Display
Size:
6.4 inches
6.7 inches
Resolution:
3120 x 1440 pixels, 19.5:9 ratio, 538 PPI
2400 x 1080 pixels, 20:9 ratio, 393 PPI
Technology:
AMOLED
Super AMOLED Plus
Refresh rate:
60Hz
Screen-to-body:
87.78 %
89.23 %
Features:
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
Hardware
System chip:
HiSilicon Kirin 980 (7 nm)
Qualcomm Snapdragon 865+ SM8250-AB (7 nm)
Processor:
Octa-core, 2600 MHz, ARM Cortex-A76 and ARM Cortex-A55, 64-bit
Octa-core, 1x 3.1GHz Kryo 585 + 3x 2.42GHz Kryo 585 + 4x 1.80GHz Kryo 585, 64-bit
GPU:
Mali-G76 MP10
Adreno 650
RAM:
6GB LPDDR4
8GB LPDDR5
Internal storage:
128GB
128GB (UFS 3.0), available to use: 102.5 GB, not expandable
Storage expansion:
Nano Memory (NM) up to 256 GB
Device type:
Smartphone
Smartphone
OS:
Android (10, 9.0 Pie), Huawei Emotion UI
Android (13, 12, 11, 10), Samsung One UI
Battery
Capacity:
4200 mAh
4300 mAh
Type:
Li - Ion, Not user replaceable
Li - Polymer, Not user replaceable
Charging:
Huawei SuperCharge, Qi wireless charging, Reverse wireless charging
Qualcomm Quick Charge 2.0, Samsung Adaptive Fast Charging, Qi and Powermat wireless charging, Reverse wireless charging
Camera
Rear:
Triple camera
Triple camera
Main camera:
40 MP (Laser and PDAF, CMOS image sensor)
12 MP (OIS, PDAF)
Specifications:
Aperture size: F1.8; Focal length: 27 mm; Sensor size: 1/1.7"; Pixel size: 1 μm
Aperture size: F1.8; Focal length: 26 mm; Sensor size: 1/1.76"; Pixel size: 1.8 μm
Second camera:
8 MP (Telephoto, OIS, Laser and PDAF)
64 MP (Telephoto, OIS, PDAF)
Specifications:
Optical zoom: 3.0x; Aperture size: F2.4; Focal Length: 80 mm; Sensor size: 1/4"
Aperture size: F2.0; Focal Length: 27 mm; Sensor size: 1/1.7"; Pixel size: 0.8 μm
Third camera:
20 MP (Ultra-wide, Laser and PDAF, CMOS image sensor)
12 MP (Ultra-wide, Autofocus)
Specifications:
Aperture size: F2.2; Focal Length: 16 mm; Sensor size: 1/2.7"
Aperture size: F2.2; Focal Length: 13 mm; Sensor size: 1/2.55"; Pixel size: 1.4 μm
Flash:
Dual LED
LED
Video recording:
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (60 fps), 1280x720 (HD) (960 fps)
7680x4320 (8K UHD) (24 fps), 3840x2160 (4K UHD) (60 fps), 1920x1080 (Full HD) (240 fps), 1280x720 (HD) (960 fps)
Features:
Time-lapse video, Picture-taking during video recording, Video light, EIS, Video calling, Video sharing
OIS, HDR, Time-lapse video, Hyperlapse, Object tracking, EIS
Front:
24 MP (HDR)
10 MP (PDAF, HDR)
Video capture:
1920x1080 (Full HD)
3840x2160 (4K UHD)
Design
Dimensions:
6.21 x 2.85 x 0.34 inches (157.8 x 72.3 x 8.6 mm)
6.36 x 2.96 x 0.33 inches (161.6 x 75.2 x 8.3 mm)
Weight:
6.67 oz (189.0 g)
6.84 oz (194.0 g)
Materials:
Back: Glass (Corning Gorilla Glass 5)
Back: Plastic
Resistance:
Water, Dust; IP68
Water, Dust; IP68
Biometrics:
3D Face unlock, In-screen fingerprint
2D Face unlock, Ultrasonic in-screen fingerprint
Features:
Notification light
Stylus
Keys:
Right: Volume control, Lock/Unlock key
Right: Volume control, Lock/Unlock key
Colors:
Black, Emerald green, Twilight
Mystic gray, Mystic bronze, Mystic green, Mystic red
Cellular
5G:
n2, n5, n12, n25, n41, n66, n71, n260, n261, SA, NSA, Sub-6, mmWave
4G (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 9(1800), 12(700 a), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 26(850+), 28(700 APT), 32(1500 L-band)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 13(700 c), 14(700 PS), 18(800 Lower), 19(800 Upper), 20(800 DD), 25(1900+), 26(850+), 28(700 APT), 29(700 d), 30(2300 WCS), 66(AWS-3)
4G (TDD):
Bands 34(2000), 38(2600), 39(1900+), 40(2300)
Bands 38(2600), 39(1900+), 40(2300), 41(2600+), 46, 48(3600)
3G:
Bands 6(800), 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 8(900)
Data Speed:
LTE-A Pro Cat 21 (1400/200 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA
LTE-A Pro Cat 20 (2000/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM:
Shared with microSD
SIM type:
Nano SIM
Nano SIM
HD Voice:
Yes
Yes
VoLTE:
Yes
Multimedia
Headphones:
No 3.5mm jack
No 3.5mm jack
Speakers:
Earpiece, Multiple speakers
Earpiece, Multiple speakers
Features:
32-Bit DAC, aptX-HD
32-Bit DAC, Dolby Atmos, aptX, Dolby Digital, Dolby Digital Plus
Screen mirroring:
Wireless screen share
Wireless screen share
Radio:
FM
Additional microphone(s):
for Noise cancellation
for Noise cancellation
Connectivity & Features
Bluetooth:
5.0
5.0
Wi-Fi:
802.11 a, b, g, n, ac, dual-band; Wi-Fi Direct, Hotspot
802.11 a, b, g, n, ac, ax (Wi-Fi 6), dual-band; MIMO, Wi-Fi Direct, Hotspot
USB:
Type-C (reversible), USB 3.1
Type-C (reversible), USB 3.2
Features:
Mass storage device, OTG, Video out, Charging, Headphones port
Charging, Headphones port, OTG, Video out
HDMI:
Yes
Location:
GPS, A-GPS, Glonass, Galileo, BeiDou, Dual-band positioning
GPS, A-GPS, Glonass, Galileo, Cell ID, Wi-Fi positioning
Sensors:
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Accelerometer, Gyroscope, Compass, Hall (for flip covers), Barometer
Other:
NFC, UMA (Wi-Fi Calling), Infrared, VoIP, Tethering, Computer sync, OTA sync
NFC, ANT+
Hearing aid compatible:
M3, T3
Regulatory Approval
FCC approval:
Date approved:
Oct 17, 2018
Jul 22, 2020
FCC ID value:
QISLYA-LX9
A3LSMN981U
Measured SAR:
Head:
0.58 W/kg
0.41 W/kg
Body:
0.81 W/kg
0.92 W/kg
Simultaneous Transmission:
1.53 W/kg
1.59 W/kg
Wireless Router:
0.77 W/kg
1.22 W/kg
Phablet:
3.17 W/kg
3.99 W/kg
Buyers information
Price:
$ 1000
User Manual:
This is the official Samsung Galaxy Note 20 User Guide in English provided from the manufacturer.
In The Box:
Type-C Headphones, 40W Charger, Type-C Cable, SIM Ejectr tool, Quick start guide, Protective case, Warranty card, Type-C to 3.5mm headphone adapter.
Data Cable, Travel Adapter, Ejection Pin, Quick Start Guide
Availability
Officially announced:
Oct 16, 2018
Aug 05, 2020
