Nokia Lumia 820

Sep 5, 2012
Market status
Release date
Oct 30, 2012

US carrier availability

Discontinued: AT&T


  • Fast mobile data support (4G)


  • Low pixel density screen (217 ppi)
  • Too little RAM memory (1024 MB RAM)
  • Low resolution display (480 x 800 pixels)




Nokia Lumia 820 is situated in the mid-range class, a notch below the Nokia Lumia 920, yet promises a Windows Phone 8 experience identical to what a high-end device is expected to deliver. First thing you'll notice about the Nokia Lumia 820 is its colorful outfit and the unibody look of its construction. The smartphone will be available with red, yellow, grey, cyan, purple, white and black. interchangeable shells, some of which allow the device to be charged wirelessly. The next thing that grabs the audience's attention is the 4.3-inch display enhanced with ClearBlack technology allowing identical outdoor readability to that of the Lumia 920's screen. Its resolution is 480 by 800 pixels, which is a bit underwhelming, yet still acceptable for a mid-range device. Moreover, the screen supports Super Sensitive touch technology, meaning that using some of the smartphone's features is possible even if the user is wearing gloves. Underneath the hood of the Nokia Lumia 820 runs a dual-core Snapdragon S4 processor clocked at 1.5GHz paired with 1GB of RAM, which leads us to believe that performance won't be an issue with the smartphone, especially knowing how smoothly Windows Phone runs even on less capable hardware. There is an 8-megapixel camera with Carl Zeiss optics and dual LED flash on the smartphone's back, yet features like optical image stabilization and other PureView enhancements have been left out. Oh well, at least 1080p video can be captured at 30 frames per second. On the device's front resides a VGA camera for video chats and the occasional self-portrait.

Do you ...?



  • Device type:
    • Smart phone
  • OS:
    • PopupWindows Phone 8
  • Dimensions:
    • 4.87 x 2.70 x 0.39 inches (123.8 x 68.5 x 9.9 mm)
  • Weight:
    • 5.64 oz (160 g)
      the average is 5.2 oz (150 g)


  • Physical size:
    • 4.3 inches
  • Resolution:
    • 480 x 800 pixels
  • Pixel density:

    Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.

    • 217 ppi
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • AMOLED
  • Screen-to-body ratio:
    • 62.04 %
  • Colors:
    • 16 777 216
  • Touchscreen:
      • Multi-touch
  • Features:
    • Light sensor, Proximity sensor


  • Camera:
      • Popup8 megapixels
    • Flash:
      • Dual LED
    • Aperture size:

      Aperture size - The aperture of a camera is the opening through which light travels before it reaches the camera sensor. The smaller the number is, the bigger this opening is, allowing for more light to pass.

      • F2.2
    • Focal length (35mm equivalent):
      • 28 mm
    • Camera sensor size:
      • 1/3.2"
    • Features:
      • Autofocus, Touch to focus, Digital zoom, Geo tagging
    • Settings:
      • Exposure compensation, ISO control, White balance presets
    • Shooting Modes:
      • PopupMacro mode, Night mode
  • Camcorder:
      • 1920x1080 (1080p HD) (30 fps)
    • Features:
      • Continuous autofocus, Video calling
  • Front-facing camera:
      • 0.3 megapixels VGA


  • System chip:

    System chip - Most modern handsets use an advanced chip that includes many of the device’s hardware modules like the processor, Wi-Fi, Bluetooth and sometimes even the wireless radio. This field shows what particular system chip (or System-on-a-Chip) is used in the phone.

    • Qualcomm Snapdragon S4 Plus MSM8960
  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Dual-core, 1500 MHz, Krait
  • Graphics processor:
      • Adreno 225
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 1024 MB RAM
  • Built-in storage:
    • 8 GB
  • Storage expansion:
    • microSD, microSDHC, microSDXC up to 64 GB


  • Talk time:
    • 15.40 hours
      the average is 15 h (884 min)
  • Stand-by time:
    • 15.0 days (360 hours)
      the average is 18 days (425 h)
  • Talk time (3G):
    • 8.10 hours
      the average is 15 h (913 min)
  • Stand-by time (3G):
    • 15.0 days (360 hours)
      the average is 24 days (580 h)
  • Music playback:
    • 61.00 hours
  • Video playback:
    • 5.60 hours
  • Capacity:
    • 1650 mAh
  • Wireless charging:
    • Optional


  • Music player:
    • Filter by:
      • Album, Artist, Playlists
    • Features:
      • Album art cover, Background playback
  • Radio:
      • FM, Stereo, RDS

Internet browsing

  • Browser:
    • Popup
      • Internet Explorer 10
  • Built-in online services support:
    • Facebook, YouTube (upload), Flickr, Picasa/Google+, Twitter


  • GSM:
    • 850, 900, 1800, 1900 MHz
  • UMTS:
    • 850, 900, 1900, 2100 MHz
  • FDD LTE:
    • 800 (band 18), 900 (band 8), 1800 (band 3), 2100 (band 1), 2600 (band 7) MHz
  • Data:
    • LTE Cat 3 (100/50 Mbit/s), , HSDPA+ (4G) 42.2 Mbit/s, UMTS, EDGE, GPRS
  • Micro SIM:
    • Yes
  • Positioning:

    Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.

    • GPS, A-GPS, S-GPS, Glonass, Cell ID, Wi-Fi positioning
  • Navigation:
    • Turn-by-turn navigation, Voice navigation
specifications continue after the ad


  • Bluetooth:
      • 3.0
  • Wi-Fi:
      • 802.11 a, b, g, n, n 5GHz
    • Mobile hotspot:
      • Yes
  • USB:
      • USB 2.0
    • Connector:
      • microUSB
    • Features:
      • Mass storage device, USB charging
  • Other:
    • NFC, Computer sync, OTA sync

Other features

  • Notifications:
    • Haptic feedback, Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
  • Additional microphone(s):
      • for Noise cancellation
  • Sensors:
      • Accelerometer, Gyroscope, Compass
    • Voice dialing, Voice commands, Voice recording, TTY/TDD


  • Officially announced:
    • 05 Sep 2012

Shopping information

  • Accessories:
    • Nokia AC-50 MicroUSB Charger, Nokia Charging and Data Cable CA-190CD, Nokia Headset WH-208, Product user guide

To see the full specifications with in-depth details click here.

Despite our efforts to provide full and correct Nokia Lumia 820 specifications, there is always a possibility of making a mistake. If you see any wrong or incomplete data, please LET US KNOW.
