HTC Magician

Dec 15, 2004
Market status


No pros


  • Lacks Wi-Fi
  • Single-core processor
  • Too little RAM memory (64 MB RAM)
  • It is so thick it needs a personal fitness trainer (0.72 inches inches)
  • Resistive touchscreen technology means its display is less sensitive than you would like it to be
  • Low resolution display (240 x 320 pixels)
  • Low-resolution camera (1.3 megapixels)
  • The camera lacks autofocus
  • The camera lacks flash
  • Lacks an ambient light sensor for automatic screen brightness adjustment
  • Lacks a proximity sensor that turns the display оff during a phone call
  • No front-facing camera
  • Lacks global positioning system (GPS)




HTC Magician / MDA Compact is a tri-band GSM. It features 65k TFT display, 1.3 megapixels camera with MPEG4 video capture Bluetooth, IMAP / POP3 / SMTP e-mail, WAP 2.0 Internet browser, Intel PXA270 Xscale 416 MHz Processor and Touch screen.

Do you ...?



  • Device type:
    • Smart phone
  • OS:
    • Windows Mobile Professional (2003 SE)
  • Dimensions:
    • 4.20 x 2.30 x 0.72 inches (105 x 58 x 18 mm)
  • Weight:
    • 5.30 oz (150 g)
      the average is 5.1 oz (147 g)


  • Resolution:
    • 240 x 320 pixels
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • TFT
  • Colors:
    • 65 536
  • Touchscreen:
      • Yes


  • Camera:
      • 1.3 megapixels
    • Features:
      • CMOS image sensor, Digital zoom, Mirror
    • Settings:
      • Exposure compensation
    • Shooting Modes:
      • Burst mode
  • Camcorder:
      • Yes


  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Single core, 416 MHz, Intel PXA270 XScale
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 64 MB RAM / 64 MB ROM
  • Storage expansion:
    • SD, MMC


  • Talk time:
    • 5.00 hours
      the average is 14 h (828 min)
  • Stand-by time:
    • 7.9 days (190 hours)
      the average is 17 days (417 h)
  • Capacity:
    • 1200 mAh

Internet browsing

  • Browser:
      • Internet Explorer Mobile


  • GSM:
    • 850, 1800, 1900 MHz
    • Other version supports GSM 900/1800/1900 MHz
  • Data:
    • GPRS


  • Bluetooth:
      • 1.2
  • USB:
      • Yes
    • Connector:
      • miniUSB
  • Other:
    • Computer sync, Infrared
specifications continue after the ad

Other features

  • Notifications:
    • Service lights, Polyphonic ringtones (40 voices), Vibration, Phone profiles, Speakerphone
    • Voice recording

To see the full specifications with in-depth details click here.

This device is also known as i-mate JAM, T-Mobile MDA Compact, O2 xda II mini

Despite our efforts to provide full and correct HTC Magician specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.

If you are interested in using our specs commercially, check out our Phone specs database licensing page.
