprint
Keys: Right: Volume control, Lock/Unlock key
Colors: Aurora gray, Illusion Sky

Cellular

5G: n2, n5, n66, n78, n260, n261, Sub-6, mmWave
LTE (FDD): Bands 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 12(700 a), 13(700 c), 20(800 DD), 28(700 APT), 66(AWS-3)
LTE (TDD): Bands 46, 48(3600)
UMTS: Bands 1(2100), 2(1900), 5(850), 8(900)
Data Speed: LTE-A, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
SIM type: Nano SIM
HD Voice: Yes

Multimedia

Headphones: No 3.5mm jack
Speakers: Earpiece, Loudspeaker
Features: aptX
Screen mirroring: DLNA, Wireless screen share
Radio: FM
Additional microphone(s): for Noise cancellation

Connectivity & Features

Bluetooth: 5.1
Wi-Fi: 802.11 a, b, g, n, ac, dual-band; Wi-Fi Direct, Hotspot
USB: Type-C (reversible), USB 3.1
Features: Charging, Headphones port, OTG
Location: GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors: Accelerometer, Gyroscope, Compass
Other: NFC, UMA (Wi-Fi Calling)
Hearing aid compatible: M4, T4

Regulatory Approval

FCC approval:
Date approved: Sep 29, 2020
FCC ID value: ZNFF100VM
Measured SAR:
Head: 0.19 W/kg
Body: 0.82 W/kg
Simultaneous Transmission: 1.59 W/kg
Wireless Router: 1.06 W/kg
Phablet: 3.65 W/kg

Buyers information

Price: $ 1000
User Manual: This is the official LG Wing User Guide in English provided from the manufacturer.
In The Box: Pre-installed SIM Card, Embedded Li-ion Battery, Wall/USB Charger, Type-C to 3.5mm Adapter, SIM Eject Pin, Quick Reference Guide, Product Safety & Warranty Brochure

Availability

Officially announced: Sep 14, 2020
Despite our efforts to provide full and correct LG Wing specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please

LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.

Alternative variants

LG Wing

for AT&T

Differences from the main variant:
Weight: 8.82 oz (250.0 g)
LTE (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 12(700 a), 14(700 PS), 20(800 DD), 29(700 d), 30(2300 WCS)
LTE (TDD): Bands 38(2600), 40(2300), 41(2600+)

LG Wing

for T-Mobile

Differences from the main variant:
5G: n25, n41, n66, n71
LTE (FDD): Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 66(AWS-3), 71(600)
LTE (TDD): Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
UMTS: Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Hearing aid compatible: M4, T3

Carrier Availability

Available

Verizon Since Oct 15, 2020
AT&T Since Nov 6, 2020

Discontinued

T-Mobile
