Display
Size:
5.3 inches
6.7 inches
Resolution:
960 x 480 pixels, 203 PPI
3216 x 1440 pixels, 20.1:9 ratio, 526 PPI
Technology:
TFT
AMOLED
Refresh rate:
120Hz
Screen-to-body:
72.69 %
89.79 %
Colors:
16 777 216
Touchscreen:
Capacitive, Multi-touch
Features:
Ambient light sensor, Proximity sensor
HDR support, Scratch-resistant glass (Corning Gorilla Glass), Ambient light sensor, Proximity sensor
Hardware
System chip:
MediaTek MT6739
Qualcomm Snapdragon 888
Processor:
Quad-core, 1500 MHz, ARM Cortex-A53, 64-bit, 28 nm
Octa-core, 2840 MHz, Kryo 680, 64-bit, 5 nm
GPU:
PowerVR GE8100
Adreno 660
RAM:
1GB LPDDR3
8GB LPDDR5
Internal storage:
16GB
128GB (UFS 3.1), not expandable
Storage expansion:
microSDXC up to 64 GB
Device type:
Smartphone
Smartphone
OS:
Android (8.0 Oreo)
Android (11), OxygenOS UI
Battery
Capacity:
2500 mAh
4500 mAh
Type:
Not user replaceable
Charging:
OnePlus Warp Charge, Qi wireless charging
Max charge speed:
Wired: 65.0W; Wireless: 50.0W
Camera
Rear:
Single camera
Quad camera
Main camera:
8 MP (Autofocus)
48 MP (OIS, PDAF)
Specifications:
Aperture size: F1.8; Focal length: 23 mm; Sensor size: 1/1.4"; Pixel size: 1.12 μm
Second camera:
8 MP (Telephoto, OIS, Autofocus)
Specifications:
Optical zoom: 3.3x; Aperture size: F2.4; Focal Length: 77 mm; Pixel size: 1.0 μm
Third camera:
50 MP (Ultra-wide)
Specifications:
Aperture size: F2.2; Focal Length: 14 mm; Sensor size: 1/1.56"
Fourth camera:
2 MP (Black and White)
Video recording:
1920x1080 (Full HD) (30 fps)
7680x4320 (8K UHD) (30 fps), 3840x2160 (4K UHD) (120 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (480 fps)
Features:
Video calling, Video sharing
OIS, HDR, Continuous autofocus, EIS
Front:
5 MP (Flash)
16 MP (EIS)
Design
Dimensions:
5.56 x 2.78 x 0.39 inches (141.1 x 70.5 x 9.8 mm)
6.43 x 2.90 x 0.34 inches (163.2 x 73.6 x 8.7 mm)
Weight:
5.43 oz (154.0 g)
6.95 oz (197.0 g)
Materials:
Back: Glass (Corning Gorilla Glass)
Resistance:
Water, Dust; IP68
Biometrics:
Fingerprint (touch)
2D Face unlock, In-screen fingerprint
Keys:
Right: Volume control, Lock/Unlock key
Left: Volume control; Right: Lock/Unlock key, Other
Colors:
Black, Gold
Morning Mist, Forest Green, Stellar Black
Cellular
5G:
n1, n2, n3, n5, n7, n8, n20, n25, n28, n38, n40, n41, n48, n66, n71, n77, n78, NSA
LTE (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 12(700 a), 28(700 APT)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 30(2300 WCS), 32(1500 L-band), 66(AWS-3), 71(600)
LTE (TDD):
Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
UMTS:
Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900), 9(1700), 19(800)
Data Speed:
LTE, HSPA, HSUPA, UMTS
LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS
SIM type:
Nano SIM
Multimedia
Headphones:
3.5mm jack
No 3.5mm jack
Speakers:
Earpiece, Loudspeaker
Earpiece, Loudspeaker, Multiple speakers
Features:
Album art cover, Background playback
Dolby Atmos
Screen mirroring:
Wireless screen share
Wireless screen share
Additional microphone(s):
for Noise cancellation
Connectivity & Features
Bluetooth:
4.0
5.2
Wi-Fi:
802.11 b, g, n; Hotspot, Wi-Fi Direct
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
USB:
microUSB, USB 2.0
Type-C (reversible), USB 3.1
Features:
Mass storage device, Charging
Charging, Headphones port, Mass storage device
Location:
GPS, A-GPS
GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors:
Accelerometer
Accelerometer, Gyroscope, Compass
Other:
VoIP, Tethering, Computer sync, OTA sync
NFC
Phone features
Notifications:
Haptic feedback, Music ringtones, Vibration, Flight mode, Silent mode, Speakerphone
Other features:
Voice dialing, Voice commands, Voice recording
Regulatory Approval
FCC approval:
Date approved:
Mar 28, 2018
Mar 24, 2021
FCC ID value:
YHLBLUGRANDM3
2ABZ2-EF14A
Measured SAR:
Head:
0.50 W/kg
1.19 W/kg
Body:
1.15 W/kg
0.75 W/kg
Simultaneous Transmission:
1.34 W/kg
1.52 W/kg
Wireless Router:
1.34 W/kg
1.19 W/kg
Buyers information
Price:
$ 969
In The Box:
Warp Charge 65 Power Adapter, Warp Charge Type-C to Type-C Cable, Quick Start Guide, Welcome Letter, Safety Information and Warranty Card, OnePlus Sticker, SIM Tray Ejector
Availability
Officially announced:
Mar 23, 2021
