Display
Size:
5.2 inches
6.1 inches
Resolution:
1920 x 1080 pixels, 16:9 ratio, 424 PPI
2520 x 1080 pixels, 21:9 ratio, 449 PPI
Technology:
IPS LCD
OLED
Screen-to-body:
69.17 %
80.82 %
Touchscreen:
Capacitive, Multi-touch
Features:
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
120Hz refresh rate, HDR support, Scratch-resistant glass (Corning Gorilla Glass 6), Ambient light sensor, Proximity sensor
Hardware
System chip:
Qualcomm Snapdragon 835 MSM8998
Qualcomm Snapdragon 865 SM8250
Processor:
Octa-core, 2450 MHz, Kryo 280, 64-bit, 10 nm
Octa-core, 2840 MHz, Kryo 585, 64-bit, 7 nm
GPU:
Adreno 540
Adreno 650
RAM:
4GB LPDDR4
8GB LPDDR5
Internal storage:
64GB, available to use: 49.4 GB
128GB (UFS)
Storage expansion:
microSDXC up to 2000 GB
microSDXC up to 1000 GB
Device type:
Smartphone
Smartphone
OS:
Android (8.0 Oreo)
Android (10)
Battery
Capacity:
2700 mAh
4000 mAh
Type:
Not user replaceable
Not user replaceable
Charging:
Qualcomm Quick Charge 3.0
USB Power Delivery
Camera
Rear:
Single camera
Triple camera
Main camera:
19 MP (Laser and PDAF)
12 MP (OIS, PDAF)
Specifications:
Aperture size: F2.0; Focal length: 25 mm; Sensor size: 1/2.3"; Pixel size: 1.22 μm
Aperture size: F1.7; Focal length: 24 mm; Sensor size: 1/1.7"
Second camera:
12 MP (Telephoto, OIS, PDAF)
Specifications:
Optical zoom: 3.0x; Aperture size: F2.4; Focal Length: 70 mm; Sensor size: 1/3.4"; Pixel size: 1 μm
Third camera:
12 MP (Ultra-wide, PDAF)
Specifications:
Aperture size: F2.2; Focal Length: 16 mm; Sensor size: 1/2.55"
Video recording:
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD), 1280x720 (HD) (960 fps)
3840x2160 (4K UHD) (120 fps), 1920x1080 (Full HD) (60 fps)
Features:
HDR, Object tracking, Picture-taking during video recording, EIS, Video calling, Video sharing
OIS, HDR, Time-lapse video, EIS
Front:
13 MP (Wide Angle)
8 MP (EIS, HDR)
Video capture:
1920x1080 (Full HD)
1920x1080 (Full HD)
Design
Dimensions:
5.83 x 2.87 x 0.29 inches (148 x 73 x 7.4 mm)
6.22 x 2.68 x 0.31 inches (158 x 68 x 8 mm)
Weight:
5.50 oz (156.0 g)
5.75 oz (163.0 g)
Materials:
Back: Aluminum
Back: Glass (Corning Gorilla Glass 6); Frame: Aluminum
Resistance:
Water, Splash; IP68
Water, Dust; IP65/68
Biometrics:
Fingerprint (touch)
Fingerprint (touch)
Keys:
Right: Volume control, Camera shutter, Lock/Unlock key
Right: Volume control, Camera shutter, Lock/Unlock key
Colors:
Black, Silver, Pink, Blue
Black, Blue, Grey
Cellular
5G:
n1, n3, n8, n28, n77, n78, SA, NSA
LTE (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 20(800 DD), 25(1900+), 29(700 d), 66(AWS-3)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 17(700 b), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 32(1500 L-band), 66(AWS-3)
LTE (TDD):
Bands 38(2600), 40(2300), 41(2600+)
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
UMTS:
Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 6(800), 8(900)
Data Speed:
LTE-A Pro Cat 16 (1000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS
LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM:
Shared with microSD
SIM type:
Nano SIM
Nano SIM
Multimedia
Headphones:
3.5mm jack
3.5mm jack
Speakers:
Earpiece, Multiple speakers
Earpiece, Multiple speakers
Features:
aptX-HD
Dolby Atmos, aptX-HD, Album art cover
Screen mirroring:
DLNA, Wireless screen share
Wireless screen share
Additional microphone(s):
for Noise cancellation
for Noise cancellation
Connectivity & Features
Bluetooth:
5.0
5.1
Wi-Fi:
802.11 a, b, g, n, ac, dual-band; MIMO, Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; Wi-Fi Direct, Hotspot
USB:
Type-C (reversible), USB 3.1
Type-C (reversible), USB 3.1
Features:
Mass storage device, Charging
Charging, OTG, Video out
Location:
GPS, A-GPS, Glonass
GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Sensors:
Accelerometer, Gyroscope, Compass, Barometer, Step detector, Step counter
Accelerometer, Gyroscope, Compass, Barometer
Other:
NFC, Tethering, Computer sync, OTA sync
NFC
Phone features
Notifications:
Haptic feedback, Music ringtones, Vibration, Flight mode, Silent mode, Speakerphone
Other features:
Voice dialing, Voice commands, Voice recording, TTY/TDD
Regulatory Approval
FCC approval:
Date approved:
Apr 19, 2021
FCC ID value:
PY7-50241N
Measured SAR:
Head:
0.32 W/kg
Body:
0.48 W/kg
Simultaneous Transmission:
1.21 W/kg
Wireless Router:
0.72 W/kg
Buyers information
Price:
$ 700
$ 950
User Manual:
This is the official Sony Xperia 5 II User Guide in English provided from the manufacturer.
Availability
Officially announced:
Aug 31, 2017
Sep 17, 2020
Expected Announcement:
Yes
