Display
Size:
5.7 inches
6.4 inches
Resolution:
2560 x 1440 pixels, 513 PPI
2400 x 1080 pixels, 20:9 ratio, 409 PPI
Technology:
S-LCD 5
AMOLED
Refresh rate:
90Hz
Screen-to-body:
69.19 %
86.20 %
Colors:
16 777 216
Features:
Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
HDR support, Scratch-resistant glass (Corning Gorilla Glass 5), Ambient light sensor, Proximity sensor
Additional display:
2.0 inches, 160 pixels 1040 x, IPS LCD
Hardware
System chip:
Qualcomm Snapdragon 821 MSM8996 Pro-AB
Snapdragon 765G SM7250-AB (7 nm)
Processor:
Quad-core, 2150 MHz, Kryo, 64-bit
Octa-core, 2400 MHz, Kryo 475, 64-bit
GPU:
Adreno 530
Adreno 620
RAM:
4GB LPDDR4
8GB LPDDR4
Internal storage:
64GB
128GB (UFS 2.1), not expandable
Storage expansion:
microSDXC up to 2000 GB
Device type:
Smartphone
Smartphone
OS:
Android (8.0 Oreo, 7.0 Nougat)
Android (10)
Battery
Capacity:
3000 mAh
4115 mAh
Type:
Not user replaceable
Li - Polymer, Not user replaceable
Charging:
Qualcomm Quick Charge 3.0
OnePlus Warp Charge
Max charge speed:
Wired: 30.0W
Camera
Rear:
Single camera
Quad camera
Main camera:
12 MP (Sapphire crystal lens cover, OIS, Laser and PDAF, BSI sensor)
48 MP (OIS, PDAF)
Specifications:
Aperture size: F1.8; Sensor size: 1/2.3"; Pixel size: 1.55 μm
Aperture size: F1.8; Focal length: 26 mm; Sensor size: 1/2"; Pixel size: 0.8 μm
Second camera:
8 MP (Ultra-wide)
Specifications:
Aperture size: F2.2
Third camera:
2 MP (Macro)
Specifications:
Aperture size: F2.4
Fourth camera:
5 MP (Depth information)
Specifications:
Aperture size: F2.4
Flash:
Dual LED
Dual LED
Video recording:
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD), 1280x720 (HD) (120 fps)
3840x2160 (4K UHD) (30 fps), 1920x1080 (Full HD) (240 fps)
Features:
Hyperlapse, Video calling, Video sharing
Time-lapse video, EIS
Front:
16 MP (Wide Angle, Autofocus, HDR)
32 MP (Dual-Camera, EIS, HDR)
Video capture:
1920x1080 (Full HD)
3840x2160 (4K UHD) (30 fps)
Design
Dimensions:
6.39 x 3.14 x 0.31 inches (162.41 x 79.79 x 7.99 mm)
6.23 x 2.89 x 0.32 inches (158.3 x 73.3 x 8.2 mm)
Weight:
6.00 oz (170.0 g)
6.49 oz (184.0 g)
Materials:
Back: Glass; Frame: Aluminum
Back: Glass (Corning Gorilla Glass 5); Frame: Plastic
Biometrics:
Fingerprint (touch)
2D Face unlock, In-screen fingerprint
Features:
Touch sensitive control keys
Keys:
Right: Volume control, Lock/Unlock key
Left: Volume control; Right: Lock/Unlock key
Colors:
Black, Pink, Blue, White
Blue marble, Gray onyx
Cellular
5G:
n1, n3, n7, n28, n78, SA, NSA
4G (FDD):
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 17(700 b), 20(800 DD), 28(700 APT)
Bands 1(2100), 2(1900), 3(1800), 4(AWS-1), 5(850), 7(2600), 8(900), 12(700 a), 17(700 b), 18(800 Lower), 19(800 Upper), 20(800 DD), 26(850+), 28(700 APT), 32(1500 L-band), 66(AWS-3)
4G (TDD):
Bands 38(2600), 39(1900+), 40(2300), 41(2600+)
Bands 34(2000), 38(2600), 39(1900+), 40(2300), 41(2600+)
3G:
Bands 5(850), 8(900), 4(1700/2100), 2(1900), 1(2100)
Bands 1(2100), 2(1900), 4(1700/2100), 5(850), 6(800), 8(900)
Data Speed:
LTE-A Cat 12 (600/100 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
LTE-A Pro Cat 18 (1200/150 Mbit/s), HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s
Dual SIM:
Shared with microSD
Yes
SIM type:
Nano SIM
Nano SIM
HD Voice:
Yes
VoLTE:
Yes
Multimedia
Headphones:
No 3.5mm jack
No 3.5mm jack
Speakers:
Earpiece, Loudspeaker
Earpiece, Loudspeaker
Features:
Album art cover, Background playback
aptX, aptX-HD
Screen mirroring:
DLNA, Wireless screen share, SlimPort
Wireless screen share
Additional microphone(s):
for Noise cancellation, Video recording
for Noise cancellation
Connectivity & Features
Bluetooth:
4.2
5.1
Wi-Fi:
802.11 a, b, g, n, ac, dual-band; Hotspot, Wi-Fi Direct
802.11 a, b, g, n, ac, dual-band; MIMO, Wi-Fi Direct, Hotspot
USB:
Type-C (reversible), USB 3.1
Type-C (reversible), USB 2.0
Features:
Mass storage device, Video out, Charging, Headphones port
Charging, Headphones port, OTG
Location:
GPS, A-GPS, Glonass, BeiDou
GPS, A-GPS, Glonass, Galileo, BeiDou, Dual-band positioning, Cell ID, Wi-Fi positioning
Sensors:
Accelerometer, Gyroscope, Compass
Accelerometer, Gyroscope, Compass
Other:
NFC, UMA (Wi-Fi Calling), Tethering, Computer sync, OTA sync
NFC
Phone features
Notifications:
Haptic feedback
Other features:
Voice dialing, Voice commands, Voice recording
Regulatory Approval
FCC approval:
Date approved:
Aug 02, 2017
Jan 18, 2021
FCC ID value:
NM82PZF100
2ABZ2-EF014
Measured SAR:
Head:
1.03 W/kg
1.08 W/kg
Body:
0.22 W/kg
0.80 W/kg
Simultaneous Transmission:
1.26 W/kg
1.48 W/kg
Wireless Router:
0.54 W/kg
1.09 W/kg
Buyers information
Price:
$ 749
€ 399
In The Box:
Screen protector (pre-applied), Warp Charge 30 power adapter, Warp Type-C cable (Support USB 2.0), Quick start guide, Welcome letter, Safety information and warranty card, Brand sticker, Phone case, SIM tray ejector, Highest SAR value card
Availability
Officially announced:
Jan 12, 2017
Jul 21, 2020
